Model Number
607M140
Performance
Sensitivity(± 10 %)
Measurement Range
Frequency Range(± 3 dB)
Resonant Frequency
Broadband Resolution(1 to 10,000 Hz)
Non-Linearity
Transverse Sensitivity
Environmental
Overload Limit(Shock)
Temperature Range
Temperature Response
Enclosure Rating
Electrical
Settling Time(within 1% of bias)
Discharge Time Constant
Excitation Voltage
Constant Current Excitation
Output Impedance
Output Bias Voltage
Spectral Noise(10 Hz)
Spectral
Noise(100 Hz)
Spectral
Noise(1 kHz)
Electrical Isolation(Case)
Physical
Size (Hex x Height)
Weight
Mounting
Mounting Thread
Mounting Torque
Mounting Torque
Sensing Element
Sensing Geometry
Housing Material
Sealing
Electrical Connector
Electrical Connection Position
Cable Length
Cable Type
[6]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP
is a registered trademark of PCB Group, Inc.
INDUSTRIAL ICP® ACCELEROMETER
ENGLISH
SI
100 mV/g
10.2 mV/(m/s²)
± 80 g
± 785 m/s²
24 to 840,000 cpm
0.4 to 14,000 Hz
1500 kcpm
25 kHz
2
550 µg
5395 µm/sec
± 1 %
± 1 %
≤ 7 %
≤ 7 %
5000 g pk
49,050 m/s² pk
-65 to +250 °F
-54 to +121 °C
See Graph
See Graph
IP68
IP68
≤ 2.0 sec
≤ 2.0 sec
≥ 0.4 sec
≥ 0.4 sec
24 to 28 VDC
24 to 28 VDC
2 to 20 mA
2 to 20 mA
<150 Ohm
<150 Ohm
10 to 14 VDC
10 to 14 VDC
2
10 µg/√Hz
98.1 (µm/sec
)/√Hz
2
7 µg/√Hz
68.7 (µm/sec
)/√Hz
2
7 µg/√Hz
68.7 (µm/sec
)/√Hz
8
8
>10
Ohm
>10
Ohm
9/16 in x 0.97 in
14 mm x 24.6 mm
1.1 oz
31 gm
Stud
Stud
1/4-28 Male
No Metric Equivalent
3 to 4 ft-lb
4.1 to 5.4 Nm
2 to 3 ft-lb
2.7 to 4.1 Nm
Ceramic
Ceramic
Shear
Shear
Stainless Steel
Stainless Steel
Welded Hermetic
Welded Hermetic
Molded Integral Cable
Molded Integral Cable
Side
Side
10 ft
3.0 m
Polyurethane
Polyurethane
OPTIONAL VERSIONS
[2]
Optional versions have identical specifications and accessories as listed for the standard model
except where noted below. More than one option may be used.
[3]
[1]
[1]
[4]
[1]
NOTES:
[1] Typical.
[2] Conversion Factor 1g = 9.81 m/s².
[3] The high frequency tolerance is accurate within ±10% of the specified frequency.
[4] Zero-based, least-squares, straight line method.
[5] 1/4-28 has no equivalent in S.I. units.
[1]
[6] See PCB Declaration of Conformance PS023 for details.
[1]
[1]
[5]
SUPPLIED ACCESSORIES:
Model 080A156 Mounting Base (1)
Model ICS-2 NIST-traceable single-point amplitude response calibration at 6000 cpm (100 Hz)
for each axis (1)
Entered: LK
Engineer: RB
Sales: MC
Date: 3/22/2018
Date: 3/22/2018
Date: 3/22/2018
3425 Walden Avenue, Depew, NY 14043
Revision: NR
ECN #: 47985
Approved: BAM
Spec Number:
69070
Date: 3/22/2018
Phone: 800-959-4464
Fax: 716-684-3823
E-Mail: imi@pcb.com
