- Page 1 User’s Manual ™ Sunlight Readable RGB RackMount Rack Mount High Brightness LCD Monitor SRM-10V Series SRM-15X Series SRM-18W Series Manual P/N: 01-854 Revision 1.0 The Innovators of Flat Panel Technology...
- Page 2 Please take a moment..to record the following information in the space provided below. Should the need arise to contact General Digital™ regarding your LCD monitor, this information will help us to better serve you. You will fi nd the model number/serial number label affi xed to the rear of your monitor.
-
Page 3: Table Of Contents
Table of Contents Precautions .................4 Package Contents..............7 Installation .................8 Connections................9 Troubleshooting ...............12 Specifi cations..............13 Options & Accessories .............14 Mechanical Drawing ............15 Warranty................16 Contact Information ............18 Sunlight Readable RGB RackMount ™ User’s Manual The Innovators of Flat Panel Technology... -
Page 4: Precautions
Precautions Installation ™ General Digital recommends that you install or leave the monitor: • In a place free of extreme temperatures, i.e., away from radiators, heating vents, direct sunlight. • In a place free of mechanical vibration and shock. • In a place far from any equipment that generates a strong magnetic fi eld. •... - Page 5 Precautions (continued) Characteristics of the LCD Screen • Keep the LCD from facing direct sunlight for extended periods as this can damage the screen. • The LCD screen may lose uniformity or otherwise malfunction if pushed, scratched or has a heavy object set upon it. •...
- Page 6 Precautions (continued) Transportation • Disconnect all cables from the monitor and grasp the support and base sections of the display stand fi rmly with both hands when transporting. If you drop the monitor, you may be injured or the monitor may be damaged. •...
-
Page 7: Package Contents
™ One (1) Sunlight Readable RGB RackMount model from one of the following LCD monitor families: SRM-10V Series SRM-15X Series SRM-18W Series One (1) Documentation CD with User’s Manuals and LCD Monitor Calibration & Setup Guides in PDF format; and Adobe ®... -
Page 8: Installation
Installation 19" Rack Mount 1) Affi x your monitor to a 19" rack. 2) Attach a shielded video cable (connected at one end to your computer, work- station or composite NTSC/PAL video source) to the video connector(s) located on the rear of the unit. 3) A. -
Page 9: Connections
To reference the information about the connectors on your unit, simply match the connectors on your unit with the photos on these pages. AC Power Connector/Line Entry Filter (IEC type) GD Part No.: 16-011/16-020 Manufacturer: Corcom/Corcom Manufacturer Part No.:... - Page 10 Connections (continued) DC Power Input Connector: 3-pin 3W3 Enclosure Mating Connector GD Part No.: 30-425/30-364 30-382 Manufacturer: Cinch/ITT Cannon Cinch Manufacturer Part No.: 008 0328-3/DAMC3H3PJK87 008 00334-4 PIN NUMBER SIGNAL 1 (A1) +12 VDC 30-425 2 (A2) — 3 (A3)
- Page 11 Connections (continued) VGA Input Connector: 15-pin High Density Enclosure Mating Connector GD Part No.: 30-238 30-239 Manufacturer: Amphenol (or equivalent) Amphenol (or equivalent) Manufacturer Part No.: 17HD015SAA000 17HD015PAA000 PIN NUMBER SIGNAL Green 30-238 Blue — Ground Red Return 30-239 Green Return Blue Return —...
-
Page 12: Troubleshooting
Troubleshooting FAILURE POSSIBLE CAUSE SOLUTION No Image No Power If the Green LED on the front bezel is illuminated, it indicates that the power supply is functional and connected properly. If the LED does not function properly, continue with the next set of instructions. No Image Defective AC Cable/ Verify that the power supply is properly connected to the... -
Page 13: Specifi Cations
Specifi cations SRM -10V SRM -15X Display Size (Diagonal) 10.4" 15.0" Resolution (Pixels) 640 x 480 1024 x 768 Colors 262,144 16.7 Million Luminance (Minimum) 1600 Nits 1800 Nits Contrast* 400:1 350:1 Hor. Viewing Angle (Min.) ±70° ±60° Vert. Viewing Angle (Min.) +40°, -70°... -
Page 14: Options & Accessories
Options & Accessories Though the most popular options and accessories are listed here, we have many others from which to choose. Please visit our web site at http://www.GeneralDigital.com or inquire with a Sales Engineer for details. LCD DISPLAY OVERLAY* Clear Float Glass, Antiglare One Side Clear Float Glass, Antiglare Two Sides Clear Float Glass, Antirefl... -
Page 15: Mechanical Drawing
Mechanical Drawing Sunlight Readable RGB RackMount ™ User’s Manual The Innovators of Flat Panel Technology... -
Page 16: Warranty
Warranty ™ GENERAL DIGITAL CORPORATION (hereinafter Seller) STANDARD TERMS AND CONDITIONS OF SALES 1. Acknowledgment and acceptance of any order by seller is • Unauthorized modifi cation of the product by any means. expressly limited to and made conditional upon the terms •... - Page 17 Warranty (continued) expense and at its option, either procure for the Buyer the 11. ARBITRATION. Any controversy or claim arising out right to continue using said product or part, or replace same of or relating to this agreement shall, at the option of either with non-infringing comparable products, or modify it so it party, be settled by arbitration in accordance with the rules becomes non-infringing, or refund the purchase price thereof.
-
Page 18: Contact Information
Contact Information We want you to be completely satisfi ed with your product. Please feel welcome to contact us should you require any of our services. General Digital ™ Corporation 8 Nutmeg Road South South Windsor, CT 06074 Phone: 860.282.2900 Toll-Free: 800.952.2535 Fax:...
