CleverMic 4012UHN User Manual

4k video conference camera

Advertisement

Quick Links

4K Video Conference Camera
User Manual
4K Video Conference Camera
User Manual
English (V1.0)
Copyright Notice
All contents of this manual, whose copyright belongs to our Corporation cannot be cloned, copied or
translated without the permission of the company. Product specifications and information which
were referred to in this document are for reference only. We may change, delete, or update any
content at any time and without prior notice.
=============================================================================
This is class A production. Electromagnetic radiation at specific frequencies may affect the image
quality of TV in home environment.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4012UHN and is the answer not in the manual?

Questions and answers

Summary of Contents for CleverMic 4012UHN

  • Page 1 4K Video Conference Camera User Manual 4K Video Conference Camera User Manual English (V1.0) Copyright Notice All contents of this manual, whose copyright belongs to our Corporation cannot be cloned, copied or translated without the permission of the company. Product specifications and information which were referred to in this document are for reference only.
  • Page 2: Table Of Contents

    4K Video Conference Camera User Manual Catalogue 1 Note ..........................1 2 Packing List ........................ 1 3 Quick Start ........................1 4 About Product ......................2 4.1 Features ............................ 2 4.2 Product Specification ......................... 2 4.3 Interfaces and Buttons ......................4 4.4 Dimension ..........................
  • Page 3 4K Video Conference Camera User Manual 6.5.1 Setup IP Controlled by Dynamic DNS .................. 12 6.5.2 Dynamic DNS Visit Camera ....................12 6.5.3 VLC Stream Media Player Monitor ..................12 6.6 Camera Parameter Setup ....................... 13 6.6.1 Homepage Introduction ......................13 6.6.2 Video Settings ........................
  • Page 4: Note

    4K Video Conference Camera User Manual environment to avoid any cover (plastic Note material) damage. Make sure there is no obstacle within rotation range.  Electric Safety Please never power on before installation is Installation and operation must accord with completed.
  • Page 5: About Product

    4K Video Conference Camera User Manual  Multiple Interfaces 2) Connect the power adapter to the power connector on the rear panel of the camera. It supports HDMI 2.0 HD output, and also The power indicator on the front panel of equipped with 3G-SDI interface, the effective the camera is on.
  • Page 6 4K Video Conference Camera User Manual Backlight 3840x2160, 1920x1080, Support Compensation First Stream 1280x720, 1024x576, Resolution 960x540, 640x480, Digital Noise 2D & 3D Digital Noise 640x360 Reduction Reduction 1920x1080, 1280x720, Signal Noise ≥55dB 1024x576, 720x576 (50Hz Ratio Second Stream support), 720x480 (60Hz Horizontal Angle 60°...
  • Page 7: Interfaces And Buttons

    4K Video Conference Camera User Manual 1 x USB 3.0: Up to 4.4 Dimension 4K@60fps compressed USB Interface video and 1080P original video can be output Power Jack JEITA type (DC IN 12V) Physical Parameter Input Voltage DC 12V / PoE (802.3af) Current 1.0A (Max) Consumption...
  • Page 8: Remote Control

    4K Video Conference Camera User Manual Key Description 1. Standby Key Press this button to enter standby mode. Press it again to enter normal mode. Note: Power consumption in standby mode is approximately half of the normal mode 2. Number Key To set preset or call preset.
  • Page 9: Rs232 Interface

    4K Video Conference Camera User Manual 13. Reset Key 4.6 RS232 Interface Clear preset: Erase a preset position. [CLEAR PRESET] + Numeric button (0-9) Or: [*]+[#]+[CLEAR PRESET]: Erase all the preset individually. 14. PTZ Control Key Press arrow buttons to perform panning and tilting.
  • Page 10: Visca Network

    4K Video Conference Camera User Manual 4.7 VISCA Network GUI Settings 5.1 MENU Press [MENU] button to display the main menu on the normal screen, using arrow button to move the cursor to the item to be set. Press the [HOME] button to enter the corresponding sub-menu.
  • Page 11: Color

    4K Video Conference Camera User Manual ExpComp: Exposure the compensation value, WB-Mode: White balance mode, optional optional items: -7 ~ 7 (Effective only in items: Auto, Indoor, Outdoor, One Push, ExpCompMode item to On). Manual, VAR. Backlight: Set the backlight compensation, RG Tuning: Optional items: 0 ~ +10 (Effective optional items: On, Off (Effective only in Auto only in Auto mode);...
  • Page 12: P/T/Z

    4K Video Conference Camera User Manual Flip-H: Image flipped horizontally, optional 5.6 NOISE REDUCTION items: On, Off. Move the main menu cursor to [NOISE Flip-V: Image Flip Vertical, optional items: On, REDUCTION], and press [HOME] key enter Off. the noise reduction page, as shown in the B&W-Mode: Optional items: On, Off.
  • Page 13: Restore Default

    4K Video Conference Camera User Manual [HOME] key enter the communication setup Network Function page, as shown in the following figure. COMMUNICATION SETUP 6.1 Operating Environment Protocol VISCA Operating System: Windows 7/8/10, Mac OS X, V_Address V_AddrFix Linux, Android Net Mode Serial Network Protocol: TCP/IP Baudrate...
  • Page 14: Visit/Access Camera

    4K Video Conference Camera User Manual If you don't know camera IP, view as below: Method 2: Open “upgrade_En.exe”, change IP Method 1: Press * and # and 4 on remote and click “Set”. After modified, the video controller one by one, the camera IP address conference camera will be restart.
  • Page 15: Camera Controlled By Wan

    4K Video Conference Camera User Manual 6.5.2 Dynamic DNS Visit Camera Set domain name to camera, setup the parameter, then dynamic DNS can access camera. Access link: http://hostname: port number. For example, setup host computer name: youdomain.f3322.org, the camera port number is 89, the access link should be http://youdomain.3322.org:89.
  • Page 16: Camera Parameter Setup

    4K Video Conference Camera User Manual B. PTZ Setup RTSP port number default 554. If the camera port default is 80, then unnecessary to input port number of URL address. 6.6 Camera Parameter Setup 1) Pan and Tilt Control 6.6.1 Homepage Introduction Up, Down, Left and Right arrows and the home Menu button allow you to manually drive the camera...
  • Page 17: Video Settings

    4K Video Conference Camera User Manual Click the "Set" button to save the current 6.6.2 Video Settings location with that preset number. Click the “Call” button to cause the camera to return to that position. This enables smooth, quick and convenient control without the need to manually drive the camera.
  • Page 18: Image Settings

    4K Video Conference Camera User Manual 4) Resolution 11) Split Mode First stream support 3840x2160, 1920x1080, Select split mode, optional items: Fixed blocks, 1280x720, 1024x576, 960x540, 640x480, Fixed bytes. 640x360. Second stream support 1920x1080, 12) Slice Size 1280x720, 1024x576, 720x576 (50Hz support), Set the size of slice.
  • Page 19: Audio Settings

    4K Video Conference Camera User Manual 5) Hue 6.6.5 System Settings Hue 0 ~ 14, slider control, on the right shows the corresponding numerical. Default value is 7. 6) Flip & Mirror Tick Flip to realize image upside down, tick mirror to realize image around the mirror.
  • Page 20: Device Information

    4K Video Conference Camera User Manual (default value is 6688, then 6688 is the 1) Lan Settings multicast port of the first stream; 6690 is the Default the IP address is 192.168.100.88, the multicast port of the second stream). MAC address cannot be modified. 8) SDK Settings 2) Port Settings Turn On/Off active connection.
  • Page 21 4K Video Conference Camera User Manual Unqualified Application  Unable to access video conference camera  No shooting extreme bright object for a long through IE Browser period of time, such as sunlight, light 1) Using PC to access the network to test whether the network access can work sources, etc.
