Page 1: User Manual
CleverMic Uno USB3.0 HD Video Camera User Manual Version V1.1 （English）... -
Page 2: Table Of Contents
Contents SAFETY GUIDES..................................1 ACCESSORIES ..................................2 QUICK START ..................................2 PRODUCT HIGHLIGHTS ..............................3 CAMERA SPEC ..................................3 CAMERA INTERFACE ................................. 3 CAMERA DIMENSION ................................. 4 IR REMOTE CONTROLLER ............................... 5 VISCA IN（RS232）PORT..............................7 VISCA PROTOCOL ................................8 PELCO-D PROTOCOL ............................... 14 PELCO-P PROTOCOL ................................ -
Page 3: Safety Guides
SAFETY GUIDES 1.Before operation, please fully read and follow all instructions in the manual. For your safety, always keep this manual with the camera. 2.The camera power input range is 100-240VAC(50-60Hz),ensure the power supply input within this rate before powering on. 3.The camera power voltage is 12VDC, rated currency is 2A. -
Page 4: Accessories
ACCESSORIES Check all bellow items when open the package: Camera ··············································· 1 Power Adapter ······································ 1 Power Cable ········································· 1 RS232 Control Cable ······························· 1 USB3.0 Cable ······································· 1 Remote Controller ·································· 1 User Manual ········································· 1 Double-sided Adhesive ···························· 1 QUICK START 1.Check all cable connections before power on. -
Page 5: Product Highlights
PRODUCT HIGHLIGHTS 1. Fashionable and smart design, with advanced Ambarella A9 DSP, provides ultra crystal image quality. 2. DVI-I(HDMI) &USB3.0 simultaneously output. 3. Fast switching between different video format: only 3 seconds needed. 4. USB2.0 compatible. 5.Daisy chain function: with both Visca in and Visca out port. 6. -
Page 6: Camera Dimension
CAMERA DIMENSION(mm) -
Page 7: Ir Remote Controller
IR REMOTE CONTROLLER POWER Under normal working mode, short press POWER key, the camera will enter stand by mode; Press again, camera will self-configuration, then go back to HOME position. It will go to preset position if power on model has been set before. - Page 8 FOCUS KEY( ON THE LEFT) Manual focus, only valid under manual focus model. ZOOM KEY( ON THE RIGHT SIDE) Set the zoom rate NAVIGATE KEY: UP/DOWN/LEFT/RIGHT Under working mode, use navigate key to set the pan tilt, and select menu when enter OSD. OK /HOME KEY Under working mode, short press OK to make the camera go back to HOME position;...
-
Page 9: Visca In(Rs232) Port
VISCA IN(RS232) PORT VISCA IN & RS485 Connection Function Camera VISCA IN RS485 A(+) A(+) IR OUT B(-) B(-) IR OUT VISCA IN & Mini DIN Connection VISCA IN & DB9 Connection Camera VISCA IN Mini DIN Camera VISCA IN Windows DB-9 A(+) A(+) -
Page 10: Visca Protocol
SERIAL PORT CONFIGURATION Parameter Value Parameter Value Baud rate 2400/4800/9600/115200 Stop Bit 1bit Start Bit 1 bit Check Bit None Date Bit 8 bit VISCA PROTOCOL Part1 Camera Return Command Ack/Completion Message Command Packet Note z0 41 FF Returned when the command is accepted. Completion z0 51 FF Returned when the command has been executed. - Page 11 Command Function Command Packet Note Manual 8x 01 04 35 05 FF Outdoor Auto 8x 01 04 35 06 FF Sodium Lamp Auto 8x 01 04 35 07 FF Sodium Auto 8x 01 04 35 08 FF Reset 8x 01 04 03 00 FF 8x 01 04 03 02 FF Manual Control of R Gain CAM_RGain...
- Page 12 Command Function Command Packet Note 8x 01 04 A4 02 FF Mount Up CAM_MountMode Down 8x 01 04 A4 03 FF Mount Down CAM_ColorGain Direct 8x 01 04 49 00 00 00 0p FF (0~0x0E) CAM_2D Direct 8x 01 04 53 0p FF (0~0x05) Noise Reduction CAM_3D...
- Page 13 Command Function Command Packet Note Home 8x 01 06 04 FF Reset 8x 01 06 05 FF 8x 01 06 07 00 0W W:1 UpRight 0:DownLeft 0Y 0Y 0Y 0Y 0Z 0Z 0Z 0Z FF Pan-tiltLimitSet YYYY: Pan Limit Position(TBD) 8x 01 06 07 01 0W ZZZZ: Tilt Limit Position(TBD) Clear...
- Page 14 11:1440*900@60HZ(USB OUTPUT) 12:1366*768@60HZ(USB OUTPUT) 13:1280*800@60HZ(USB OUTPUT) 14:1024*768@60HZ(USB OUTPUT) 15:800*600@60HZ(USB OUTPUT) 16:800*600@30HZ(USB OUTPUT) 17:640*480@60HZ(USB OUTPUT) 18:640*480@30HZ(USB OUTPUT) y0 50 02 FF IR_Transfer 8x 09 06 1A FF y0 50 03 FF y0 50 02 FF IR_Receive 8x 09 06 08 FF y0 50 03 FF y0 07 7D 01 04 00 FF Power ON/OFF...
- Page 15 VISCA Exposure Value 1/10000 close 1/6000 1/4000 1/3000 1/2000 1/1500 1/1000 1/725 1/500 f9.6 Iris 1/350 f6.8 1/250 f5.6 Shutter speed 1/180 f4.8 1/125 f4.0 1/100 f3.4 1/90 f2.8 1/60 f2.4 1/30 f2.0 1/15 f1.8 16dB 18dB 20dB 22dB Gain Gain 24dB 10dB...
- Page 16 x5.8 0x34BC x6.9 0x37A4 x8.2 0x3A98 x9.9 0x3D8C x11.8(tele) 0x4000...
-
Page 17: Pelco-D Protocol
PELCO-D PROTOCOL Function Byte1 Byte2 Byte3 Byte4 Byte5 Byte6 Byte7 0xFF Address 0x00 0x08 Pan Speed Tilt Speed Down 0xFF Address 0x00 0x10 Pan Speed Tilt Speed Left 0xFF Address 0x00 0x04 Pan Speed Tilt Speed Right 0xFF Address 0x00 0x02 Pan Speed Tilt Speed... -
Page 18: Pelco-P Protocol
PELCO-P PROTOCOL Function Byte1 Byte2 Byte3 Byte4 Byte5 Byte6 Byte7 Byte8 0xA0 Address 0x00 0x08 Pan Speed Tilt Speed 0xAF Down 0xA0 Address 0x00 0x10 Pan Speed Tilt Speed 0xAF Left 0xA0 Address 0x00 0x04 Pan Speed Tilt Speed 0xAF Right 0xA0 Address... -
Page 19: Osd Menu
OSD MENU 1.Under working mode, press the MENU key on the IR remote controller, to enter the OSD menu as bellow shows: 2.After enter the main menu, use the navigate key to select the main menu. Once been selected, the main menu will change to blue background, and the right side will show all sub menu options . - Page 20 White Balance:AUTO、INDOOR、OUTDOOR、MANUAL、OUTAUTO、 WB MODE SODIUM LAMP AUTO 、SODIUM LAMP R GAIN Red gain level: 0~255, only valid under manual white balance mode. IMAGE B GAIN Blue gain level:0~255 , only valid under manual white balance mode. COLOR G Color gain setting: 0~14 FLICK Anti-Flicker setting:50/60HZ, to reduce the video flicker 2D noise reduction:0~5, the bigger value, the less noise on image, the lower...
-
Page 21: Ir Transfer(Ir Pass)
IR TRANSFER(IR PASS) 1 IR transfer( IR Pass) function available by setting the SW3 and SW4( at the bottom of the camera). Currently the camera support NEC and SEJIN 4PPM code. For customized with other code, pls contact us for adding: Dial Switch（IR CODE TYPE）... -
Page 22: Uvc Control
UVC CONTROL 1. Only run the client software after the USB3.0 HD camera has completed self-configuration(the IR indicator in blue color and will not flash); If run the software before the camera configuration finishes, may cause black video issue. 2. Make sure the USB3.0 camera is recognized by the PC Device Manager. In case the PC does not recognize the camera(with warning of “MFG”), following bellow steps: 1).Go to Device Manager.
