RCB732E4MG
USER
MANUAL
EN
User Manual
Freezer - Fridge

Advertisement

Table of Contents
loading

Related Manuals for AEG RCB732E4MG

Summary of Contents for AEG RCB732E4MG

  • Page 1 RCB732E4MG User Manual Freezer - Fridge USER MANUAL...
  • Page 2 EN FIRE Warning; Risk of fire / flammable materials EN -2-...

  • Page 3: Table Of Contents

    INdEx BEFORE USING THE APPLIANCE ............5 General warnings ..................... 5 Old and out-of-order fridges or freezer ............10 Safety warnings ....................10 Installing and operating your fridge freezer ............ 11 Before Using your Fridge ................12 Dimensions ..................... 13 THE VARIOUS FUNCTION ANd POSSIBILITIES ......
  • Page 4 FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.

  • Page 5: Before Using The Appliance

    PART - 1. BEFORE USING THE APPLIANCE General warnings This appliance is not intended to be used as a built-in appliance. WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.
  • Page 6 • Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance. • This appliance is intended to be used in household and domestic applications such as: - staff kitchen areas in shops, offices and other working environments.
  • Page 7 use appliances safely unless continuous supervision is given, older children (8-14 years old) and vulnerable people can use appliances safely after they have been given appropriate supervision or instruction concerning use of the appliance. Very vulnerable people are not expected to use appliances safely unless continuous supervision is given.
  • Page 8 Service • To repair the appliance contact the Authorised Service Centre. Use original spare parts only. • Please note that self-repair or nonprofessional repair can have safety consequences and might void the guarantee. • The following spare parts will be available for 7 years after the model has been discontinued: thermostats, temperature sensors, printed circuit boards, light sources, door handles, door hinges, trays and baskets.
  • Page 9 ELECTRICAL INFORMATION (FOR UK TYPE PLUG) Warning! This appliance must be earthed. The mains lead of this appliance has been fitted with a specially earthed plug. Important: Do not use the appliance without the fuse cover in position. Should the fuse need to be replaced, it must be replaced with a 13A fuse, ASTA approved to BS1362.

  • Page 10: Old And Out-Of-Order Fridges Or Freezer

    Old and out-of-order fridges or freezer • If your old fridge or freezer has a lock, break or remove the lock before discarding it, because children may get trapped inside it and may cause an accident. • Old fridges and freezers contain isolation material and refrigerant with CFC. Therefore, take care not to harm environment when you are discarding your old fridges.

  • Page 11: Installing And Operating Your Fridge Freezer

    • Do not place glass bottles or cans in the ice-making compartment as they will burst when the contents freeze. • Do not place explosive or flammable material in your fridge. Place drinks with high alcohol content vertically in the fridge compartment and make sure their tops are tightly closed.

  • Page 12: Before Using Your Fridge

    • Before using your fridge freezer, wipe all parts with a solution of warm water and a teaspoon of sodium bicarbonate. Then, rinse with clean water and dry. Return all parts to the fridge freezer after cleaning. • Install the two plastic distance guides (the parts on the black vanes -condenser- at the rear) by turning it 90°...

  • Page 13: Dimensions

    dimensions Overall dimensions Overall space required in use 1860 1197 the height, width and depth of the appliance including the handle, the height, width and depth of the plus the space necessary for free appliance without the handle circulation of the cooling air, plus the space necessary to allow door opening to the minimum Space required in use...

  • Page 14: The Various Function And Possibilities

    PART - 2. THE VARIOUS FUNCTION ANd POSSIBILITIES Information about New Generation Cooling Technology Fridges with new-generation cooling technology have a different operating system to static fridges. Other (static) fridges may experience a build up of ice in the freezer compartment due to door openings and humidity in the food.

  • Page 15: Display And Control Panel

    display and Control Panel Using the Control Panel 1. Enables the setting of the freezer. 2. Enables the setting of the cooler. 3. Freezer set value screen. 4. Cooler set value screen. 5. Economy mode symbol. 6. Super freeze symbol. 7.

  • Page 16: Door Open Alarm Function

    Notes: • The maximum amount of fresh food (in kilograms) that can be frozen within 24 hours is shown on the appliance label. • For optimal appliance performance in maximum freezer capacity, activate super freeze mode 3 hours before you put fresh food into the freezer. Super freeze mode will automatically cancel after 24 hours, depending on the environmental temperature or when the freezer sensor reaches a sufficiently low temperature.

  • Page 17: Accessories

    Climate class Meaning Ambient Temperature This refrigerating appliance is intended to be used at Tropical ambient temperatures ranging from 16 °C to 43 °C. This refrigerating appliance is intended to be used at Subtropical ambient temperatures ranging from 16 °C to 38 °C. This refrigerating appliance is intended to be used at Temperate ambient temperatures ranging from 16 °C to 32 °C.

  • Page 18: Extra Chill Compartment

    Extra Chill Compartment (In some models) Ideal to preserve the taste and texture of fresh cuts and cheese. The pull out drawer assures an environment with a lower temperature compared to the rest of the fridge, thanks to the active circulation of cold air.

  • Page 19: Arranging Food In The Appliance

    PART - 3. ARRANGING FOOd IN THE APPLIANCE Refrigerator compartment • Fresh food compartment is the one marked (on the rating plate) with • To reduce humidity and avoid the consequent formation of frost, always store liquids in sealed containers in the refrigerator. Frost tends to concentrate in the coldest parts of the evaporating liquid and, in time, your appliance will require more frequent defrosting.

  • Page 20: Freezer Compartment

    Food Maximum storage time How and where to store Eggs 1 month On the designated egg shelf Cooked food 2 Days All shelves Freezer compartment • Freezer compartment is the one marked with • The freezer is used for storing frozen food, freezing fresh food, and making ice cubes. •...
  • Page 21 • The storage time of food is dependent on the type of oil used. Suitable oils are margarine, calf fat, olive oil and butter. Unsuitable oils are peanut oil and pig fat. • Food in liquid form should be frozen in plastic cups and other food should be frozen in plastic folios or bags.
  • Page 22 Maximum storage time Vegetables and Fruits Preparation (months) String beans and Wash, cut into small pieces and boil in water 10 - 13 beans Beans Hull, wash and boil in water Cabbage Clean and boil in water 6 - 8 Carrot Clean, cut into slices and boil in water Cut the stem, cut into two pieces, remove the...

  • Page 23: Cleaning And Maintenance

    PART - 4. CLEANING ANd MAINTENANCE Disconnect the unit from the power supply before cleaning. Do not wash your appliance by pouring water on it. Do not use abrasive products, detergents or soaps for cleaning the appliance. After washing, rinse with clean water and dry carefully. When you have finished cleaning, reconnect the plug to the mains supply with dry hands.

  • Page 24: Defrosting

    defrosting Your refrigerator performs automatic defrosting. The water formed as a result of defrosting passes through the water collection spout, flows into the vaporisation container behind your refrigerator and evaporates there. • Make sure you have disconnected the plug of your refrigerator before cleaning the vaporisation container.

  • Page 25: Before Calling Your After Sales Service

    PART - 6. BEFORE CALLING YOUR AFTER SALES SERVICE Errors Your fridge will warn you if the temperatures for the cooler and freezer are at improper levels or if a problem occurs with the appliance. Warning codes are displayed in the freezer and cooler indicators.
  • Page 26 ERROR TYPE MEANING WHAT TO dO 1. Set the fridge temperature to a colder value or set Super Cool. This should remove the error code once the required temperature has been reached. Keep doors closed to improve time taken to reach the correct Likely to occur after: Fridge temperature.
  • Page 27 Your refrigerator is operating noisily The following noises can be heard during normal operation of the appliance. Cracking (ice cracking) noise occurs: • During automatic defrosting. • When the appliance is cooled or warmed (due to expansion of appliance material). Clicking noise occurs: When the thermostat switches the compressor on/off.

  • Page 28: Hints For Energy Saving

    • This appliance is designed for domestic use and for the stated purposes only. It is not suitable for commercial or common use. If the consumer uses the appliance in a way that does not comply with these instructions, we emphasise that the manufacturer and the dealer will not be responsible for any repair or failure within the guarantee period.

  • Page 29: The Parts Of The Appliance And The Compartments

    PART - 7. THE PARTS OF THE APPLIANCE ANd THE COMPARTMENTS This presentation is only for information about the parts of the appliance. Parts may vary according to the appliance model. A) Refrigerator compartment 8) Freezer midle basket B) Freezer compartment 9) Freezer bottom basket 1) Thermostat box / Interior display 10) Levelling feet...

  • Page 30: Technical Data

    PART - 8. TECHNICAL dATA The technical information is situated in the rating plate on the internal side of the appliance and on the energy label. The QR code on the energy label supplied with the appliance provides a web link to the information related to the performance of the appliance in the EU EPREL database.
  • Page 31 52309748...
