Summary of Contents for Sercomm SZ-DWS02
- Page 1 SZ-DWS02 ZigBee Door / Window Sensor User Guide...
-
Page 3: Table Of Contents
Table of Contents CHAPTER 1 INTRODUCTION..................1 Package Contents ....................1 Specfication ................錯誤! 尚未定義書籤。 CHAPTER 2 DEVICE DESCRIPTION ................2 Components......................2 Installation Guide ....................3 Preparing the Sensor for Installation ..............6 Operation....................... 7 CHAPTER 3 REGULATORY APPROVAL ..............8 ... -
Page 5: Chapter 1 Introduction
ZigBee Door/Window Sensor is a consumer electronic device, which is used for home monitoring and security. Package Contents The following items should be included: SZ-DWS02 sensor Magnet Adhesive Tape x 2 pcs for Magnet / Sensor ... -
Page 6: Chapter 2 Device Description
Chapter 2 Device Description This Chapter provides device description for the ZigBee Door/Window Sensor. Components... -
Page 7: Installation Guide
Installation Guide Main Body:... - Page 8 Magnet:...
- Page 9 The mgnet shall be fixed to close to the specific area, and the distance from sensor shall not be over 1.27cm (0.5 inch)
-
Page 10: Preparing The Sensor For Installation
Preparing the Sensor for Installation The Sensor & Magnet contact can be mounted vertically or horizontally but note that the Magnet contact must be aligned (on the same side) as the alignment marks on the Sensor. -
Page 11: Operation
Operation 1. Normal operation, the LED will not light. 2. The sensor equipped with tamper switch. If the cover of sensor is removed, the door sensor will send an alarm report to the ZigBee interface controller. Before replacing the cover, the sensor is under “Awake” mode ：... -
Page 12: Chapter 3 Regulatory Approval
Chapter 3 REGULATORY APPROVAL FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. - Page 13 CE Approval CE Standards This product complies with the 99/5/EEC directives, including the following safety and EMC standards: EN300328-2 EN301489-1/-17 EN60950 CE Marking Warning This is a Class B product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures.
