1.
Overview .......................................................................................................................................................... 2
1.1.
A1101R09A ................................................................................................................................................. 2
1.2.
A1101R09C ................................................................................................................................................. 2
1.3.
Features ....................................................................................................................................................... 2
1.4.
Theory of Operation .................................................................................................................................. 3
1.4.1.
Typical Flow ..................................................................................................................................... 6
1.5.
Applications ............................................................................................................................................... 7
2.
Product Approvals .......................................................................................................................................... 8
2.1.
2.1.1.
FCC Labeling Requirements ............................................................................................................. 8
2.1.2.
End User Manual ............................................................................................................................. 9
2.1.3.
RF Exposure ...................................................................................................................................... 9
2.2.
Canada (Industry Canada, IC) ............................................................................................................... 10
2.3.
Potential Interference Sources ................................................................................................................ 11
2.3.1.
Time critical data ............................................................................................................................ 11
2.4.
Approved Usage ...................................................................................................................................... 11
2.4.1.
USA & Canada ............................................................................................................................... 12
3.
Electrical Characteristics .............................................................................................................................. 13
3.1.
Absolute Maximum Ratings .................................................................................................................. 13
3.2.
Operating Conditions ............................................................................................................................. 13
3.3.
Pin Out ...................................................................................................................................................... 13
3.4.
Recommended Layout ............................................................................................................................ 16
3.5.
Power Supply Considerations ............................................................................................................... 18
Anaren AIR Module, Users Manual
U s e r s M a n u a l
Models A1101R09A and A1101R09C
1/18, 8/18/2010:3:57 PM
) ..................................................................... 8
Advertisement
Table of Contents
Related Manuals for Anaren A1101R09A
Summary of Contents for Anaren A1101R09A
-
Page 1: Table Of Contents
Anaren AIR Module, Users Manual U s e r s M a n u a l Models A1101R09A and A1101R09C Contents Overview ................................2 1.1. A1101R09A ..............................2 1.2. A1101R09C ..............................2 1.3. Features ............................... 2 1.4. Theory of Operation ..........................3 1.4.1. -
Page 2: Overview
States (FCC) and Canada under Industry Canada (IC) Radio Standards Specification (RSS) RSS-210 and RSS-Gen. The modular approval allows the end user to place either an A1101R09A or an A1101R09C with an approved antenna inside a finished product without having to perform costly regulatory testing for an intentional radiator. -
Page 3: Theory Of Operation
1.4. Theory of Operation The A1101R09A and A1101R09C are for low power wireless applications in the US 902 – 928MHz ISM band. The devices can be used to implement a variety of networks, including; point to point, point to multipoint, peer to peer and mesh networks The A1101R09A and A1101R09C both interface to an application microcontroller via SPI bus. - Page 4 Anaren AIR Module, Users Manual depend not only on the antenna, but also the ground plane, enclosure and installation environment. • Filtering Filtering removes spurious signals to comply with regulatory intentional radiator requirements. • Matching The matching provides the correct loading of the transmit amplifier to achieve the highest output power as well as the correct loading for the receive LNA to achieve the best sensitivity.
- Page 5 Anaren AIR Module, Users Manual Figure 1 The functionality of the A1101R09A, using an integral antenna Figure 2 The functionality of the A1101R09C, using an external antenna. 5/18, 8/18/2010:3:57 PM...
-
Page 6: Typical Flow
Anaren AIR Module, Users Manual Figure 3 Transceiver IC block diagram. 1.4.1. Typical Flow After initial setup of registers for desired behavior, the normal operation flow diagram is shown in Figure 4. In applications of infrequent data transmissions the transceiver would be in “sleep” mode to save power (400nA). -
Page 7: Applications
Anaren AIR Module, Users Manual Figure 4 Transceiver state diagram 1.5. Applications Ultra low-power wireless applications, operating in the 902-928 MHz ISM band. Wireless alarm and security systems Industrial monitoring and control Wireless sensor networks AMR – Automatic Meter Reading... -
Page 8: Product Approvals
“Intentional Radiators”. The devices meet the requirements for modular transmitter approval as detailed in FCC public notice DA 00-1407 Released: June 26, 2000. The A1101R09A and A1101R09C module can be integrated into a finished product with obtaining subsequent FCC approvals. -
Page 9: End User Manual
If the A1101R09A and A1101R09C module is used in a portable application (antenna is less than 20 cm from persons during operation), the end user is responsible for performing Specific Absorption Rate (SAR) testing in accordance with FCC rules 2.1091. -
Page 10: Canada (Industry Canada, Ic)
Anaren AIR Module, Users Manual 2.2. Canada (Industry Canada, IC) The A1101R09A and A1101R09C modules has been certified for use in Canada under Industry Canada (IC) Radio Standards Specification (RSS) RSS-210 and RSS-Gen. From section 7.1.1 RSS-Gen, Issue 2, June 2007, Modular Transmitter Approval:... -
Page 11: Potential Interference Sources
Using the radio modules outside of these limitations are prohibited and could void the user’s authority to operate the modules. The user should use one of the register configurations listed below. Anaren provides register setting files for optimal performance and compliance for each of the data rates given in the following at www.anaren.com. -
Page 12: Usa & Canada
Anaren AIR Module, Users Manual 2.4.1. USA & Canada For use in USA and Canada the modules have been approved for use as digitally modulated transmitters, for which they must have a minimum occupied bandwidth (6dB) of 500kHz. In addition the spectral density may not exceed 8dBm/3kHz and the total output power including antenna gain may not exceed 1W. -
Page 13: Electrical Characteristics
3.3. Pin Out The A1101R09A and A1101R09C radio’s share a common pin-out and foot print, that is also shared by Anaren modules using other frequencies. Thus enabling easy changeover from one to another, e.g. if it is desired to change the frequency or antenna scheme or if the adaptive antenna tuning is needed. Below the common footprint are shown. - Page 14 Anaren AIR Module, Users Manual Pin # Pin Name Pin Type Description Do Not Connect. Internal GND connection used during testing, not recommended to connect to main GND. Do Not Connect. Internal RF output connection used during test. Connecting this pin to anything will require recertification for intentional radiators.
- Page 15 Anaren AIR Module, Users Manual Input GDO0 Digital I/O General purpose port (Analog output) GDO2 Digital I/O General purpose port Vdcoup2 Analog Optional decoupling of the modules internal Vdd supply. It is recommended to not connect anything to this pin. In particular noisy environment this pin can be used to further reduce the noise on the modules internal Vdd, please see section 3.4 for...
-
Page 16: Recommended Layout
Anaren AIR Module, Users Manual 3.4. Recommended Layout Figure 5 Recommended PCB layout. 16/18, 8/18/2010:3:57 PM... - Page 17 Anaren AIR Module, Users Manual Figure 6 Mounting the module in a corner Figure 7 Mounting the module along an edge Figure 8 Mounting the module along an edge Figure 9 Mounting the module along an with overhang. This option is not generally edge, with a ground plane cut-out.
-
Page 18: Power Supply Considerations
The A1101R09A and A1101R09C radio modules have integral ferrite bead in the supply line from pin 18 (Vdd) and decoupling capacitance to reduce any noise on the incoming power supply line. This arrangement will take care of most supply voltage noise.
