Installer: Leave these instructions with consumer.
Consumer: Keep these instructions for future reference.
WARNING: If the information in this
manual is not followed exactly, a fire or
explosion may result causing property
damage, personal injury or loss of life.
Do not store or use gasoline or other
flammable vapors and liquids in the vicinity of
this or any other appliance.
WHAT TO DO IF YOU SMELL GAS.
Do not try to light any appliance.
Do not touch any electrical switch; do
not use any phone in your building.
Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
If you cannot reach your gas supplier, call the
fire department.
Installation and service must be performed by a
qualified installer, service agency or the gas
supplier.
WARNING: Do Not Burn Wood or any other
materials in this firepit.
Questions, Problems, Missing Parts? Before
returning to your retailer, call our customer service
department at 1-800-537-8484, 9 a.m. – 5 p.m.
EAST, Monday – Friday.
1
ASSEMBLY INSTRUCTIONS
CSA Model: 98910L
Printed in China
FOR USE WITH 20LB. PROPANE
CYLINDER WITH TYPE 1 CONNRCTION
(NOT SUPPLIED) OR FOR USE WITH
NATURAL GAS AFTER CONVERSION
KIT (SUPPLIED) IS INSTALLED.
WARNING: For Outdoor Use Only
WARNING: Improper installation,
Adjustment alteration, service or
maintenance can cause injury or property damage.
Read the installation, operating
and maintenance instructions thoroughly before
installing or servicing this equipment.
WARNING:
USE FACTORY APPROVED REPLACEMENT
PARTS AND ACCESSORIES ONLY.USE OF
UNAPPROVED PART OR ACCESSORIES CAN
VOID THE WARRANTY ON THIS PRODUCT
AND RESULT IN A HAZARDOUS
CONDITION.PLEASE CONTACT US FOR
INFORMATION REGARDING REPLACEMNT
HOSES, THERMOCOUPLES, ELECTRODES,
IGNITION MODULES, LAVAROCKS, LOGS, ETC.
Advertisement
Table of Contents
Related Manuals for Frontgate 98910L
Summary of Contents for Frontgate 98910L
- Page 1 ASSEMBLY INSTRUCTIONS CSA Model: 98910L Printed in China Installer: Leave these instructions with consumer. Consumer: Keep these instructions for future reference. FOR USE WITH 20LB. PROPANE CYLINDER WITH TYPE 1 CONNRCTION WARNING: If the information in this (NOT SUPPLIED) OR FOR USE WITH...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Important Safety Information Information about Propane Specifications Installation Natural Gas Conversion Lighting Instructions Maintenance Batteries Parts List Warranty... -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION The installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1, or CAN/CGA –B149.2, Propane Installation Code. The appliance and its appliance main gas valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of 1/2 psi (3.5kPa). -
Page 4: Information About Propane
IMPORTANT SAFETY INFORMATION ABOUT PROPANE (LP) GAS A self contained LP-gas cylinder for use with this appliance must have a capacity of 20 lbs. and must be equipped with a Type 1 connector and an OPD (overfill protection device). The LP-gas supply cylinder to be used must be constructed and marked in accordance with the specification for LP-gas cylinders of the U.S. -
Page 5: Installation
INSTALLATION With the help of another person, turn the table base assembly in the upright position. With the help of another person, carefully place the natural stone table top onto the table base. After making any necessary adjustments to the alignment of the natural stone table top and the top connector bracket, use bolts and washers as shown in Fig.3. - Page 6 The logs and burner are lettered. Place the logs as shown in Fig. 5 through 9. Figure 5. Log A Figure 6. Log B Figure 7. Log C Figure 8. Log D Figure 9. Log E...
- Page 7 Remove any lava rock from the ignition well as shown in Fig. 10. Figure 10 Remove any lava rock from the ignition well Lift off the tank door, place the tank in the holder and use the chain to hold the tank. Connect the regulator as shown in Fig.
-
Page 8: Natural Gas Conversion
Figure 12 NATURAL GAS CONVERSION Natural gas conversion must be performed only by natural gas provider or service company. 1. Disconnect the gas hose from the gas valve. See Fig. 13. Figure 13 2. Disconnect the gas tube from the orifice and remove the orifice holder as shown in Fig .14. Figure 14 3. -
Page 9: Lighting Instructions
Figure 15 Figure 16 Apply a solution of soapy water to all connections to check for leaks. If soap bubbles continue to form, the connection has a leak. If a leak is found, close the tank valve and tighten all connections. NEVER USE A FLAME TO CHECK FOR LEAKS. -
Page 10: Maintenance
Figure 19 MAINTENANCE The flames should look like those in Fig. 20. To clean the burner, use a soft brush after the burner and lava rocks have cooled completely. Never use a vacuum cleaner on the lava rocks. It is recommended that the lava rocks be stored indoors during the winter if they will be subjected to freezing temperatures. -
Page 11: Batteries
BATTERIES Make sure the control knob is in the “OFF” position. Unscrew the push button cap on the ignition module located on the control panel to access the battery compartment. The ignition module requires one AAA size battery. See Fig. 21. Figure 21 Parts List (ARS02300) Manufactured by: Agio-USA... - Page 12 90-DAY LIMITED WARRANTY What is Covered Under This Warranty? The item you have purchased is warranted against defects in materials and workmanship for the following parts as outlined below only when unit is installed and operated in accordance with the instructions in this Owner’s Manual and in compliance with local building and fire codes: •...
