Furniture of America CM3577T Assembly Instructions

Hide thumbs Also See for CM3577T:

For more information contact our team: service.ec@foagroup.com

ASSEMBLY RATING

The Assembly Rating is a 5-point system that

shows the degree of effort needed in

assembling a specific product (with 1 being

easy and 5 being difficult). For some

products, two persons are recommended.

EASY

CM3577T

DIFFICULT

Tools Required For Assembly:

Allen Wrench

2 PERSONS RECOMMENDED

Page 1 of 5

(Included)

Rev: 18-07-17

Table of Contents

Do you have a question about the CM3577T and is the answer not in the manual?

Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM3577T ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in assembling a specific product (with 1 being Allen Wrench easy and 5 being difficult).
Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 5...
Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #A x 4pcs #1 x 1pc Hex Nut Ø5/16" Table Top #B x 4pcs #2 x 1pc Nut Ø5/16"...
Page 4 Align top cross bar (#4) to the legs (#3), then secure by using bolts (#D) with washers (#E,F). #A x 4pcs #B x 4pcs #C x 4pcs #D x 4pcs #E x 4pcs #F x 4pcs Attach threaded pins (#C) to the legs (#3), then align bottom cross bar (#5) to the threaded pins (#C) of the legs (#3).
Page 5 Open levers in the bottom of the table (#1), then extend the table (#1). Place table leaf (#2) to the table (#1). OPEN Secure leaf on table by locking the mechanism. LOCK ASSEMBLY IS COMPLETED Page 5 of 5...
