Owner's Manual
LED LCD MONITOR
(LED Monitor*)
* LG LED Monitor applies LCD screen with LED backlights.
Please read this manual carefully before operating your set and retain it for future reference.
32QP880
www.lg.com
Copyright
2021 LG Electronics Inc. All Rights Reserved.

Advertisement

loading

Related Manuals for LG 32QP880-B.AEU

Summary of Contents for LG 32QP880-B.AEU

  • Page 1 Owner’s Manual LED LCD MONITOR (LED Monitor*) * LG LED Monitor applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. 32QP880 www.lg.com Copyright 2021 LG Electronics Inc. All Rights Reserved.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS LICENSE Each model has different licenses. Visit www.lg.com for more information on the license. LICENSE ............2 The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI OPEN SOURCE SOFTWARE NOTICE INFORMATION 3 Licensing Administrator, Inc.

  • Page 3: Open Source Software Notice Information

    Illustrations in this document represent typical procedures, so they may look different from the actual product. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.
  • Page 4 • The power cord provided may differ depending upon the region. Supported Drivers and Software You can download and install the latest version from the LGE website (www.lg.com). • Drivers and Software: Monitor Driver / - Monitor Driver: Optional...
  • Page 5 Moving and Lifting the Monitor How to Use the Joystick Button You can easily control the functions of the monitor by pressing the joystick button or moving it left/right/up/ When moving or lifting the monitor, follow these instructions to prevent the monitor from being scratched or down with your finger.
  • Page 6 Installing on a Table CAUTION • • Lift the monitor and place it on the table in an upright position. Place the monitor at least 100 mm away from Avoid touching the monitor screen as much as possible. the wall to ensure sufficient ventilation. - This may result in damage to the screen or some of the pixels used to create images.
  • Page 7 How to fix a clamp CAUTION • Unplug the power cord before moving or installing the monitor. There is risk of electric shock. After positioning the stand on the table, secure it by turning the handle. • Make sure to use the power cord that is provided in the product package and connect it to a grounded power •...
  • Page 8 ± CAUTION • Stands that are not fully engaged to the table may allow the monitor to wobble or fall over. • Make sure the table is solid and stable enough to fully support installation of the monitor. Tables made of fragile materials such as glass may break.
  • Page 9 Swivel stand Pivot Feature Your monitor mount lets you adjust the monitor viewing angel. The pivot feature allows the monitor to rotate 90 ° counter-clockwise. ±110° Monitor’s head ±150° Table ±75° WARNING • When using the Pivot function, do not rotate the monitor too fast or with excessive force. The table may be scratched by contact with the monitor’...
  • Page 10 Raise the monitor up to the maximum height. Rotate the monitor counter-clockwise as shown in the figure. Adjust the angle of the monitor in the direction of the arrow as shown in the figure. Complete the installation by rotating the monitor 90 ° as shown in the figure.
  • Page 11 Leveling the Screen Adjusting the Stand Height If the screen appears crooked to one side after the product has been placed in position, straighten the angle Make sure to hold and move the monitor with both hands. horizontally as follows. Max.
  • Page 12 Adjusting the Angle Using the Kensington Lock For more information on installation and usage, refer to the Kensington lock owner’ s manual or visit the website at http://www.kensington.com. Adjust the angle of the screen. The angle of the screen can be adjusted forward or backward from -20 ° to 20 ° Connect the monitor to a table using the Kensington security system cable.
  • Page 13 - Wall Mount Plate (Optional): LSW149 NOTE • A non-VESA standard screw may damage the product and cause the monitor to fall. LG Electronics is not liable for any accidents relating to the use of non-standard screws. • The wall mount kit includes the installation guide and all necessary parts.
  • Page 14 • Installing the monitor on the ceiling or on a slanted wall may result in the monitor falling off, which could lead to injury. Use an authorized LG wall mount and contact the local dealer or qualified personnel. • To prevent injury, this apparatus must be securely attached to the wall in accordance with the installation instructions.

  • Page 15: Using The Monitor

    CAUTION HDMI Connection • If you use generic cables not certified by LG, the screen may not display or there may be image noises. Transmits digital video and audio signals from your PC to the monitor. • Do not press the screen for a prolonged time. This may cause image distortion.
  • Page 16 Connecting AV Devices DisplayPort Connection Transmits digital video and audio signals from your PC to the monitor. HDMI Connection NOTE HDMI transmits digital video and audio signals from your AV device to the monitor. • There may be no video or audio output depending on the DP (DisplayPort) version of the PC. •...
  • Page 17 Connecting Peripherals CAUTION • Cautions when using a USB device. USB Device connection - A USB device with an automatic recognition program installed, or that uses its own driver, may not be recognized. The USB port on the product functions as a USB hub. - Some USB devices may not be supported or may not work properly.

  • Page 18: User Settings

    USER SETTINGS Headphones Connection Connect peripherals to the monitor via the headphones port. NOTE NOTE • Peripheral devices are sold separately. • Your monitor’ s OSD (On Screen Display) may differ slightly from that shown in this manual. • Depending on the audio settings of the PC and external device, headphones and speaker functions may be limited.
  • Page 19 Main Menu Features • Main menu disabled: Enables the main menu. • Main menu enabled: Exits the main menu. (Holding down the button more than 5 seconds to turn off the monitor. You can turn off the monitor this way at any time, including when the OSD is on.) •...
  • Page 20 Menu Settings [Quick Settings] [Settings] [Quick Settings] To view the OSD menu, press the joystick button at the bottom of the monitor and then enter the [Settings]. • [Brightness]: Adjusts the brightness of the screen. • Move the joystick up/down and left/right to set the options. [Contrast]: Adjusts the contrast of the screen.
  • Page 21 [Input] [Picture] [Settings] [Input] [Settings] [Picture] [Picture Mode] • [Input List]: Selects the input mode. • [Aspect Ratio]: Adjusts the aspect ratio of the screen. The display may look the same for [Full Wide], [Just [Picture Mode] on SDR (Non HDR) signal Scan] and [Original] options at the recommended resolution (2560 x 1440).
  • Page 22 [Settings] [Picture] [Picture Adjust] [Picture Mode] on HDR signal • [Brightness]: Adjusts the brightness of the screen. • [Custom]: Allows the user to adjust each element. • [Contrast]: Adjusts the contrast of the screen. • [Vivid]: Optimized the screen for HDR vivid colors. •...
  • Page 23 [Settings] [Picture] [Game Adjust] [Settings] [Picture] [Color Adjust] • • [Response Time]: Sets a response time for displayed pictures based on the movement of the picture on the [Gamma]: screen. For a normal environment, it is recommended that you use [Fast]. When there is a lot of motion, it is - [Mode 1], [Mode 2], [Mode 3]: The higher the gamma value, the darker the image becomes.
  • Page 24 [General] [Settings] [Picture] [Picture Reset] • [Do you want to reset your picture settings?] [Settings] [General] - [Yes]: Returns to the default settings. • [Language]: Sets the menu screen to the desired language. - [No]: Cancel the select. • [SMART ENERGY SAVING]: Conserve energy by using luminance compensation algorithm. - [High]: Saves energy using the high-efficiency [SMART ENERGY SAVING] feature.

  • Page 25: Troubleshooting

    TROUBLESHOOTING • [DisplayPort Version]: Set DisplayPort Version to the same version as the connected external device. ([1.4], [1.2]) To use the HDR function, set to [1.4]. • [Buzzer]: This feature lets you set the sound generated from Buzzer when your monitor powers on. •...

  • Page 26: Product Specification

    Have you installed the display driver? - Output: 19.5 V 10.8 A - Be sure to install the display driver from our web site: http://www.lg.com. Environmental Conditions - Make sure to check if the graphics card supports Plug and Play function.
  • Page 27 Dimensions: Monitor Size (Width x Depth x Height) • With Stand (mm): 714.3 x 470 x 640 • Without Stand (mm): 714.3 x 45.7 x 420.1 Weight (Without Packaging) • With Stand (kg): 11.0 • Without Stand (kg): 6.5 Power Sources •...
  • Page 28 Support Mode (Preset Mode, DisplayPort / USB-C) Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1152 x 864 54.347 60.05 1280 x 720 45.00 60.00 1280 x 800 49.702...
  • Page 29 (Preset Mode, HDMI) Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1152 x 864 54.347 60.05 1280 x 720 45.00 60.00 1280 x 800 49.702 59.810 1280 x 1024...
  • Page 30 HDMI Timing (Video) Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) 480p 31.5 720p 1080p 67.5 2160p 67.5...
  • Page 31 The model and serial number of the product are located on the back and on one side of the product. Record them below in case you ever need service. Model Model Serial No. Serial No.
