OPERATION, INSTALLATION AND MAINTENANCE MANUAL
Wall Mounted Radiant Gas Heater
DANGER
!
If you smell gas:
1.
Shut off gas to the appliance.
Extinguish any open flame.
2.
If odor continues, keep away from the
3.
appliance and immediately call your gas
supplier or your fire department
DANGER
!
Do not store or use flammable liquids or vapors in the
vicinity of this appliance.
Manual # P80196016A - Rev.03.11.2021
!
!
Improper Installation, adjustment,
alteration, service, or maintenance can
cause property damage, injury or death.
Read this operating and assembly
instruction thoroughly before installing
.
or serving this heater.
!
!
FOR OUTDOOR AND NON-RESIDENTIAL INDOOR
USE ONLY.
THIS APPLIANCE MUST NOT BE INSTALLED OR
USED IN RESIDENTIAL DOMESTIC INDOORS.
Appliance is to be protected from rain.
TO BE INSTALLED ONLY BY AN AUTHORIZED
PERSON.
TGH34WN (Natural Gas)
TGH34WL (ULPG)
WARNING
WARNING
!
!
Advertisement
Table of Contents
Related Manuals for Thermofilm HEATSTRIP TGH34WN
Summary of Contents for Thermofilm HEATSTRIP TGH34WN
- Page 1 OPERATION, INSTALLATION AND MAINTENANCE MANUAL TGH34WN (Natural Gas) Wall Mounted Radiant Gas Heater TGH34WL (ULPG) DANGER WARNING If you smell gas: Improper Installation, adjustment, Shut off gas to the appliance. alteration, service, or maintenance can Extinguish any open flame. cause property damage, injury or death. If odor continues, keep away from the Read this operating and assembly appliance and immediately call your gas...
-
Page 2: Table Of Contents
4. Quantity of parts needed Important: Use only Thermofilm replacement parts. The use of any part that is not a Thermofilm replacement part can be dangerous and void your product warranty. Keep this Instruction Manual for convenient referral and for part... -
Page 3: Primary Safety Warnings
WARNING WARNING 1. This appliance must be used only for outdoor and 16. Burner and circulation air passageways of the non-residential indoor use. This appliance must not be heater must be kept clean. Frequent cleaning may be installed or used in residential indoor areas.This appliance required as necessary. - Page 4 OUTDOOR AREAS SAFTY APPLIANCE LOCATIONS APPENDIX This appliance is for outdoor and non-residential indoor use only. This appliance must not be installed or used in residential indoor areas. This appliance shall only be used in an above ground open-air situation with natural ventilation, without stagnant areas, where gas leakage and products of combustion are rapidly dispersed by wind and natural convection.
- Page 5 DANGER FREE HELP Grill Information Center: Ÿ Thermofilm Australia Pty Ltd is the expert on NEVER OPERATE THE HEATER WITHOUT this product and trained to help you with: A REGULATOR. Ÿ Assembly Questions Ÿ...
- Page 6 The hose assembly must be replaced prior to the appliance being put into operation if there is evidence of excessive abrasion or wear, or if the hose is damaged. The replacement hose must be purchased from Thermofilm Australia Pty Ltd.
-
Page 7: Product Preview
PRODUCT OVERVIEW SPECIFICATION Intallation Clearances This appliance must only be used in a well ventilated W all Mounted Radiant Gas Heater area. The following clearance should be followed: Model Type W all Mounted Model No TGH34W N TGH34W L The heater should not be installed: - Where heat ignition can cause damage to gas Gas Type ULPG... -
Page 8: Part Diagrams And Lists
Hardware Pack Parts List PART # PART DESCRIPTION PURPOSE OF PART P06033006A Hardware Pack For use in assembly of TGH42W N & TGH42W L S112M05102 Pan Head Screw M5 x 10mm Install Heat Deflector to Head P05501166D Pin Φ6 x 150m m P05501164B R Cotter Pin Install heater to W all Mounting Bracket S020100223 Bolt M6 x 150m m... - Page 9 Parts Diagram...
- Page 10 Parts List PART NO. DESCRIPTION QTY. Protective Guard P03351045D Name Plate P00408001A Thermocouple with wire P05308007B Electrode with wire P02618082A Burner Assembly P02005035D Burner Bracket, Side P033510324 Burner Holder P020110804 Manifold assembly - LPG Y0060898 Manifold assembly - NG Y0060899 Orifice (LP) P06536036A Orifice (NG)
-
Page 11: Installation Instructions
Installation Instructions CAUTION: To assemble this heater, you should obtain assistance from another person when handling the larger, heavier pieces. Please refer to the Page 6 "Dimension and Clearance Detail" before installing this heater. Install Heat Deflector Remove all the packing materials. Install the Heat Deflector to the Head using 3 Pan Head Screws M5x10mm, then tighten all the screws securely. - Page 12 Install Wall Mounting Bracket Install the wall mounting bracket to the wall with appropriate fixings for the material to be attached (Masonry, wood, metal etc.), using 6 appropriate fasteners (not included), then tighten all the screws securely. Install Heater Install the Heater to the Wall Mounting Bracket using 1 Pin Φ6*150mm with 1 R Cotter Pin, using 1 Bolt M6*150mm with 1 Plan Washer M6 and 1 Wing Nut M6.
-
Page 13: Use And Care Instruction
USE AND CARE INSTRUCTIONS Check For Gas Leaks GAS REQUIREMENTS Never test for leaks with an open flame. Prior to first TGH34WN(NG) Model: use, at the beginning of each season, you must check for gas leaks. Follow these three steps: This appliance is for use with Natural Gas only. -
Page 14: Lighting Instruction
LIGHTING INSTRUCTIONS Heater Lighting Instructions Before each use, check all hoses for cracks, nicks, cuts, burns or abrasions. If a hose is damaged in any way, do not use your heater before replacing the hose with an authorized part from the Parts List. Also make sure all gas supply connections are securely tightened. -
Page 15: Troubleshooting
TROUBLE SHOOTING Fault Causes Remedy (a) Air in gas line Purge gas line (b) Blockage in gas line Trace back and clear Pilot or main burner will not light (c) Igniter not sparking Repair lead, electrode, piezo or replace battery (d) Cylinder turned off Turn on (e) Cylinder empty... -
Page 16: Warranty Terms
WARRANTY TERMS Thermofilm warrants to the original owner that HEATSTRIP products will be free from defects in materials and workmanship for a period of 24 months from the date of purchase in accordance with the following warranty terms and conditions.
