Sealey CP20VID Instructions

thank you for purchasing a Sealey product. manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
refer to Wear eye
instructions protection
1. Safety
1.1. GeNeral Safety
maintain the impact driver and battery in good condition. check moving parts alignment on a regular basis.
9
replace or repair damaged parts. use an authorised service agent and recommended parts only. unauthorised parts may be
9
dangerous and will invalidate the warranty.
ensure the impact driver is switched off before installing the battery pack.
9
Keep the impact driver and charger clean for best and safest performance.
9
Remove ill fitting clothing. Remove ties, watches, rings and other loose jewellery and contain long hair.
9
Evaluate your working area before using the Impact Driver; e.g. ceilings, floors and enclosures may contain electrical items or water
9
piping.
ensure battery pack is correctly inserted into the impact driver handle and latched in place before attempting to switch on impact
9
driver.
Secure loose work pieces with a clamp, vice or other adequate holding device.
9
Avoid unintentional starting.
9
Wear approved safety eye protection (standard spectacles are not adequate).
9
maintain correct balance and footing. ensure the floor is not slippery and wear non-skid shoes.
9
Keep direction switch in the locked position until the impact driver is required for use.
9
Keep children and unauthorised persons away from the working area.
9
do Not use the Impact Driver where there are flammable liquids, solids or gases, such as paint solvents, etc.
8
do Not allow children to operate the impact driver.
8
do Not operate the impact driver if any parts are missing as this may cause failure and/or personal injury.
8
do Not hold unsecured work piece in your hand.
8
do Not leave the impact driver operating unattended.
8
do Not carry the impact driver with your finger on the power switch. Keep chuck direction switch in the locked position.
8
do Not use the impact driver for a task it is not designed to perform.
8
do Not operate the impact driver when you are tired or under the influence of alcohol, drugs or intoxicating medication.
8
do Not get the impact driver or battery charger wet or use in damp or wet locations.
8
2. iNtroductioN
the 20V series has been designed to suit users from the DIY enthusiast to the professional. These body only tools offer a one battery fits all
solution with a choice of 20V lithium batteries ranging from 2Ah to 4Ah, meaning costs can be kept down whilst quality remains high. Quality,
stylish, lightweight tools with composite housing and a soft grip making them comfortable and easy to use.
3. SpecificatioN
model no.. ............................................................... cP20Vid
Battery ............................20V 2Ah - 4Ah Li-ion (not included)
drive ........................................................................1/4" Hex.
impact rate ........................................................... 0-3000bpm
no load speed ......................................................0-2200rpm
maximum Torque .........................................................180nm
Battery model no's
2Ah ..................................................................... cP20VBP2
3Ah ...................................................................... cP20VBP3
4Ah ...................................................................... cP20VBP4
mains charger model no ...................................... cP20Vmc
Weight ......................................................................... 1.17kg
noise power .................................................................106dB
noise pressure ...............................................................95dB
Vibration ................................................................. 15.87m/s²
uncertainty ................................................................. 1.5m/s²
© Jack sealey limited
instructions for
impact driver 20v 1/4"hex drive 180Nm
- body oNly
model no:
Wear protective Wear ear
gloves protection
Original Language Version
cp20vid
cP20Vid | issue 1 06/04/18
