  • Page 1 RG-WALL1600-S3100 Next-Generation Firewall Hardware Installation and Reference Guide V1.3...
  • Page 2 This document is provided “as is”. The contents of this document are subject to change without any notice. Please obtain the latest information through the Ruijie Networks website. Ruijie Networks endeavors to ensure content accuracy and will not shoulder any responsibility for losses and damages caused due to content omissions, inaccuracies or errors.
  • Page 3 It is intended for the users who have some experience in installing and maintaining network hardware. At the same time, it is assumed that the users are already familiar with the related terms and concepts. Obtaining Technical Assistance  Ruijie Networks Website: https://www.ruijienetworks.com/  Technical Support Website: https://ruijienetworks.com/support...

  • Page 4: Product Introduction

    Figure 1-1 Appearance of the RG-WALL1600-S3100 Front and Back Panels The RG-WALL1600-S3100's front and back panels are shown in Figure 1-2. See the description for the detailed parts specified by the numbers in the figure. Figure 1-2 Front Panel of the RG-WALL1600-S3100...
  • Page 5 Indicates that the port is up at 100Mbp. Indicates that the port is up at 10Mbp or it is not connected. Console Port Console Console port Figure 1-2 Back Panel of the RG-WALL1600-S3100 Interface Type Description RESET Indicates the reset key, which is used to restore the factory settings.

  • Page 6: Preparation Before Installation

    2.1.4 Static Discharge Damage Prevention Although much has been done in RG-WALL1600-S3100 to prevent static electricity, great damage may be caused to the circuitry and equipment when the static electricity exceeds a certain limit. In the communication network of the RG-WALL1600-S3100, electrostatic induction may come from the following sources: External electric field produced by the high-voltage supply cable, lightning, etc;...
  • Page 7 2.2 Installation Site Requirements RG-WALL1600-S3100 must be used in the room. This series of products are desktop devices, so they can be placed in non-machine-room or mounted into a rack with the support of a tray. To ensure normal operation and a prolonged use life of the equipment, the installation site must meet the following requirements.
  • Page 8 2.2.7 System Grounding Requirements A good grounding system is the basis for the stable and reliable operation of the RG-WALL1600-S3100. It is the key to prevent lightning stroke and resist interference. Please carefully check the grounding conditions on the installation site according to the grounding requirements, and perform grounding properly as needed.
  • Page 9 Air-laid paper, fiber end microscope Meter Multimeter, Errormeter, Optic-power meter RG-WALL1600-S3100 is not shipped with a tool kit. The tool kit is customer-supplied. 2.4 Unpacking Requirements Goods Checklist USB cables, Ethernet cables, power cables, power adapters and optical disk containing tools and Installation Kit documents.

  • Page 10: Product Installation

    3.1 Installation Procedure 3.2 Installation Verification The RG-WALL1600-S3100 is complicated equipment, so you must carefully plan and arrange the installation location, networking mode, power supply, and wiring before installation. Verify the following before installation:  The installation location is of a good air flow.
  • Page 11 Note that the space between neighboring standard installation holes is a little smaller than that between an auxiliary installation hole and its neighboring standard installation hole. When installing a guide rail for the RG-WALL1600-S3100 series, ensure that the plane to carry the chassis should be installed on the plane of delimiters (entire-U delimiter) of the two neighboring RUs, as shown in Figure 3-1.
  • Page 12 Levelly lift the RG-WALL1600-S3100 by two people on both sides, and slowly move it to the front of the cabinet. Levelly lift the RG-WALL1600-S3100 to a position slightly higher than the tray or the slide rail of the cabinet, put the equipment onto the tray or the slide rail, and push it into the cabinet.
  • Page 13 Insert the twisted pair with the RJ45 port into the appropriate port according to the identification on the panel of the linecard. Distinguish the crossover cable and straight-through cable. Connect the cables of each port in sequence. 3.7 Binding the Cables Precautions ...

  • Page 14: System Debugging

    4 System Debugging 4.1 Establishing the Configuration Environment Because this series of products are desktop devices, easy configuration is provided without application of console cables. The user name and password are admin and firewall respectively. Initial Connection Connect one end of a power cable to the power port on the device, and then connect the other end of the cable to a power outlet.
  • Page 15 Figure 4-1 In the Connectivity Note window, type the name of the new connection and click OK. A window appears as shown in Figure 4-2. In the Connect Using field, select the serial port you want to use. Figure 4-2 After selecting the serial port, click OK.
  • Page 16 After setting the serial port parameters, click OK. Now many PCs do not have Console ports and systems do not support hyperterminals. Therefore, Console-to-USB cables and terminal emulators (e.g., SecureCRT) are needed. Parameter Settings Step 1. Connect both ends of the Console-to-USB cable to the Console port of the device and the USB port of the PC properly.
  • Page 17 Click Next, and the following interface will be displayed. Figure 4-6 After configuring the parameters, click Next, and you can configure the session name. Click OK, and the following interface will be displayed. Figure 4-7...
  • Page 18 Click Finish, and the following interface will be displayed. Figure 4-8 4.2 Power-on Startup Checking Before Power-on  The device is properly grounded.  The power cable is correctly connected.  The power supply voltage complies with the requirement of the device. ...
  • Page 19 After power-on, you are recommended to perform the following checks to ensure the normal operation of follow-up configurations.  Check that information appears on the terminal.  Check that the device indicator is normal.

  • Page 20: Monitoring And Maintenance

    5 Monitoring and Maintenance 5.1 RG-WALL1600-S3100 Monitoring Indicators When the RG-WALL1600-S3100 is running, you can monitor the status of each single-board by inspecting the status LED of the appropriate single-board. Figure 5-1 LED Description Status/Port Type Description Green Indicates that the device is on.

  • Page 21: Troubleshooting

    6 Troubleshooting 6.1 General Installation Troubleshooting Flow 6.2 Common Troubleshooting Procedures Fault 1 The system login password is lost. [Fault Description] The login password is forgotten or lost, and so it is not possible to configure the data. [Troubleshooting] Please contact Ruijie technical support. Fault 2 The AC power module does not work.
  • Page 22 The Status LED of each line card is OFF, the Power LED is OFF, and the fan does not work. The LED on the panel of the power module is OFF. The fan does not work. [Troubleshooting] Check if the cables of the cabinet have been correctly connected. Check whether the power cables are tightly connected to the cabinet power sockets and power modules.

  • Page 23: Appendix A Connectors And Connection Media

    7 Appendix A Connectors and Connection Media 1.1000BASE-T/100BASE-TX/10BASE-T Port 1000BASE-T/100BASE-TX/10BASE-T is a port that supports adaptation of three rates, and automatic MDI/MDIX Crossover at these three rates. The 1000BASE-T complies with IEEE 802.3ab, and uses up to 100m of 100-ohm Category-5 or Supper Category-5 UTP or STP cable.

  • Page 24: Appendix B Cabling Recommendations In Installation

    8 Appendix B Cabling Recommendations in Installation When RG-WALL1600-S3100 is installed in standard 19-inch cabinets, the cables are tied in the binding rack on the cabinet by the cabling rack, and top cabling or bottom cabling is adopted according to the actual situation in the equipment room.
  • Page 25 Figure B-2 Bundling up cables (2)  When cables need to bend, you should first bundle them up. However, the buckle cannot be bundled within the bend area. Otherwise, significant stress may be generated in cables, breaking cable cores. As shown in Figure B-3. Figure B-3 Bundling up cables (3) ...
  • Page 26  The hard power cable should be fastened by the terminal connection area to prevent stress.  Do not use self-tapping screws to fasten terminals.  Power cables of the same type and in the same cabling direction should be bundled up into cable bunches, with cables in cable bunches clean and straight.
