Model No. WLTL49200
Serial No.
Write the serial number in the
space above for future reference.
Serial
Number
Decal
QUESTIONS?
As a manufacturer, we are
committed to providing complete
customer satisfaction. If you have
questions, or if there are missing
parts, we will guarantee complete
satisfaction through direct assis-
tance from our factory.
TO AVOID UNNECESSARY DE-
LAYS, PLEASE CALL DIRECT TO
OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our customer hot line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.ÐFri., 6 a.m.Ð6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
¨
USER'S MANUAL
Visit our website at
www.weslo.com
new products, prizes,
fitness tips, and much more!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Weslo WLTL49200
Summary of Contents for Weslo WLTL49200
- Page 1 ¨ Model No. WLTL49200 Serial No. Write the serial number in the space above for future reference. Serial Number Decal QUESTIONS? As a manufacturer, we are committed to providing complete customer satisfaction. If you have questions, or if there are missing...
-
Page 2: Table Of Contents
450 joules. The surge suppressor must be electrically rated for 120 volts AC and 15 amps. To purchase a surge suppressor, see your local WESLO dealer or call 1-800-999- 3756 and order part number 146148. 12. Keep the power cord and the surge suppres- sor away from heated surfaces. - Page 3 14. Never start the treadmill while you are stand- ing on the walking belt. Always hold the handrails while using the treadmill. 15. Do not perform exercises with the hand weights at speeds faster than a walk. Using weights and not holding the handrails may compromise your ability to maintain your balance.
-
Page 4: Before You Begin
The model number of the treadmill is WLTL49200. The serial number can be found on a decal attached to the tread- mill (see the front cover of this manual for the location). -
Page 5: Assembly
ASSEMBLY Assembly requires two people. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires the included allen wrench and your own phillips screwdriver ters Note: The underside of the treadmill walking belt is coated with high-performance lubricant. - Page 6 3. Attach the Weight Rack (90) to the Uprights (11) with the two Rack Washers (41) and Rack Bolts (89). Note: If nec- essary, spread the Uprights apart (11) to align the holes in the Weight Rack with the holes in the Upright. Insert the Right Handrail (88) into the upper end of the right Upright (11), with the lower end of the Handrail to the side of the Extension Leg (34) as shown.
-
Page 7: To Plug In The Power Cord
(see drawing 1 at the right). To purchase a surge suppressor, see your local WESLO dealer or call toll-free 1-800-999-3756 and order part number 146148. Use only a single-outlet surge suppressor that is UL 1449 listed as a transient voltage surge suppressor (TVSS). -
Page 8: Battery Installation
DIAGRAM OF THE CONSOLE Speed Control CAUTION: Before operating the console, read the following precautions. ¥ Do not stand on the walking belt when turning on the power. ¥ Always wear the clip (see the drawing above) while using the treadmill. When the key is re- moved from the console, the walking belt will stop. - Page 9 Insert the key fully into the power switch. Note: Inserting the key will not turn on the dis- plays. The displays will turn on when the ON/RESET button is pressed or when the walking belt is started. If you just installed batter- ies, the displays will already be on.
-
Page 10: How To Fold And Move The Treadmill
HOW TO USE THE HAND WEIGHTS To exercise your upper body as you walk on the treadmill, hold the 1-pound weights at your sides or press the weights above your head. To increase the intensity of your exercise, use the 2-pound or 3-pound weights. The hand weights can be stored on the weight rack. -
Page 11: How To Move The Treadmill
HOW TO MOVE THE TREADMILL Before moving the treadmill, convert the treadmill to the stor- age position as described above. Make sure that the stor- age latch is closed fully over the catch. 1. Hold the upper ends of the handrails. Place one foot on the base as shown. -
Page 12: Troubleshooting
MAINTENANCE AND TROUBLE-SHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please call our Customer Service Department toll- free at 1-800-999-3756, Monday through Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). PROBLEM: The power does not turn on a. - Page 13 PROBLEM: The console, incline, or treadmill does not function properly a. Remove the key and unplug the power cord. Check to make sure the Wires (21) are fully inserted into the two connectors in the Console Base (46). Make sure the Cable Tie is secure. PROBLEM: The walking belt slows when walked on a.
-
Page 14: Conditioning Guidelines
CONDITIONING GUIDELINES WARNING: Before beginning this or any exercise program, consult your physician. This is especially important for in- dividuals over the age of 35 or individuals with pre-existing health problems. The pulse sensor is not a medical device. Various factors, including the user's move- ment, may affect the accuracy of heart rate readings. -
Page 15: Exercise Frequency
EXERCISE FREQUENCY To maintain or improve your condition, complete three workouts each week, with at least one day of rest be- SUGGESTED STRETCHES The correct form for several basic stretches is described below. Move slowly as you stretchÑnever bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. - Page 16 PART LISTÑModel No. WLTL49200 Key No. Qty. Description Left Handrail Key/Clip Incline Leg Pivot Bolt Battery Cover Left Foot Rail Lift Motor Rear Roller Speed Potentiometer Speed Control Knob Console Assembly Upright Motor Belt Small Screw Storage Latch Frame Spacer (Left) 8Ó...
-
Page 18: Ordering Replacement Parts
¥ The KEY NUMBER and DESCRIPTION of the desired part(s) (see the PART LIST and the EXPLODED DRAW- ING in the center of this manual). WESLO is a registered trademark of ICON Health & Fitness, Inc. ICON Health & Fitness, Inc. (ICON), warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of ninety (90) days from the date of pur- chase.
