OWNER'S MANUAL
WASHING
MACHINE
Please read this manual carefully before operating
your set and retain it for future reference
T65SJ#*Z
T70SJ#*Z
T80SJ#*Z
# : FS, SF, SS, BK, DR, BW
* : 1, 2, 3
MFL68486515
Rev.02_280120
Copyright © 2019-2020 LG Electronics Inc. All Rights Reserved.
www.lg.com

Advertisement

Table of Contents
loading

Related Manuals for LG T70SJBK1Z

Summary of Contents for LG T70SJBK1Z

  • Page 1 Please read this manual carefully before operating your set and retain it for future reference T65SJ#*Z T70SJ#*Z T80SJ#*Z # : FS, SF, SS, BK, DR, BW * : 1, 2, 3 www.lg.com MFL68486515 Rev.02_280120 Copyright © 2019-2020 LG Electronics Inc. All Rights Reserved.

  • Page 2: Read This Manual

    ontents READ THIS MANUAL Inside you will find many helpful hints on how to use and maintain your washer properly. Just a little preventive care on your part can save you a great deal of time and money over the life of your washer. You will find many answers to common problems in the Troubleshooting section.

  • Page 3: Smart Diagnosis

    roduct Features Washer doesn't operate while the lid is opened. If the lid is opened during the wash, rinse or spin cycles, the operation stops for safety. Pre Wash Normal  The purpose of this program is to deliver best Wash Performance by adding extra 8 minutes of uniquely designed washing pattern before the main wash cycle.

  • Page 4: Afety Information

    afety Information Read carefully and thoroughly go through this booklet as it contains important safety information that will protect the user from unexpected dangers and prevent potential damages to the product. This booklet is divided into 2 parts : Warning and Caution. : This is a warning sign specifying user’s applications which might be dangerous.
  • Page 5 j{kk tkudkjh bl iq L rd dks /;kuiw o Z d vkS j iw . kZ : i ls i<+ s a D;ks a f d bles a viz R ;kf'kr [krjks a ls mi;ks x drkZ dh j{kk vkS j mRikn ds fy, vla H kkfor uq d lku dks jks d us ds fy, egRoiw . kZ tkudkjh nh xbZ gS A ;g iq L rd Hkkxks a es a foHkkftr dh xbZ gS % ps r kouh vkS j lko/kkuhA ;g ,d ps r kouh dk la d s r gS ftles a mi;ks x drkZ dh dk;Z i )fr;k¡...
  • Page 6 afety Information WARNING YOUR LAUNDRY AREA • Keep the area underneath and around your appliances free of combustible materials such as lint, paper, rags, chemical, etc. Operating with such materials around the machine may trigger explosion or fire. • Close supervision is necessary if this appliance is used by or near children. Do not allow children to play on, with, or inside this or any other appliance.
  • Page 7 j{kk tkudkjh vkidk ps r kouh diM+ k /kks u s • vius midj.kks a ds uhps vkS j vklikl ds {ks = k dks Toyu'kkhy lkexz h tS l s fya V ] dkxt] diM+ s dk {ks = k ,oa jlk;u bR;kfn ls eq D r j[ks a A e'khu ds vklikl bl rjg dh lkexz h ds lkFk la p kyu djus ij foLQks V gks ldrk gS ;k vkx yx ldrh gS A...
  • Page 10 ” Parts can be different according to the model. Please do not match this figure with model as it may be different from your model .These are schematic diagrams only. Due to continuous improvements at LG, specification of washing machine are subject to change without prior notice.
  • Page 11 unction Information Our machine provides various washing methods which suits various conditions and types of laundry. Different types of laundry washing Normal Wash this Program for everyday washing e.g. sheets, towels, T-shirts . (refer to page 20) Turbowash Use this program to save time for washing regular laundry. (refer to page 20) (* Turbowash logic is applicable on water level 1 to 7, higher levels follow Normal Wash Course pattern.) Strong (Jeans) Wash Use this Program for heavily soiled durable garments e.g.
  • Page 12 Use nylon nets for long, DELICATE items. For laundry with long strings or long length , a net will prevent tangling during washing. Fasten zippers, hook, and strings to make sure that these items don't snag on other clothes. Nylon net is not supplied by LG.
  • Page 13 se of Water, Detergent, Bleach and Softener se of Water, Detergent, Bleach and Softener Using Water Using Water Amount of WATER LEVEL Amount of WATER LEVEL • This machine detects the quantity of laundry • automatically, then set the WATER LEVEL •...
  • Page 14 se of Water, Detergent, Bleach and Softener se of Water, Detergent, Bleach and Softener Water Level and Amount of Detergent Water Amount Amount Level of Water of laundry Concentrated detergent: 20g per 30 liters of water.  62 l Less than Regular synthetic detergent: 30g per 30 liters of water.
  • Page 15 se of Water, Detergent, Bleach and Softener Using Fabric Softener • Dilute fabric softener with water. Softener dispenser( Undiluted fabric softener may result in spots that look like oil stains. • Measure and add the recommended amount of fabric softener into the compartment marked with this symbol( Follow manufacturer’s direction.
  • Page 16 pecial Guide for Stain Removal WARNING Do not use or mix liquid chlorine bleach with other household chemicals such as toilet cleaners, rust removers, acid or products containing ammonia. These mixtures can produce dangerous fumes which can cause serious injury or death. To reduce the risk of fire or serious injury to persons or property, comply with the basic warnings listed below: Read and comply with all instructions on stain removal products.
  • Page 17 pecial Guide for Stain Removal Stain Removal STAIN TREATMENT Adhesive tape, chewing gum, Apply ice. Scrape off excess. Place stain face down on paper towels. Saturate with prewash stain remover or rubber cement nonflammable dry cleaning fluid. Use product containing enzymes to pretreat or soak stains. Baby formula, dairy products, egg Beverages (coffee, tea, soda, juice, Pretreat stain.
  • Page 18 If you want to use the washing machine without alarm signal sounds, pressing Beeper button allow you to select : High High respectively. Default setting is High Use this feature based on soil/dirt level of the cloth. Select Soil Level for low, medium or high soil/dirt level respectively.
  • Page 19 SMART DIAGNOSIS Function Display It marks the place to put the phone to receive signal when a problem occurs. (refer to page 38) To cancel delay time, turn the power switch off or press Start/Pause button follows : & then keep pressing delay button Program 1: until Delay LED turn Off.
  • Page 20 Normal Wash Use this program for washing normal clothes, this mode Normal automatically selects the most program is appropriate conditions and set by default completes the sequence in one operation. The built-in sensor detects the size of the load and ideal wash power &...
  • Page 21 - If the water is already in the tub, or putting wet laundry into the tub before starting will increase the WATER LEVEL. Wash tub rotates twice to Open the lid and add When the wash program detect the laundry load. appropriate quantity of ends, the buzzer will ring - Changes to WATER LEVEL is possible,...

  • Page 24: Tub Clean

    UB CLEAN If scrud is allowed to build-up in the machine it can result in stains on your clothes or unpleasant smell in your washer. Scrud is the wax build-up that can occur within any washer when the fabric softener comes into contact with detergent, and according to particular degree of dirtiness or quality of water to be used, in these case, use this program to clean inner tub and outer tub.
  • Page 25 Press the POWER button to turn power on. Press Spin for 3 seconds to select Air Dry. Other function cannot be selected during Air Dry. Automatically set to 30 minutes upon selection. Press Spin button again to select duration (30min 1hr 1:30hr 2hr) To deselect Air Dry press power button.
  • Page 26 • Press the WASH button to • Press the RINSE button to When you want to only select the desired timing. select the desired no. of drain, press SPIN button. rinse cycles. • Press the RINSE button to Then press START/PAUSE select the desired no.
  • Page 27 DELAY START (RESERVATION) Wash is used to delay the finishing time of the operation. The hours to be delayed can be set by the user accordingly. The time on the display is the finishing time, not the start time. Select the program for laundry on the Control panel. This program will not work in GENTLE (WOOL/SAREE) and TUB CLEAN Program.
  • Page 28 Press and hold Beeper and Rinse Button simultaneously for 3 seconds. • The child lock is set, it will not be released automatically even if the cycle is terminated. Thus, you should turn power on washing machine • and then terminate function by pressing "Beeper and Rinse"...
  • Page 29 lacing, Leveling and Installation Improper installation of the washer may cause noise and malfunctioning. The ventilating openings in the base area must not be obstructed by carpeting when the washing machine is Note : installed on a carpeted floor. Install the washing machine on a level and firm Installation area surface.
  • Page 30 onnecting Hose Water Supply Hose Normal Type (Normal tap without thread & one touch type inlet hose.) Separate Middle connector from Water Supply Hose Separate Middle connector from the Water Middle Fixed Sticker connector Supply Hose by pulling the Pressing Rod and the Pressing Handle Pressing Handle that is attached to the Water Pressing Rod...

  • Page 31: How To Connect The Drain Hose

    condition. Drain Hose How to connect the drain hose Insert the drain hose to the connect- Press the hose clip. ing area at the body. While pressing, push the hose towards the body. Release the hose clip after pushing the hose.
  • Page 32 lko/kkuh...
  • Page 33 To Clean the Magic Filter If the magic filter is damaged, purchase a new one from LG Authorised Service Center. # Product feature may vary according to different models. Refer page 39 for model wise features for your purchased model.

  • Page 34: Leaning And Maintenance

    leaning and Maintenance When there is a fear of freezing • Close the water taps and remove the Water Supply Hose. • Remove the water which remains in the water supply. • Lower the drain hose and drain the water in the bowl and the drain hose by spinning. If frozen °...
  • Page 35 ] ls djok,a A India Pvt. Ltd. Merely as a facilitator. vf/kd tkudkjh ds fy, ns [ ks a os c lkbV % http://www.lg.com/in For more detailed information , please visit : http://www.lg.com/in (LG WhatsApp No.)
  • Page 36 ommon washing problems Many washing problems involve poor soil & stain removal, residues of lint and scum, and fabric damage. For satisfactory washing results, follow these instructions. WASH PROBLEM Problems Solutions & Preventive Measures Possible Causes • Not enough Detergent •...
  • Page 37 Door(Lid) Open - Close the lid properly. - Press Start button to remove dE error. - Press Start button again to resume the machine operation. • Please call your nearest LG Electronics Internal sensing service center for help. failure Power failure...
  • Page 38 Diagnosis Only use this feature when instructed to do so by the LG Customer Service Call Center. The transmission sound is similar to a fax machine, and so has no meaning except to the call center. Press and hold the Water level button for three seconds, while holding the phone mouthpiece to the icon or POWER button.
  • Page 39 eatures & Specifications...
  • Page 40 MFL68486515 A-24/6, Mohan Cooperative Industrial Estate, Mathura Road, New Delhi-110044 CIN NO. U32107DL1997PTC220109...
