Everflourish RF101T1L Instruction Manual

Item no. Transmitter RF101T1L

Functions

A.
1. Learning code system
2. Manual button on each receiver for ON/OFFcontrol.
B.

Diagram

No. Description
1 ON OFF
C.

Instruction

1. Pairing
a) Plug the receiver into an outlet, the LED indicator flashes (under pairing mode), press the ON or
OFF button on the transmitter.
If the LED is not under pairing mode, press the manual button over 3 seconds to turn the
receiver into pairing mode.
b) LED stop flashing, pairing success.
c) Pairing mode can last for 15 seconds, if no operation on transmitter after 15 seconds, the
receiver will exist the pairing mode, LED stops flashing.
2. Control
a) Press ON/OFF button on the transmitter to switch the related channel's receiver ON/OFF
D.
Caution
1. Do follow product parameter for functionally use
2. Product is non-waterproof, require using in dry environment
3. When the battery of transmitter is in low voltage, it influences product transmitting distance
E.

Specification

Receiver battery: 125VAC, 60Hz
Transmitter battery: CR2032L DC3V
Frequency: 433.92 MHz
Distance: Up to 30 meters in open area
Instruction Manual
Remote control
1
Function
Switch ON/OFF the paired receiver
