  • Page 1 LCD Display Models: DV65UM...

  • Page 2: Table Of Contents

    Contents Document History ..........................5 Warnings ............................. 6 Protection against Image Retention ..................... 6 Exemptions ..........................6 Important Safety Instructions, Maintenance & Recommended Use..........7 Safety Precautions ........................7 Installation Cautions ........................7 Use ............................... 8 Cleaning ............................8 Product Features ..........................
  • Page 3 Wake Up from Sleep ........................35 Default Settings .......................... 36 Supported Timings ........................... 37 Specifications ............................ 40 Troubleshooting ..........................42 External Control ..........................43 Compliance ............................55 Dimensions ............................56 Appendix I: Moving and Carrying Information ................57 Appendix II: Installing a Wall Mount .................... 58 Appendix III: Wall Mount Safety Notes ..................
  • Page 4 NOTES...

  • Page 5: Document History

    Document History Title: DIAMONDVIEW DV65UM Display User Manual Issue Date: 08 December 2021 Revision: Ver.02 Version Update Remark First issue. Ver.01 09 April 2020 MEUS Changes Ver.02 08 December 2021...

  • Page 6: Warnings

    Warnings Protection against Image Retention Operation usage to protect against image retention • Operating time: 18 of 24 hours a day. Moving images or video type signal are OK to use 24 hours a • Liquid Crystal refresh time is required. Cycling the display type between 5 minutes’ for static display •...

  • Page 7: Important Safety Instructions, Maintenance & Recommended Use

    Important Safety Instructions, Maintenance & Recommended Use. Before using this display, please read this user manual thoroughly to help protect against property damage and to ensure your personal safety and the safety of others. • For your safety, be sure to observe the warnings located in this manual. •...

  • Page 8: Use

    If you encounter a problem during installation, please contact your dealer for assistance. Don’t repair or open the display, these actions will void the unit’s warranty Using extension cords (not recommended) • • Don’t use any kind of cleaning liquid on the display. For cleaning, only use a damp Sham cloth. •...

  • Page 9: Product Features

    Product Features This display supports 3840x2160 or 4K UHD resolution and can display true 1.07 billion colors. It supports a full range of interface types, including: DisplayPort 1.2 x2 / HDMI 1.4 x2 / HDMI 2.0 x2 / VGA / PC audio in / IR extender / OPS.

  • Page 10: Packing List

    Packing List...

  • Page 11: Accessories

    Accessories Power Cord (US black, right angle) x1 HDMI Cable x1 OSD Remote Control x1 IR Extender x1 (AAA) batteries x2 Included...

  • Page 12: Product Overview

    Product Overview When operating the display, ambient room conditions should not exceed the following: Operating temperature: 0˚C to 40˚C (0˚F to 104˚F)  Humidity: 35~85% RH  Main Power Switch and AC Inlet Plug the power cord into the AC socket on the side of the display. Locate the Main Power switch directly below the AC socket and press “-”...

  • Page 13: Power Switches

    Power Switches • The main power switch located directly below the AC power inlet. Please refer to Main Power Switch and AC Inlet on page 13. The on/off switch is the top button on the display keypad. • The on/off switch is also located on the remote control. •...

  • Page 14: Operating The Display

    Operating the Display Setting up the Display Step 1: Plug in the power cable and turn on the AC power switch (without turning on the signal source device(s)). “I” is power on “O” is power off Step 2: Plug in the signal source cables. Step 3: Press the power key on the display’s keypad or the power key on the remote control to turn on the display.

  • Page 15: Turning Display On And Off

    Turning Display On and Off With the power on, press the power button on the remote control or keypad to put the display into standby mode. To turn off power completely, turn the AC switch to “O” or disconnect the AC power cord from the power outlet.

  • Page 16: Reading The Status Led

    Reading the Status LED The LED indicator light is located on the rear of the display near the keypad. The following table explains what the different colors and blink patterns mean. LED Indicator Condition Green Normal operation Blinking Orange No signal Power Saving Orange Power off...

  • Page 17: Using The Remote Control

    Using the Remote Control Customer Data Function Code Code 40AF 04FB INFO 40AF 1CE3 POWER 40AF 07F8 40AF 08F7 DISPLAYPORT1 40AF 09F6 HDMI1 40AF 0AF5 ──── 40AF 0BF4 DISPLAYPORT2 40AF 0CF3 HDMI2 40AF 1AE5 PIP POSITION 40AF 15EA 40AF 10EF HDMI3 40AF 11EE...

  • Page 18: Locking The Osd (On-Screen Display)

    Locking the OSD (On-screen Display) To lock the remote control and keypad (to prevent tampering display settings): Press Enter, Enter, Exit, Exit, Enter and Exit on the remote control or the keypad. To unlock the remote control and keypad: Press Enter, Enter, Exit, Exit, Enter and Exit on the controller by sequence again and all keys will be unlocked.

  • Page 19: Changing The Remote Control Battery

    Changing the Remote Control Battery Remove the battery cover Slide back and remove the battery cover in the direction of the arrow. Insert the batteries Align and insert two AAA batteries according to their plus and minus ports (as indicated in the remote control). Close the battery cover Replace the battery cover in the direction of the arrow and snap it back into place.

  • Page 20: Using The Menus

    Using the Menus Navigating through the Menu System 1. With the power on, press MENU. The Image Settings menu will display. 2. Within the menu, use ,,, , and ENTER to navigate through the menus and adjust options. 3. Press MENU to return to the previous menu. To exit the menu system, press EXIT. Input Menu Save and recall up to four configurations of single or multi-source layouts.
  • Page 21 Source 3 Select the third source Options: DisplayPort1, DisplayPort2, HDMI1, HDMI2, HDMI3, HDMI4, VGA, OPS Note: This function is only available when Multi-Source Views is set to Quad View. If HDMI4 was selected as another source, OPS cannot be selected. If OPS was selected as another source, HDMI4 cannot be selected.

  • Page 22: Picture Menu

    Picture Menu This menu is used for making common video adjustments. Aspect Ratio Adjust the aspect ratio of the screen. The first selection is for the main source, and the second selection is for sources 2-4. Options: Main: Full Screen, Letterbox, 4:3, Native PiP/Dual View: Full Screen ;...
  • Page 23 Saturation Adjusts the brilliance and brightness (only Video Mode). Press  or , select the desired level, and then press ENTER. Range: 0~100; Default: 50 Backlight Increase or decrease the intensity of the LCD backlight. Press  or , select the desired level, and then press ENTER.

  • Page 24: Picture Menu- Rgb Adjust Submenu (Color Temp = User)

    Picture Menu– RGB Adjust Submenu (Color Temp = User) Gamma Select gamma Options: Off, 2.2 Default: 2.2 Temperature Select color temperature Options: User, 5000K, 6500K, 7500K, 9300K Default: 9300K Red Gain Adjust the amount of red in bright content Range: 0~100 Default: 50 Green Gain Adjust the amount of green in bright content...

  • Page 25: Audio Menu

    Audio Menu This menu is used for adjusting volume settings. Volume Adjust the sound. Press  or , select the desired level, and then press ENTER. Range: 0~100 Default: 50 Treble Adjust the sound in high tones (treble). Press  or , select the desired level, and then press ENTER.

  • Page 26: Osd Settings Menu

    OSD Settings Menu This menu is used to make initial set-up adjustments to the OSD (On-Screen Display) menu and other on- screen messages. OSD H Position Adjust the horizontal position of the OSD menu. Press  or  to select the desired level, and then press ENTER.

  • Page 27: Setup Menu

    Setup Menu Auto Adjust Force the display to reacquire and lock to the input signal (VGA source only). This is useful when the signal quality is marginal. Options: No, Yes Default: No H Position Adjust the horizontal position of the image (VGA source only). Press or to select the desired level.

  • Page 28: Real Time Clock Submenu

    Real Time Clock Submenu This menu is used to set the internal clock of the display, and to power on and power off the display at preset times if desired Current Time Set the year, month, day, and time of day Options: User Mode, Workday Mode, Everyday Mode Real Time Clock –...

  • Page 29: Real Time Clock - Workday Mode

    Real Time Clock – Workday Mode Workday Mode Select the power on/off time for Monday-Friday, Saturday and Sunday Options: Disable, Enable Use the arrow keys to specify the on and off times Real Time Clock –Everyday Mode Everyday Mode Select the power on/off time for all days of the week Options: Disable, Enable Use the arrow keys to specify the on and off times...

  • Page 30: Adv. Setup Menu

    Adv. Setup Menu Smart light control Enable dynamic contrast (DCR) or ambient light sensor Options: Off, DCR, Light Sensor; Default: Off IRFM Creates slight frame motion to help avoid image retention. Options: On Default: Off Wake Up from Sleep Select a source to wake up the display from sleep mode Options: VGA Only, Digital, RS232, Ethernet, Never Sleep Default: VGA Only DP1 Ver.

  • Page 31: Communication Menu

    Communication Menu This menu configures the display’s RS-232 and Ethernet communication ports. Baud Rate Options: 115200, 38400, 19200, 9600 Default: 115200 Enable Network Enable the display’s built-in Ethernet port Options: Off, On Default: Off IP Address Settings Enable Dynamic IP mode or set the static IP address of the display’s Ethernet port See next page for more settings Power Status Alert Enable an automatic alert when the display is powered down...

  • Page 32: Assigning An Ip Address To The Display

    Assigning an IP Address to the Display To assign an IP address to your display, access the IP Address Settings Menu in the Communication Menu. Consult your system IT administrator if you do not know how to configure the parameters shown in the menu. The default settings are shown below.

  • Page 33: Unlocking And Enabling The Lan Port

    Unlocking and Enabling the LAN Port Ethernet Board Settings – Web service can configure the device by opening the browser and connecting via Web GUI directly. 1. Login – Use Web browser to configure the Ethernet board and connect via the IP of the display. Once you connect the Login window will popup.
  • Page 34 4. SMTP Setup and Configuration: a. SMTP Setup allows you to configure the SMTP Server address, SMTP Login Information, Mail to and from address b. Setup and Configure Email Alert of Power Status, Source Status and Signal Lost Status c. Test of Email alerts and communications...

  • Page 35: Information Menu

    Information Menu This read-only menu provides information on the active sources and the latest firmware version. Wake Up from Sleep By default, the display will enter power saving (Sleep Mode) if no signal is received for 5 minutes. Normally, the RS-232, DisplayPort and HDMI inputs are inactive in Sleep Mode, to save power. To change the behavior of Sleep Mode, change the “Wake up from Sleep”...

  • Page 36: Default Settings

    Default Settings Menu Parameter Default Settings Power switch Input Main Source HDMI1 Auto Scan Multi-Source Views Picture Aspect Ratio Full Screen Scheme User Brightness Contrast Sharpness Saturation Backlight Gamma Color Temp. 9300K Red Gain Green Gain Blue Gain Red Offset Green Offset Blue Offset RGB Range...

  • Page 37: Supported Timings

    Supported Timings Compatible Video Sources Frame Line Pixel Signal Type Resolution Rate Rate Rate References (Hz) (kHz) (MHz) 640x480 59.940 31.469 25.175 x VESA DMT, CEA-861-F Format 1 640x480 72.809 37.861 31.500 x VESA DMT 640x480 75.000 37.500 31.500 x VESA DMT 640x480 85.008 43.269 36.000 x VESA DMT...
  • Page 38 Compatible Video Sources Frame Line Pixel Signal Type Resolution Rate Rate Rate References (Hz) (kHz) (MHz) 1920x1080 59.950 66.587 138.500 x VESA CVT-R 1920x1200 49.932 61.816 158.250 x VESA CVT 1920x1200 59.950 74.038 154.000 x VESA CVT-R 1680x1050 49.974 54.121 119.500 x VESA CVT 1680x1050 59.954 65.290 146.250...
  • Page 39 Compatible Video Sources Frame Line Pixel Signal Type Resolution Rate Rate Rate References (Hz) (kHz) (MHz) 4096x2160 56.250 297.000 CEA-861-F Format 99 4096x2160 67.500 297.000 CEA-861-F Format 100...

  • Page 40: Specifications

    Specifications Item Specification Unit Resolution 3840x2160 Backlight Illumination Direct Response time (typ.) Viewing Angle (typ.) 178 / 178 LCD Panel Pixel Pitch (Sub Pixel) 0.124(H) x 0.372(V) Color Saturation (typ.) NTSC Aspect Ratio 16 : 9 Brightness (typ.) cd/m Optical* Contrast Ratio (typ.) 5000:1 HDMI 1.4 x2 (4K/ 30Hz)
  • Page 41 Item Specification Unit Dimension (W x H x D) 1454.1 x 829.1 x 92.0 (Without handle) Active Area 1628.48(H) x 803.52(V) (65” diagonal) Size and Weight Bezel Width (L/R/T/B) 10.9 / 10.9 / 10.9 / 10.9 Objectives Net weight 32.7 Gross weight 43.25 Storage temperature...

  • Page 42: Troubleshooting

    Troubleshooting Before calling service personnel, please check the following chart for a possible cause to the trouble you are experiencing. Operating The Display Perform the adjustments according to on page 16  If the problem you are experiencing isn’t described below or you can’t correct the problem, stop using ...

  • Page 43: External Control

    External Control RS232 control is not necessary for operation but is a convenient way to control displays from a computer at a distance. Most functions that can be done with the remote, can also be done with RS232 commands. Plus, you can send inquiries to the displays and find out the current settings and values.
  • Page 44 Request LCD panel serial 07 01 00 53 45 52 S(0)…S(12) 08 07 01 01 53 45 52 08 number. S(0) …S(12) = the serial number in ASCII Request LCD panel firmware 07 01 00 47 56 45 S(0)…S(5) 08 07 01 01 47 56 45 08 version.
  • Page 45 Value Reply Main Item Control Item CMD Type Content CMD (HEX) Remark (HEX) (HEX) Game Cinema Vivid User 6500K 43 4F 54 Color 9300K Temperature 5000K 7500K Off (Gamma) 47 41 43 Gamma 2.2 (Gamma) 55 53 52 00~64 00~64 Red Gain (0~100) 00~64 00~64...
  • Page 46 Value Reply Main Item Control Item CMD Type Content CMD (HEX) Remark (HEX) (HEX) Everyday Mode 54 4D 53 Timer Mode Workday Mode User Mode In User Mode: Set bit0 to 1: Sunday Enable Set bit1 to 1: Monday Enable Set bit2 to 1: Tuesday Enable Set bit3 to 1:...
  • Page 47 Value Reply Main Item Control Item CMD Type Content CMD (HEX) Remark (HEX) (HEX) 53 4E 48 00~17 00~17 Sunday On Hour 53 4E 4D 00~3B 00~3B Sunday On Minute Sunday 53 46 48 00~17 00~17 Sunday Off Hour 53 46 4D 00~3B 00~3B Sunday Off Minute...
  • Page 48 Value Reply Main Item Control Item CMD Type Content CMD (HEX) Remark (HEX) (HEX) 54 46 48 00~17 00~17 Saturday Off Hour 54 46 4D 00~3B 00~3B Saturday Off Minute 56 4F 4C Volume 00~64 00~64 volume 42 41 53 Bass 00~0C 00~0C...
  • Page 49 Value Reply Main Item Control Item CMD Type Content CMD (HEX) Remark (HEX) (HEX) 1080P 45 48 32 HDMI2 4K30Hz 1080P 45 48 33 HDMI3 4K30Hz 4K60Hz 1080P 45 48 34 HDMI4 4K30Hz 4K60Hz 1080P 4K30Hz 45 48 35 4K60Hz 1080P 45 44 31 DisplayPort1...
  • Page 50 Value Reply Main Item Control Item CMD Type Content CMD (HEX) Remark (HEX) (HEX) to MIN) Select the input source (refer to (refer to MIN) of sub window 3 (refer 50 49 50 MIN) to MIN) PIP Position Bottom-left PIP Position Bottom- Right PIP position 50 50 4F...
  • Page 51 Value Reply Main Item Control Item CMD Type Content CMD (HEX) Remark (HEX) (HEX) 49 52 46 IRFM Smart Light 53 4C 43 Control 4C 45 44 Power LED DP 1.1 DisplayPort 44 50 4D Version DP 1.2 Disable OPS power down check OPS Power 4F 50 43...
  • Page 52 Value Reply Main Item Control Item CMD Type Content CMD (HEX) Remark (HEX) (HEX) P-SOURCE Key PIP Key P-POSITION Key SWAP Key SCALING Key FREEZE Key MUTE Key BRIGHT Key CONTRAST Key AUTO Key VOLUME+ Key VOLUME- Key HDMI3 Key HDMI4 Key OPS Key DISPLAYPORT2 Key...
  • Page 53 Value Reply Main Item Control Item CMD Type Content CMD (HEX) Remark (HEX) (HEX) Enable Load default settings 4C 44 53 Default (About 15 seconds.) 50 53 41 Off (Power Status Alert) On (Power Status Alert) Off (Source Status Alert) 53 53 41 E-Mail Alert On (Source Status...
  • Page 54 Examples Power Control and Input Source Turn monitor power off [CMD: POW]  [Transmit]: PC → 07 01 02 50 4F 57 00 08 → Monitor [Return]: Monitor → 07 01 00 50 4F 57 00 08 → PC Turn monitor power on [CMD: POW] ...

  • Page 55: Compliance

    Compliance FCC: FCC CFR Title 47 Part 15 Subpart B: Class A, CISPR 22  ANSI C63.4  ICES-003  cTUVus: UL 60950-1  CAN/CSA-C22.2 NO.62368-1-14   IEC 62368-1...

  • Page 56: Dimensions

    Dimensions...

  • Page 57: Appendix I: Moving And Carrying Information

    Appendix I: Moving and Carrying Information Moving the Display: Moving the display requires at least four people. Attempting to move the display with one person may result in dropping the display and/or serious injury. When moving a display in its shipping carton, lift the carton using the white handles.

  • Page 58: Appendix Ii: Installing A Wall Mount

    Appendix II: Installing a Wall Mount Follow the manual instructions for the mount you have selected. • • Refer all servicing issues to qualified service personnel. Moving the display requires at least two people • Before installing, please make sure the wall is reinforced and strong enough to hold the •...

  • Page 59: Appendix Iii: Wall Mount Safety Notes

    Appendix III: Wall Mount Safety Notes...
