Modulex LINEAR150 Installation Manual

Installation Guide Mounting
LINEAR ModuleX
Discontinued product
LINEAR150
End-Type
300
600
900
1200
Coner-Type
Cross-Type
T-Type
To install the fixture safely《 Read carefully and follow all the instructions in the guide 》
Warning : Failure to install the fixture properly could result in personal injury.
Caution :
Failure to install the fixture properly could result in property damage.
The fixture is for indoor use only in general conditions.
Before Warning
Can not be used following conditions (Causes of falling, electrocution and fire)
installation
●Inclined, uneven surface
●High humidity
●Outside
●On the floor
●Vibrated or shocked areas
●Areas get direct sunlight
Please contact if you are not able to judge whether installation
environment is suitable to the places or not.
Please follow the fixturesʼ indication or specification for the distance of irradiated area.
Caution
(Causes of change in shape, change in color of irradiated objects)
Please follow the fixturesʼ instruction or this guide to install the fixture and lamp. (Causes of falling・electrification・fire)
At lighting Warning
fixture
Make sure to install all the parts of fixtures besides installation and mounting parts will not touch with any
installation
objects both inside and outside of ceiling such as lighting track, etc. (Causes of falling・electrification・fire)
Do not dismount or remodel fixtures. (Cause of electrification・fire・falling・broken fixtures)
Make sure the construction will not affect any fire prevention systems such as sprinkler by heat from the fixture.
Caution
(Causes for improper operation)
Mounting Depth Mounting Depth
SX-LB140E
SX-LB146E
weight wide weight
SX-LB140S/300
SX-LB146S/300
weight wide
weight
SX-LB146S/600 SX-LB140S/600
weight wide weight
SX-LB146S/900 SX-LB140S/900
weight wide weight
SX-LB140S/1200
SX-LB146S/1200
weight wide weight
SX-LB146C SX-LB140C
weight weight
SX-LB146CR SX-LB140CR
weight weight
SX-LB146T SX-LB140T
weight
weight
Box Fixture (sold separately)
Fixture Installing Rail
3/8"Bolt(Constructs Separately)
Adjustable bracket
Cover maintenance
Ballast
Ceiling board
(Constructs Separately)
Surface finish Surface finish
: Prohibited
: Strict observance
●Insulated inside of ceiling ●Ambient temperature under 0℃ and over 35℃
●Ceiling which canʼt hold the fixture weight
20cm〜
●On the wall
●Places affected by wind or air-conditioner machine 10cm〜
●Near fire
Insulator Insulator
●Dusty areas, corrosive gas outbreaks areas
Installation Guide
wide
wide
wide
wide
wide
Power wire
Insulator
Mounting
