Split Air Conditioner
OWNER'S MANUAL
LENNOX A I R CO ND I T I O NE RS
MO D E L:
LI012CI-180V432
LI012CI-180P432
LI018CI-180P432
LI024CI-180P432
LI012HI-180V432
LI012HI-180P432
LI018HI-180P432
LI024HI-180P432
Thank you for selecting LENNOX air conditioners.Please read this manual
carefully before operation and keep it for further reference.
LI012CO-180V432
LI012CO-180P432
LI018CO-180P432
LI024CO-180P432
LI012HO-180V432
LI012HO-180P432
LI018HO-180P432
LI024HO-180P432
