Asus ZenWiFi Pro ET12 Quick Start Manual

Quick
Start Guide
ASUS ZenWiFi Pro ET12
AXE11000 Tri Band Router
Model: ET12
Before Setup
Preparing to set up an AiMesh WiFi system
Find two ZenWiFi Pro ET12, and power both on.
1
Use a network cable to connect your optical modem to the WAN port of either ZenWiFi Pro
2
ET12. This ZenWiFi Pro ET12 will be the AiMesh router, and the other ZenWiFi Pro ET12 will
be the AiMesh node.
The LEDs turn solid blue to indicate that ZenWiFi Pro ET12 is ready for setup.
3
ASUS Router App
Download free ASUS Router APP to set up
and manage your router(s).
AiMesh Setup Steps
01
Prepare
Place your AiMesh router and node within 3 meters of each
other during the setup process.
02 AiMesh node
Keep your AiMesh node powered on and standby for AiMesh
system settings.
03 Enabling Bluetooth
Enable Bluetooth on your phone.
Troubleshooting
If your AiMesh router cannot find any AiMesh node nearby or
synchronization fails, please check the following and try again.
a Move your AiMesh node closer to the AiMesh router ideally. Ensure that it is
within 3 meters.
Your AiMesh node is powered on.
b
E19128_ZenWiFi_Pro_ET12_one-page_2PK_QSG.indd 1 E19128_ZenWiFi_Pro_ET12_one-page_2PK_QSG.indd 1
Hardware Explanations
1
2
Button and Port Explanations
LAN ports 1-2
2.5G / 1G WAN port
2.5G / 1G LAN port
Specifications:
04 Launching ASUS Router APP
Launch ASUS Router APP, and then follow the on-screen in-
structions to finish the AiMesh setup.
Plug the adapter into the DCIN port, and press the power switch.
The power LED will light up when your hardware is ready.
WPS button
Reset button
Power switch
DCIN port
DC Power adapter DC Output: +19V with max 2.37A current
+19.5V with max 2.31A current
Operating Temperature 0~40 o C Storage Temperature
Operating Humidity 50~90% Storage Humidity
AiMesh node
AiMesh Setup Steps
within
3 meters
AiMesh node
2.5G / 1G WAN port
Connect your optical modem to this
port with a network cable.
LAN ports 1-2
Connect your PC to a LAN port with
a network cable.
2.5G / 1G LAN port
Connect your PC to a 2.5G / 1G LAN
port with a network cable.
0~70 o C
20~90%
AiMesh router
AiMesh router
