Heat build-up can reduce the service life of your projector, and can also be dangerous. G Do not put any flammable object or spray can near the projector, hot air is exhausted from the ventilation holes.
Do not use attachments not recommended by the manufacturer as they may cause hazards. Do not place this projector on an unstable cart, stand, or table. The projector may fall, causing serious injury to a child or adult, and serious damage to the projector. Use only with a cart or stand recommended by the manufacturer, or sold with the projector.
: (714) 236-8610 AC POWER CORD REQUIREMENT The AC Power Cord supplied with this projector meets the requirement for use in the country you purchased it. AC Power Cord for the United States and Canada : AC Power Cord used in the United States and Canada is listed by the Underwriters Laboratories (UL) and certified by the Canadian Standard Association (CSA).
TABLE OF CONTENTS FEATURES AND DESIGN PREPARATION NAME OF EACH PART OF PROJECTOR SETTING-UP PROJECTOR CONNECTING AC POWER CORD LENS INSTALLATION POSITIONING PROJECTOR ADJUSTABLE FEET INSTALLING PROJECTOR IN PROPER POSITION MOVING PROJECTOR CONNECTING PROJECTOR TERMINALS OF PROJECTOR CONNECTING TO COMPUTER...
This Multimedia Projector is designed with most advanced technology for portability, durability, and ease of use. This projector utilizes built-in multimedia features, a palette of 16.77 million colors, and matrix liquid crystal display (LCD) technology. Compact Design This projector is extremely compact in size and weight.
CONNECTOR LAMP COVER AIR INTAKE VENTS This projector is equipped with cooling fans for protection from overheating. Pay attention to following to ensure proper ventilation and avoid a possible risk of fire and malfunction. G Do not cover vent slots.
CAUTION The AC Power Cord must meet the requirement of the country where you use the projector. Confirm the AC plug type with the chart below. The proper AC Power Cord must be used. If the supplied AC Power Cord does not match the AC outlet, contact your sales dealer.
Before setting up a projector, install Projection Lens on Projector. 1. Before installation, check where a projector is used and prepare a suitable lens. For specifications of a Projection Lens, contact sales dealer where you purchased a projector. 2. For installation, refer to lens replacement and installation manual.
Position and keystone distortion of image can be adjusted using Menu Operation. (Refer to P 21 and 37.) INSTALLING PROJECTOR IN PROPER POSITION Install the projector properly. Improper installation may reduce the lamp lifetime and cause a fire hazard. 10˚ 10˚...
G When carrying a projector, use a suitable carrying case. G Do not transport a projector by using a courier or transport service in an unsuitable transport case. This may cause damage to a projector. To transport a projector through a courier or transport service, consult your dealer for best way.
CONNECTING PROJECTOR TERMINALS OF PROJECTOR This projector has input and output terminals on its back for connecting computers and video equipment. Refer to figures on pages 12 to 14 and connect properly. COMPUTER AUDIO OUTPUT TERMINAL (ANALOG) INPUT 1/AUDIO MONITOR...
16" MODE (832 x 624) 19" MODE (1024 x 768) OFF OFF OFF 21" MODE (1152 x 870) (✽ = Cable or adapter is not supplied with this projector.) • Control Cable for PS2 Port ✽ • USB Cable • MAC Adapter (When connecting to Macintosh computer) •...
(variable) before using this terminal. (See page 23.) Audio Input External Audio Equipment Audio Amplifier ✽ = Cable is not supplied with this projector.) ✽ • Audio Cable {Mini Plug (stereo)} • Scart Cable Video Disc Player Component Video Component Video...
FOCUS BUTTON Used to adjust focus. (P21) LASER POINTER FUNCTION These caution labels are put on remote control. POWER ON-OFF BUTTON Used to turn projector on or off. (P20) AUTO PC ADJ. BUTTON NO SHOW Use to operate AUTO PC IMAGE Adjustment function.
For correct polarity (+ and –), terminals are in contact with pins in compartment. Operating Range Point Remote Control Unit toward projector (Receiver Window) whenever pressing any button. Maximum operating range for Remote Control Unit is about 16.4’ (5m) and 60° in front and rear of a projector.
TOP CONTROLS AND INDICATORS This projector has CONTROL BUTTONS (TOP CONTROLS) and INDICATORS on its top. LAMP REPLACE INDICATOR WARNING TEMP. INDICATOR Turns to yellow when Flashes life of projection lamp internal draws to an end. (P44) temperature is too high.
BEFORE OPERATION OPERATING ON-SCREEN MENU HOW TO OPERATE ON-SCREEN MENU You can control and adjust this projector through ON-SCREEN MENU. Refer to following pages to operate each adjustment on ON-SCREEN MENU. 1 DISPLAY MENU Press MENU button to display ON-SCREEN MENU.
/Auto picture control/Color temp. /White balance (R/G/B) /Sharpness/Gamma /Noise reduction/Progressive] (Refer to P34-36) BEFORE OPERATION SETTING MENU Used to change settings of projector or reset Lamp Replace Counter. (Refer to P37-40) SOUND MENU Used to adjust volume or mute sound.
Projection Lamp automatically. Refer to “Power management” on page 39. When WARNING TEMP. Indicator is flashing, projector cannot be turned on, refer to the section "MAINTENANCE" on page 42. When the both WARNING TEMP. and READY Indicator flashing, refer to the section "MAINTENANCE" on page 42.
ADJUSTING SCREEN Press ZOOM button on Top Control or ZOOM L/M button on Remote Control Unit. Message “Zoom” is displayed. Press ZOOM L button or POINT UP button to make image larger, and press ZOOM M button or POINT DOWN button to make image smaller.
BASIC OPERATION Press FREEZE button on Remote Control Unit to freeze picture on-screen. To cancel FREEZE function, press FREEZE button again or press any other button. Press NO SHOW button on Remote Control Unit to black out image. To restore to normal, press NO SHOW button again or press any other button.
Select INPUT source by pressing INPUT button on Top Control. Select INPUT source by pressing INPUT 1, INPUT 2 or INPUT 3 button on Remote Control Unit. If projector cannot reproduce proper image, select correct input source through MENU OPERATION (see below). NOTE G Input 1 terminal is switchable and can be used as computer input or monitor output.
Move arrow to "RGB", and then press SELECT button. This projector automatically tunes to most different types of computers based on VGA, SVGA, XGA or SXGA (refer to “COMPATIBLE COMPUTER SPECIFICATION” on page 49). When a computer is selected, this projector automatically tunes to incoming signal and projects the proper image without any special setting.
Store adjustment parameters. Adjustment parameters from Auto PC Adjustment can be memorized in this projector. Once parameters are memorized, setting can be done just by selecting Mode in PC SYSTEM Menu (P24). Refer to step 3 of MANUAL PC ADJUSTMENT section (P27).
Multi-Scan system of this projector. If this happens, projector cannot reproduce a proper image and image may be recognized as a flickering picture, a non-synchronized picture, a non-centered picture or a skewed picture.
Page 27
Display area Selects area displayed with this projector. Select resolution at Display area dialog box. Display area H Adjustment of horizontal area displayed with this projector. Press POINT LEFT/RIGHT button(s) to decrease/increase value and then press SELECT button. Display area V Adjustment of vertical area displayed with this projector.
Select image level among Standard, Real, Image 1, Image 2, Image 3 and Image 4 by pressing IMAGE button on Top Control or on Remote Control Unit. Standard Normal picture level preset on this projector. Real Picture level with improved halftone for graphics. IMAGE 1~4 User preset picture adjustment in IMAGE ADJUST Menu (P36).
PICTURE SCREEN ADJUSTMENT This projector has a picture screen resize function, which enables you to display desirable image size. Press MENU button and ON-SCREEN MENU will appear. Press POINT LEFT/RIGHT button(s) to move a red frame pointer to SCREEN Menu icon.
VIDEO INPUT SELECTING INPUT SOURCE WHEN SELECT INPUT 2 (5 BNC INPUT JACKS ) When connecting to those equipment, select a type of Video source in SOURCE SELECT Menu. Press MENU button and ON-SCREEN MENU will appear. Press POINT LEFT/RIGHT button to move a red frame pointer to INPUT Menu icon.
When Video System is PAL-M or PAL-N, select system manually first. PAL / SECAM / NTSC / NTSC4.43 / PAL-M / PAL-N If projector cannot reproduce proper video image, it is necessary to select a specific broadcast signal format among PAL, SECAM, NTSC, NTSC 4.43, PAL-M, and PAL-N.
Select image level among Standard, Cinema, Image 1, Image 2, Image 3 and Image 4 by pressing IMAGE button on Top Control or on Remote Control Unit. Standard Normal picture level preset on this projector. Cinema Picture level adjusted for picture with fine tone. IMAGE 1~4 User preset picture adjustment in IMAGE ADJUST Menu (P36).
PICTURE SCREEN ADJUSTMENT This projector has a picture screen resize function, which enables you to display desirable image size. Press MENU button and ON-SCREEN MENU will appear. Press POINT LEFT/RIGHT button(s) to move a red frame pointer to SCREEN Menu icon.
The projector lets you replace up to eight colors for each image. There are four preset images for VIDEO mode and four preset images for PC, giving a total of eight images.
Page 35
COLOR SELECTION MODE CANCEL The mode will return to the pointer mode (even if you press the MENU key on the projector or the remote control). (You will need to reselect and re-adjust the color in this case.) QUIT The COLOR MANAGEMENT menu will be exited and the display will return to the normal projection screen, but any settings that have been changed will not be stored.
Page 36
PICTURE IMAGE Color temp. Press either POINT LEFT button or POINT RIGHT button to Color temp. level that you want to select. (XLow, Low, Mid or High) White balance (Red) Press POINT LEFT button to lighten red tone and POINT RIGHT button to deeper tone.
Language used in ON-SCREEN MENU is selectable from among English, German, French, Italian, Spanish, Portuguese, Dutch, Swedish, Russian, Chinese, Korean and Japanese. Lamp mode When selecting the Lamp mode, the projector reduce the brightness and set into the low power consumption mode. Normal mode Auto mode The brightness is adjusted automatically to a level that is suitable for the screen.
Page 38
4:3 image, even if the input signal is HDTV. Blue back When this function is “On,” this projector will produce a blue image instead of the video noise on the screen when any input source is unplugged or turned off.
Page 39
Power management This projector is equipped with a power management function. When the input signal is interrupted and any button is not pressed for 30 seconds or more, the power management function operates in order to reduce power consumption and conserve lamp operating time.
Page 40
" when controlling a projector with computer. NOTE: This is provided not for basic operation but for future use. Key lock This function locks the operation of the projector's control panel and the remote control. This locks operation of the projector's control panel.
OPERATING WIRELESS MOUSE Wireless Remote Control Unit is not only able to operate this projector but also function as a wireless mouse for most Personal Computers. POINT button, drag ON/OFF button and two CLICK buttons are used for wireless mouse operation.
If this case happenes, disconnect and reconnect the AC power cord, and then turn on the projector again to check its operation. If the projector shuts down again or fails to be turned on, the internal check and repair will be required.
RECOMMENDATION We recommend avoiding dusty/smoky environments when operating a projector. Usage in these environments may cause poor image quality. When using under dusty or smoky conditions, dust may accumulate on a lens, liquid crystal panels, or optical elements inside a projector.
APPENDIX When the life of the Projection Lamp of this projector draws to an end, the LAMP REPLACE indicator lights yellow. If this indicator lights yellow, replace the projection lamp with a new one promptly. Allow a projector to cool, for at least 45 minutes before you open Lamp Cover.
Additionally, check carefully to ensure that there are no broken shards or pieces of glass around the projector or coming out from the cooling air circulation holes. Any broken shards found should be cleaned up carefully. No one should check the inside of the projector except those who are authorized trained technicians and who are familiar with projector service.
Problem may be with your graphics controller rather than with a projector. (When you reconnect a projector, be sure to turn computer and monitor off before you power up a projector. Power equipment back on in order of : Projector and computer.)
Page 47
SERVICE WARNING: High voltages are used to operate this projector. Do not attempt to open cabinet. You can often correct operating problems yourself. If the projector fails to work properly, see the "TROU- BLESHOOTING" section on pages 46 and 47.
LAMP green The projector is OFF. (The AC Power Cord is unplugged.) The projector is READY to be turned on with the POWER ON- OFF button. The projector is operating normally. The Warning Temp. Indicator flashes red to let you know the internal temperature of the projector exceeds the normal level.
COMPATIBLE COMPUTER SPECIFICATIONS Basically this projector can accept a signal from all computers with V, H-Frequency mentioned below and less than 180 MHz of Dot Clock. ON-SCREEN H-Freq. RESOLUTION DISPLAY VGA 1 640 x 480 31.47 VGA 2 720 x 400 31.47...
APPENDIX TECHNICAL SPECIFICATIONS Projector Type Dimensions (W x H x D) Net Weight LCD Panel System Panel Resolution Number of Pixels Color System High Definition TV Signal Scanning Frequency Motorized Lens Shift Horizontal Resolution Projection Lamp Input 1/Monitor Output Jacks...
CONFIGURATIONS OF TERMINALS COMPUTER INPUT-1 and MONITOR OUT TERMINALS (ANALOG) Terminal : HDB15-PIN Pin Configuration COMPUTER INPUT-1 TERMINAL (DIGITAL) Terminal : DVI 24-pin Pin Configuration CONTROL PORT CONNECTOR Terminal : Mini DIN 8-PIN Pin Configuration 8 7 6 USB CONNECTOR (Series B) Pin Configuration Red Input +5V Power...
G Long Zoom Lens G Short Fixed Lens The lens of this projector can be replaced with other optional lens which are sold separately. This feature enables you to use the projector for wide variety of uses. For installation and replacement of the lens, always contact the sales dealer. The projector lens must be installed or replaced by well-trained sales or service engineers.
Page 56
CHRISTIE DIGITAL SYSTEMS, Inc. CHRISTIE DIGITAL SYSTEMS, Inc. 809 Wellington Street North 10550 Camden Drive Kitchener, Ontario Cypress, CA 90630 Canada N2G 4Y7 Telephone (519) 744-8005 Telephone (714) 236-8610 North America call toll-free Fax (714) 503-3385 1-800-265-2171 (sales) Toll Free 1-800-407-7727...
