- Page 1 GR-M328FBHC PANDUAN BAGI PENGGUNA LEMARI ES FREEZER BAWAH Bacalah buku petunjuk ini dengan seksama sebelum menggunakan lemari es dan simpanlah untuk digunakan di lain waktu. www.lg.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS Big Fresh Zone PRODUCT FEATURES - Removal of the Big Fresh Zone drawer - Refitting the Big Fresh Zone drawer Extra Space IMPORTANT SAFETY Fridge Basket INSTRUCTIONS In & Out Carrier Tilting Fresh Basket Dairy Corner COMPONENTS Door-In-Door... -
Page 3: Product Features
PRODUCT FEATURES PRODUCT FEATURES * Depending on the model, some of the following functions may not be available. DOOR ALARM The Door Alarm function is designed to prevent refrigerator malfunctioning that could occur if a refrigerator door or freezer door remains open. If a refrigerator door or freezer door is left open for more than 60 seconds, a warning alarm sounds in 30 second intervals until it is closed. -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE. This guide contains many important safety messages. Always read and obey all safety messages. This is the safety alert symbol. It alerts you to safety messages that inform you of hazards that can kill or hurt you or others, or cause damage to the product. - Page 5 IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE. To reduce the risk of fire, electric shock, or personal injury when using your product, basic safety precautions should be followed, including the following. This appliance is intended to be used in household and similar applications such as - staff kitchen areas, offices and other working environments;...
- Page 6 IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE. To reduce the risk of fire, electric shock, or personal injury when using your product, basic safety precautions should be followed, including the following. CAUTION Installation The refrigerator must be properly installed in accordance with the Installer Instructions that were taped to the front of the refrigerator.
-
Page 7: Components
COMPONENTS COMPONENTS Use this page to become more familiar with the parts and features of your refrigerator. Page references are included for your convenience. *The appearance and specifications of the actual product may differ depending on the model. Refrigerator Exterior Door in Door release Button LED Display... -
Page 8: Refrigerator Interior
COMPONENTS Refrigerator Interior Adjustable Refrigerator Shelf LED interior lamps The shelves in your refrigerator are adjustable to The interior lamps light up meet your individual storage needs. the inside of the refrigerator. Dairy Product Bin Used to preserve dairy products. Fridge Basket Hygiene Fresh filter Door-In-Door... -
Page 9: Installation
INSTALLATION INSTALLATION Installation Overview Please read the following installation instructions first after purchasing this product or transporting it to another location. 1 Unpacking your 2 Choosing the proper 3 Leveling and Door refrigerator location Alignment... -
Page 10: Unpacking Your Refrigerator
INSTALLATION Unpacking Your Refrigerator Choosing the Proper Location The refrigerator should always be WARNING plugged into its own individual properly grounded electrical outlet rated for Use two or more people to move and install 220 Volts, 50 Hz, AC only, and fused the refrigerator. -
Page 11: Ambient Temperature
INSTALLATION Turning On The Power Ambient Temperature Install this appliance in an indoor area where Plug in the refrigerator. the temperature is between 55°F (13°C) and 110°F (43°C). If the temperature around the appliance is too low or high, the cooling ability CAUTION may be adversely affected. -
Page 12: How To Remove The Freezer Door
INSTALLATION Turn around to release lock and raise Remove the door by raising it from the lower hinge. hinge up. Upper hinge Keeper Lower hinge Disassemble Door, raising it from Hinge Center. Height Adjustment Leveling the doors may not be possible when the floor is not leveled, or is of weak or poor construction. -
Page 13: When The Freezer Door Is Lower
INSTALLATION Method 2) When the Freezer Door is Lower (1) Using the large side of the number Method 1 is recommended. spanner, rotate the locking nut ( Use spanner for freezer door adjustment. clockwise to unlock it before adjusting the Adjust-Hinge pin. -
Page 14: How To Use
HOW TO USE HOW TO USE Before use Clean the refrigerator. Clean your refrigerator thoroughly and wipe off all dust that may have accumulated during shipping. CAUTION Do not scratch the refrigerator with a sharp object or use a detergent that contains alcohol, a flammable liquid or an abrasive when removing any tape or adhesive from the refrigerator,. -
Page 15: Control Panel
HOW TO USE Control Panel Express Freezing Express Freezing Control Panel Features This function increases both ice making and freezing capabilities. When you touch the Express Freezing button, the graphic will illuminate in the display and will continue for 3 hours. The function will automatically disable itself after 3 hours. -
Page 16: Storing Food
HOW TO USE Storing Food Food Preservation Location Each compartment inside the refrigerator is designed to store different types of food. Store your food in the optimal space to enjoy the freshest taste. Fridge Basket Adjustable Refrigerator Shelf Store beverages, water, etc. Adjustable shelves to meet your individual storage needs. - Page 17 HOW TO USE Food Preservation Location (continued) Dairy Product Bin Store diary foods such as butter, cheese, etc. Big Fresh Zone Preserve vegetables and fruits. Door-In-Door Preserve frequently-taken out foods such as beverages, snacks, etc. Extra Space Preserve small foods such as eggs, ham, etc.
-
Page 18: Food Storage Tips
HOW TO USE Storing Frozen Food Food Storage Tips * The following tips may not be applicable NOTE depending on the model. Check a freezer food guide or a reliable cookbook for further information about preparing Wrap or store food in the refrigerator in airtight food for freezing or food storage times. -
Page 19: Adjusting The Refrigerator Shelves
HOW TO USE Storing Frozen Food (continued) Adjusting the Refrigerator Shelves Packaging Packaging The shelves in your refrigerator are adjustable Successful freezing depends on correct to meet your individual storage needs. Your packaging. When you close and seal the model may have either glass or wire shelves. package, it must not allow air or moisture in or out. -
Page 20: Using The Folding Shelf
HOW TO USE Using the Folding Shelf When Closing the Door You can store taller items, such as containers or bottles, by simply pushing the front half of the shelf underneath the back half of the shelf. Pull the front of the shelf firmly toward you to return to a full shelf. -
Page 21: Big Fresh Zone
HOW TO USE Big Fresh Zone Refitting the Big Fresh Zone drawer. Removal of the Big Fresh Zone drawer. Insert the left and right roller of the drawer into the guides whilst the draw is slightly The Moisture (balance) keeper helps optimize lifted at the front. -
Page 22: Extra Space
HOW TO USE Fridge Basket Extra Space Store small foods like eggs, ham, cheese, etc. Preserve drinks like small packs, milk, beer, juice etc. Multi-collection corner supporter In & Out Carrier Ideally used to store and carry multiple items to and from the refrigerator. Open and close pushing or pulling grips. -
Page 23: Tilting Fresh Basket
HOW TO USE Tilting Fresh Basket Dairy Corner Ideal for storing vegetables soon to be eaten. You can store dairy products such as butter, cheese etc. If you close the refrigerator door with the dairy corner left open, the refrigerator door may not close properly. -
Page 24: Door-In-Door
HOW TO USE Hold the bottom of daily basket and raise it Door-In-Door up to take it out. The Door-In-Door compartment allows for easy access of commonly used food items. The inner Door-In-Door includes two door bins, Cheese & Butter and Condiment bins, that are specially designed for food that can be stored at a warmer temperature. -
Page 25: Adjustable Moving Basket
HOW TO USE Hold both ends of the basket and lift up the Freezer Drawer front part of the basket. Use the compartment for packed frozen foods Assemble in the same method as and frequently-taken out foods. disassembly. Use the bottom compartment for frozen foods. (Dried fish &... -
Page 26: Refitting The Freezer Drawer
HOW TO USE Refitting the Freezer Drawer Easy Ice Maker Remove the water reservoir from the ice Insert both rollers into the guides with maker assembly. the front of the drawer slightly raised and Open the lid and fill with water to the gently push in. -
Page 27: How To Disassemble Easy Ice Maker
HOW TO USE Lift the ice bin gently when removing it if it CAUTION has ice in it. It is normal for the water reservoir Ensure the ice tray is fully inserted when bottle to have some ice in it. remove refitting. -
Page 28: Cleaning The Ice Tray
HOW TO USE Cleaning the Ice tray Freezer/Fridge basket You can store small packaged frozen food Remove the ice tray by pulling it out. (Freezer basket), small packaged refrigerated Caution should be taken if the ice tray food or beverages (Fridge basket) such as milk, is full of ice. -
Page 29: Maintenance Cleaning
MAINTENANCE MAINTENANCE Cleaning Both the refrigerator and freezer sections defrost automatically; however, clean both sections about once a month to prevent odors. Wipe up spills immediately. Always unplug the refrigeration before cleaning. General Cleaning Tips General Cleaning Tips WARNING Unplug refrigerator or disconnect power. Use non-flammable cleaner. -
Page 30: Replacing The Hygiene Fresh Filter
MAINTENANCE Inside Walls (allow freezer to warm Inside Walls (allow freezer to warm Replacing the Hygiene Fresh up so the cloth will not stick) up so the cloth will not stick) filter To help remove odors, you can wash the inside of the refrigerator with a mixture of baking It is recommended that you replace the soda and warm water. -
Page 31: Smart Diagnosis
LG service center. Only use the Smart Diagnosis feature when Press and hold the Freezer Temperature instructed to do so by the LG call center agent. button for three seconds while continuing The transmission sounds that you will hear are to hold your phone to the speaker. -
Page 32: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING Review the Troubleshooting section before calling for service; doing so will save you both time and money. Problem Possible Causes Solutions Refrigerator and The refrigerator display control Cancel the OFF mode so that the unit Freezer section is set to OFF (some models). commences operation. - Page 33 TROUBLESHOOTING Problem Possible Causes Solutions Refrigerator or Refrigerator was recently It may take up to 24 hours for each compartment Freezer section is installed. to reach the desired temperature. too warm. Air vents are blocked. Rearrange items to allow air to flow throughout the compartment.
- Page 34 TROUBLESHOOTING Problem Possible Causes Solutions Interior moisture Doors are opened often or for When the doors are opened often or for long buildup. long periods of time. periods of time, warm, humid air enters the compartment. This raises the temperature and moisture level within the compartment.
- Page 35 TROUBLESHOOTING Problem Possible Causes Solutions Frost or ice Condensation from food with a This is normal for food items with a high water crystals on frozen high water content has frozen content. food (inside of inside of the food package. sealed package).
- Page 36 TROUBLESHOOTING Problem Possible Causes Solutions Pulsating or Your refrigerator is designed Normal Operation High-Pitched to run more efficiently to keep Sound your food items at the desired temperature. The high efficiency compressor may cause your new refrigerator to run longer than your old one, but it is still more energy efficient than previous models.
- Page 39 Cikarang Barat, Bekasi, Jawa Barat 17520 Indonesia TANDA PENDAFTARAN 14010 PETUNJUK PENGGUNAAN MANUAL DAN KARTU JAMINAN/GARANSI DALAM BAHASA INDONESIA BAGI PRODUK ELEKTRONIK LAYANAN KONSUMEN/ Nomor : I.13.LG1.02807.0812 CUSTOMER INFORMATION CENTER LG Twin Tower, 20, Yoido-Dong, Printed in Korea Youngdungpo-Gu, Seoul, 150-721, Korea.
