Table Of Contents - AquaTools AT8695 Owner's Manual

Table of Contents

Specifications ..............................................................2
Safety Instructions ........................................................3
General Information ....................................................3
Installation ...................................................................4
Initial Startup ...............................................................4
Filter Disassembly / Assembly......................................5
Cartridge Cleaning Procedure ......................................6
System Inspection/Winterizing .....................................6
Troubleshooting Guide ................................................7
Repair Parts List ...........................................................8
Warranty......................................................................9
8(55.2)
7(48.3)
6(41.4)
5(34.5)
4(27.6)
3(20.7)
2(13.8)
1(6.9)
0(0)
0 20 40
(0) (76) (151)
Flow in GPM (LPM)
Pressure Drop Curve for AT8695 and AT86150.
Table 2 - Filter Specifications
Filter Area sq. ft. (m )
2
Max. Flow Rate GPM (LPM)
Max. Operating Pressure PSI (kPa)
Max. Continuous Water Temperature F(C)
AT86150
Max Flow
AT8695
Max Flow
60 80 100 120 140
(227) (303) (379) (454) (530)
SPECIFICATIONS
Table 1 - Filter Dimensions in inches (mm)
Dimension
A
B
Minimum
Service
Height
A
160
(606)
FIGURE 1 - Dimensions in inches (mm)
Model No.
AT8695 AT86150
95 (8.8) 150 (13.9)
95 (360) 150 (568)
50 (345) 50 (345)
104° (40°) 104° (40°)
2
Model No.
AT8695
36 (914)
31 (787)
Air Release
Valve
Pressure
Gauge
TM
Posi-Ring
Inlet
2" NPT
B
3/4" Drain
18"
12" Dia.
6-7/8" 6-35/64"
AT86150
51 (1,295)
40 (1,016)
Outlet
2" NPT
6-37/64"
3-3/4"
