FUNCTION OF MAJOR MECHANICAL PARTS (BOTTOM VIEW)
21
22
19
20
No.
19
Syncro Gear
20
Master cam
21
Capstan D.D. motor
22
Reel belt
23
24
Function
VC-AA350A/L/M/W
VC-AA352W,AA360A,AA370A
VC-AA550A/L/W,AA560A,AA570A
No.
Function
23
Clutch lever
24
Limiter pulley ass'y
25
Shifter
7
25
