PARTS DESCRIPTION

(1)
(2)
(6)
1) Control Panel
2) Louvers
3) Water Fill Door
4) Left Side Grill
5) Front Grill
6) Water Level Indicator
7) Casters
WARNING -- READ AND SAVE THE AIR COOLER SAFETY & MAINTENANCE GUIDE AND USER
MANUAL BEFORE USING THIS PRODUCT. FAILURE TO FOLLOW THESE INSTRUCTIONS MAY
DAMAGE AND/ OR IMPAIR ITS OPERATION AND VOID THE WARRANTY. IN CASE THERE IS
ANY INCONSISTENCY OR CONFLICT BETWEEN THE ENGLISH VERSION AND ANY OTHER
LANGUAGE VERSION OF THE CONTENT OF THIS MATERIAL, THE ENGLISH VERSION SHALL
PREVAIL.
(3)
(4)
(5)
(9)
(7)
(8)
(10)
8) Rear Grill Screws
9) Rear Grill
10) Water Tank
11) Power Cord & Plug
12) Water Inlet Valve
13) Honeycomb Cooling Media
14) Drain Plug
