PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 1 B1
2 1 CAC1
3 1 C2
4 1 C3
5 2 C6, C7
6 1 C8
7 1 C9
8 1 C10, C11
9 1 C13
10 1 C20
11 1 C21
12 1 C23
13 1 D1
14 2 D2, D8
15 1 D3
16 1 D4
17 1 D9
18 1 F1
19 1 L1
20 1 L2
21 1 Q1
22 2 R1, R2
23 1 R3
24 1 R4
25 1 R5
26 1 R7
27 1 R8
28 2 R10, R11
29 1 R18
30 1 R19
31 2 R20, R27
32 1 R21
33 1 R23
34 1 R25
35 2 R32, R33
36 1 T1
37 1 U1
38 1 V1
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
PART DESCRIPTION
RECTIFIER, BRIDGE 600V, 0.8A
CAP , 0.1μF , 310V, 20%
CAP , FILM, 0.22μF , 450V, 10%
CAP , 10μF , 20%, 50V, ALUM
CAP , X7R, 0.01μF , 50V, 10%, 0805
CAP , X5R, 4.7μF , 16V, 20%, 0805
CAP , C0G, 47pF , 50V, 10%, 0805
CAP , ELEC., 330μF , 63V, 20%
CAP , U2J, 1.5nF , 250V, 5%, 0805
CAP , 2.2nF , 10%, TYPE "Y1"
CAP , C0G, 4.7pF , 50V, 0805
CAP , X7R, 1μF , 100V, 10%, 1206
DIODE, ULTRA FAST RECTIFIER
DIODE, FAST SWITCHING
DIODE, 3A Ultra-Fast REC., Power-DI-5
DIODE, TVS, 600W, 170V, SMB
DIODE, TVS, 600W, 48V, SMB
FUSE, 2.5A
INDUCTOR, 1mH,
CHOKE, D Code Double Choke
XSTR, MOSFET, N-CHANNEL 650V
RES, CHIP ., 249k, 1%, 1/4W, 1206
RES, CHIP ., 200k, 1%, 1/8W, 0805
RES, CHIP ., 9.31k, 1%, 1/8W, 0805
RES, CHIP ., 150, 1%, 1/8W, 0805
RES, CHIP ., 10k, 1%, 1/8W, 0805
RES, CHIP ., 0.03, 1/4W, 1%, 1206
RES, CHIP ., 499k, 1%, 1/4W, 1206
RES, CHIP ., 100k, 1%, 1/8W, 0805
RES, CHIP ., 40.2k, 1%, 1/8W, 0805
RES, CHIP ., 20k, 1%, 1/8W, 0805
RES, CHIP ., 0, 1/8W, 0805
RES, CHIP ., 3.48k, 1%, 1/8W, 0805
RES, CHIP ., 20, 5%, 1/8W, 0805
RES, CHIP ., 200k, 1%, 1/2W, 1210
XFMR, FLYBACK
IC., Isolated Flyback Controller
VARISTOR, 385V
DEMO MANUAL DC1947A
MANUFACTURER/PART NUMBER
DIODES INC., HD06-T
VISHAY, BFC233922104
RUBYCON, 450MPH224K
RUBYCON, 50YXJ10M 5X11
Murata, GRM216R71H103KA01D
AVX, 0805YD475MAT2A
AVX, 08055A470KAT
RUBYCON, 63ZL330MEF
Murata, GRM21A7U2E152JW31D
VISHAY, 440LD22-R
AVX, 08055A4R7BAQ2A
AVX 12061C105KAT2A
CENTRAL SEMI.CMR1U-10M
DIODES INC., BAV20W-7-F
DIODES INC., PDU340-13
DIODES INC., SMBJ170A-13-F
DIODES INC. SMBJ48A-13-F
BUSSMAN, SS-5H-2.5A
TDK, TSL1315RA-102JR78-PF
EPCOS, B82731H2701A030
INFINEON, IPB60R165CP
VISHAY, CRCW0805249KFKEA
VISHAY, CRCW0805200KFKEA
VISHAY, CRCW08059K31FKEA
VISHAY, CRCW0805150RFKEA
VISHAY, CRCW080510KFKEA
VISHAY, WSL1206R0300FEA
VISHAY, CRCW1206499KFKEA
VISHAY, CRCW0805100KFKEA
VISHAY, CRCW080540K2FKEA
VISHAY, CRCW080520KFKEA
VISHAY, CRCW08050000Z0EA
VISHAY, CRCW08053K48FKEA
VISHAY, CRCW080520R0JKEA
VISHAY, CRCW1210200KFKEA
WÜRTH ELECTONIK, 750817251
LINEAR TECH. LT3799EMSE-1#PBF
Stackpole Electronic, Inc. CV385K10R
