MICROWAVE OVEN
SERVICE MANUAL
MODEL: MH-657PLM / 658PMS
CAUTION
BEFORE SERVICING THE UNIT, READ
THE SAFETY PRECAUTIONS IN THIS MANUAL.

Advertisement

Table of Contents
loading

Related Manuals for LG MH-657PLM

Summary of Contents for LG MH-657PLM

  • Page 1 MICROWAVE OVEN SERVICE MANUAL MODEL: MH-657PLM / 658PMS CAUTION BEFORE SERVICING THE UNIT, READ THE SAFETY PRECAUTIONS IN THIS MANUAL.

  • Page 2: Safety Precautions

    SAFETY PRECAUTIONS This device is to be serviced only by properly qualified service personnel. Consult the service manual for proper service procedures to assure continued safety operation and for precautions to be taken to avoid possible exposure to excessive microwave energy. PRECAUTIONS TO BE OBSERVED BEFORE AND DURING SERVICING TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY...

  • Page 3: Table Of Contents

    CONTENTS (Page) SAFETY PRECAUTIONS - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Inside front cover SPECIFICATIONS - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-1 CAUTIONS - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-1 INSTALLATIONS - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-1...

  • Page 4: Specifications

    SPECIFICATIONS ITEM DESCRIPTION MODEL MH-657PLM / 658PMS Power Requirement 230 Volts AC 50 Hz Single phase, 3 wire grounded Microwave 1,300W Gril 1,250W Combination 2,500W Power Output 900 Watts full microwave power (IEC705) Microwave Frequency 2,450 MHz Magnetron 2M214 - 39F Timer 0 ~ 99 min.

  • Page 5: Cautions

    CAUTIONS Unlike other appliances, the microwave oven is MICROWAVE RADIATION high-voltage and high-current equipment. Personnel should not be exposed to the Though it is free from danger in ordinary use, microwave energy which may radiate from the extreme care should be taken during repair. magnetron or other microwave generating device if it is improperly used or connection.

  • Page 6: Installations

    INSTALLATIONS BEFORE YOU BEGIN, READ THE FOLLOWING INSTRUCTIONS COMPLETELY AND CAREFULLY. INSTALLING EARTHING INSTRUCTIONS 1. Empty the microwave oven and clean inside it with This microwave oven is designed to be used in a fully a soft, damp cloth. Check for damage such as earthed condition.

  • Page 7: Operating Instructions

    OPERATING INSTRUCTIONS FEATURES Oven Front Plate Window Door Screen Door Seal Control Panel Safety Door Lock System Cook Tray Turntable Rotating Ring CONTROL PANEL: MH-658PMS 1. INDICATORS 2. DIAL AUTO COOK: Used to cook the foods listed by one touch. LESS/MORE: Used to change cooking time.
  • Page 8 OPERATING INSTRUCTIONS CONTROL PANEL: MH-657PLM 1. INDICATORS 2. DIAL AUTO COOK: Used to cook the foods listed by one touch. LESS/MORE: Used to change cooking time. WEIGHT: Used to select the desired weight. SET CLOCK: Used to set the time of day.

  • Page 9: Operating Sequence

    OPERATING SEQUENCE 8. CHILD LOCK The following is a description of component functions during oven operation. This oven has a CHILD LOCK feature • TO SET CHILD LOCK 1. CANCEL FUNCTION • Touch the Stop Touch the pad whenever you need to STOP •...

  • Page 10: Schematic Diagram

    SCHEMATIC DIAGRAM...

  • Page 11: Circuit Description

    CIRCUIT DESCRIPTION power of microwave oven as POWER LEVEL. GENERAL DETAILS (refer to page 1-1) • The low voltage transformer supplies the necessary • One complete cycle of relay 2 is 22 seconds. voltage to the micom controller when power cord is plugged in.

  • Page 12: Service Information

    SERVICE INFORMATION TOOLS AND MEASURING INSTRUMENTS NECESSARY TOOLS NECESSARY MEASURING INSTRUMENTS Tools normally used for TV servicing are sufficient. • TESTER(VOLTS-DC, AC., Ohmmeter) Standard tools are listed below. • Microwave survey meter • Diagonal pliers - Holaday HI-1500 • Long nose pliers HI-1501 •...
  • Page 13 MEASUREMENT WITH OUTER CASE NOTES WHEN MEASURING REMOVED • Do not exceed meter full scale deflection. • The test probe must be removed no faster than • When you replace the magnetron, measure for 1 inch/sec (2.5 cm/sec) along the shaded area, microwave energy leakage before the outer case is otherwise a false reading may result.

  • Page 14: Measurement Of Microwave Power Output

    MEASUREMENT OF MICROWAVE POWER OUTPUT • Microwave power output measurement is made with • The microwave power output P in watts is calculated the microwave oven supplied at its rated voltage and from the following formula : operated at its maximum microwave power setting with 4187 x (∆T) a load of (1000±5) g of potable water.
  • Page 15 D. DOOR GROSS ASSEMBLY REMOVAL F. FAN MOTOR ASSEMBLY REMOVAL 1) Open the door. 1) Discharge the high voltage capacitor. 2) Remove the choke cover very carefully with a flat- 2) Disconnect the leadwire from fan motor, noise filter blade screwdriver. and high voltage capacitor.
  • Page 16 H. AIR DUCT ASSEMBLY REMOVAL J. REMOVING THE TURNTABLE MOTOR 1) Remove the turntable. 1) Disconnect the leadwire from lamp and MGT 2) Remove the turntable shaft VERY CAREFULLY thermostat. with a slotted screwdriver. 2) Remove the mounting screw to the magnetron. 3) Lay the unit down on its back.
  • Page 17 K. PCB ASSEMBLY REMOVAL 1) Remove the control panel assembly from the cavity. (Refer to control panel assembly removal Latch Board on previous page.) 2) Remove screws which hold the PCB SUB ASS’Y to the control panel. 3) Disconnect the flat cable from the PCB SUB Primary Interlock Switch ASS’Y and take off the PCB SUB ASS’Y.

  • Page 18: Interlock Continuity Test

    INTERLOCK CONTINUITY TEST WARNING : FOR CONTINUED PROTECTION AGAINST EXCESSIVE RADIATION EMISSION, REPLACE ONLY WITH IDENTICAL REPLACEMENT PARTS. TYPE NO. SZM-V 16-FA-63 OR VP-533A-OF FOR PRIMARY SWITCH TYPE NO. SZM-V 16-FA-62 OR VP-532A-OF FOR MONITOR SWITCH TYPE NO. SZM-V 16-FA-63 OR VP-533A-OF FOR SECONDARY SWITCH B.

  • Page 19: Component Test Procedure

    COMPONENT TEST PROCEDURE CAUTIONS 1. DISCONNECT THE POWER SUPPLY CORD FROM THE OUTLET WHENEVER REMOVING THE OUTER CASE FROM THE UNIT. PROCEED WITH THE TEST ONLY AFTER DISCHARGING THE HIGH VOLTAGE CAPACITOR AND REMOVING THE WIRE LEADS FROM THE PRIMARY WINDING OF THE HIGH VOLTAGE TRANSFORMER.
  • Page 20 COMPONENTS TEST PROCEDURE RESULTS Antenna Gasket Chassis Filament NOTE: When testing the magnetron, be sure to install the magnetron gasket in the correct position and be sure that the gasket is in good condition. HIGH VOLTAGE Measure the resistance. Normal: Momentarily indicates CAPACITOR (Ohm-meter scale: Rx1000) several ohms, and then...
  • Page 21 COMPONENTS TEST PROCEDURE RESULTS FUSE Check for continuity of the fuse with an Normal Abnormal multi-meter. NOTE: If the fuse is blown, check the primary, the secondary, and the monitor switches, H.V.D. and H.V.C. before replacing the fuse. If the fuse is blown by improper switch operation replace the defective switch and the fuse at the same time.
  • Page 22 COMPONENTS TEST PROCEDURE RESULTS Disconnect the 8 pin Check for P.C.B. connector. Cooking Start connector from P.C.B. (Refer to schemetic diagram) Cooking Start RELAY 2, RELAY 3 Relay 3 OF P.C.B. (Wire leads removed.) Note: Relay Relay 1 Relay 1: Fan motor Turntable motor Oven lamp Relay 2: Microwave...

  • Page 23: Trouble Shooting

    TROUBLE SHOOTING WHEN YOU GET A COMPLAINT FROM YOUR CUSTOMER, EVALUATE THE COMPLAINT CAREFULLY. IF THE FOLLOWING SYMPTOMS APPLY, PLEASE INSTRUCT THE CUSTOMER IN THE PROPER USE OF THE MICROWAVE OVEN. THIS CAN ELIMINATE AN UNNECESSARY SERVICE CALL. CAUTIONS 1. Check grounding before checking for trouble. 2.
  • Page 24 (TROUBLE 1) The following visual conditions indicate a probable defective control circuit. 1. Incomplete segments. • Segment missing. • Partial segment missing. • Digit flickering (NOTE: Slight flickering is normal.) 2. Colon does not turn on or blink. 3. A distinct change in the brightness of one or more numbers in display. 4.
  • Page 25 (TROUBLE 2) Oven does not operate at all ; Display window does not display any figures and no input is accepted. CONDITION CHECK RESULT CAUSE REMEDY Replace primary Malfunction of the Check continuity 1. Fuse blows. Continuity. and monitor monitor switch. of monitor switches.
  • Page 26 (TROUBLE 3) Display shows all figures set, but oven does not start cooking while desired program times are set and START pad is touched. CONDITION CHECK RESULT CAUSE REMEDY Defective Replace Check continuity 1.Setting time does No continuity. secondary switch. secondary switch.
  • Page 27 (TROUBLE 5) No microwave oscillation even though oven lamp and fan motor run (Display operates properly) CONDITION CHECK RESULT CAUSE REMEDY No microwave Disconnect the Defective P.C.B Replace P.C.B No continuity. oscillation. wire leads from assembly assembly relay 2 and check continuity Continuity.
  • Page 28 (TROUBLE 6) Oven does not cook properly when programmed for the set power level (Operates properly on HIGH) CONDITION CHECK RESULT CAUSE REMEDY Output is full when Defective P.C.B. Replace P.C.B. Disconnect the Abnormal. you set lower assembly. assembly. wire leads from power level.

  • Page 29: Exploded View

    EXPLODED VIEW INTRODUCTION OVEN CAVITY PARTS INTERIOR PARTS BASE PLATE PARTS DOOR PARTS LATCH BOARD PARTS CONTROL PANEL PARTS...
  • Page 30 DOOR PARTS 15006A 13581A 13536A 13552A 13213A 14890A 13720D 13550A 14026A WTP004 14970A 136502 136501...
  • Page 31 CONTROL PANEL PARTS 24781S 268711 268712 23572A 249401 23806C 23550A 26638A 250201...
  • Page 32 OVEN CAVITY PARTS WTT021 33808A WTT021 33112U WTT028 WSZ094 33052M WTT020 343501 33390P 35300S 344702 33390G 34810A 466003 34370T 348102 36549H 348102 344701 35889A 568771 34036W 36549S 346810 WTP013...
  • Page 33 LATCH BOARD PARTS 43501A 466001 466003 466001 43500A...
  • Page 34 INTERIOR PARTS 33550H 34810H 568771 24970A 34930W WTT021 343502 50FZZA WSZ002 WTT021 56411A WTP004 WTT037 56201A 54975G 56549F 56322V WTT028 55900A 54974S WSZ002 WSZ002 50CZZH 56324A WSZ002 968101 WTP004 56851D 56912B 54810C 56930M WSZ002 WTT028 55262A...
  • Page 35 BASE PLATE PARTS 56170D 63302A WTT021 647781 WTT030 WSZ002 WTT021 63303A...
