CONTENTS CONTENTS How the Microwave Function Works IMPORTANT SAFETY INSTRUCTIONS Microwaves are a form of energy similar to radio, television waves, and ordinary daylight. Normally, BEFORE USE microwaves spread outwards as they travel through the Unpacking & Installing This oven, however, has a magnetron that is designed Control Panel to make use of the energy in microwaves.
IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE...
Page 6
his model doesn't provide a temperature probe. arm houses; y clients in hotels, motels and other residential environments; ed and breakfast type environments.
Page 7
aution, hot surface hen the symbol is used, It means that the surfaces are liable to get hot during use. o not place an object(a book, a box, etc.) on the product. he product may overheat or catch fire or the object may fall, causing injury to persons.
BEFORE USE BEFORE USE UNPACKING & INSTALLING By following the basic steps on these two pages you will be able to quickly check that your oven is operating correctly. Please pay particular attention to the guidelines on where to install your oven. When unpacking your oven make sure you remove all accessories and packing materials.
Page 9
BEFORE USE Press the STOP/Cancel button, and press the START button one time to set 30 seconds of cooking time. The DISPLAY will count down from 30 seconds. When it reaches 0 it will sound BEEPS. Open the oven door and test the temperature of the water.
BEFORE USE CONTROL PANEL Part COOK MODE See page 12 "Timed Cooking" See page 13 "Grill Cooking" See page 13 "Grill Combi Cooking" INVERTER DEFROST See page 25 "Inverter Defrost" PROOF / WARM See page 23 "Proof" See page 24 "Keep Warm" INVERTER COOK Inverter Cook allows you to cook most of your favorite food by selecting the food type and the...
BEFORE USE SETTING CLOCK MORE/LESS When your oven is plugged in for the first time or By turning the d ial , TIMED COOK when power resumes after a power interruption, program can be adjusted to cook food for a the numbers in the display reset to ' 12H '.
HOW TO USE HOW TO USE MICROWAVE POWER LEVELS TIMED COOKING Your microwave oven is equipped with five power levels to give you maximum flexibility and control (MANUAL COOKING) over cooking. The adjacent table will give you some idea of which foods are prepared at each of This function allows you to cook food for a the various power levels.
HOW TO USE GRILL COOKING GRILL COMBI. COOKING This feature will allow you to brown and crisp food Your oven has a combination cooking feature which quickly. There is no need for preheating. allows you to cook food with heater and microwave. Always use gloves when removing food and Example: Programme your oven with micro accessories after cooking as the oven &...
HOW TO USE CHILD LOCK This is a unique safety feature that prevents If the CHILD LOCK was already set and you unwanted oven operations. Once the CHILD touch another pad, the word Loc shows in LOCK is set, no cooking can take place. the display.
HOW TO USE ROAST MENU INSTRUCTIONS Weight Initial Code Menu Instructions Utensil Limit Temperature Jacket 0.2 - 1.0 kg Room 1. Wash potatoes and dry with a paper towel. Rack Potatoes (180 - 220 g 2. Pierce each potato 8 times with a fork. / each) 3.
HOW TO USE POPULAR MENU Your oven’s menu has been preprogrammed to automatically cook food. Tell the oven what you want and how many items there are. Then let your microwave oven cook your selections. Example: To cook 0.3 kg Dal Tadka 1.
Page 17
HOW TO USE Weight Initial Code Menu Instructions Utensil Limit Temperature Chicken Tikka 0.2 - 0.4 kg Room Ingredients Rack 4 chicken breasts, cut into cubes On a 1 cup natural yogurt drip dish 1 tablespoon ground cumin 1 tablespoon garam masala powder 1 teaspoon ground coriander 1 lemon juice 8 garlic cloves finely chopped...
Page 18
HOW TO USE Initial Weight Code Menu Instructions Utensil Temperature Limit Microwave- Fish ball 1.0 kg Ingredients Room safe bowl and Thai 200 g featherback fish, minced Herbs Spicy 2 tablespoons curry paste Soup 4 Thai eggplant, quarter 1 each red and yellow chili spur pepper, sliced 2 bunches fresh pepper corn ¼...
Page 19
HOW TO USE Initial Weight Code Menu Instructions Utensil Temperature Limit Stir-fried 0.6 kg Room Ingredients Microwave- Squid with 300 g squids safe bowl Curry Powder ½ onion, sliced 2 red spur peppers, sliced 2 Chinese celeries, cut 2 inches 2 spring onions, cut 2 inches 2 tablespoons curry powder 1 egg...
HOW TO USE SOFTEN & MELT The oven uses low power to soften / melt foods, See the following table. Example: To melt 0.2kg chocolate 1. Press STOP/Cancel 2. Press until display shows ‘3’. Turn the DIAL until display shows ‘3-4’. 4.
HOW TO USE DEFROST & COOK Your oven’s menu has been preprogrammed to automatically cook food. Tell the oven what you want and how many items there are. Then let your microwave oven cook your selections. Example: To cook 0.3 kg chicken nuggets 1.
Page 22
HOW TO USE Weight Initial Code Menu Instructions Utensil Limit Temperature 1. Remove lasagna from box packages and remove cover. Frozen 0.3 kg Frozen 2. Place food in the oven. Choose the menu, press Lasagna START. 1. Remove thick-crust pizza from all packaging. Frozen Frozen Pizza 0.5 kg...
HOW TO USE PROOF This feature allows you to cook Yogurt by pressing Proof/Warm button. Example: To cook 0.6 kg yogurt 1. Press STOP/Cancel. Proof/Warm Press until display shows ‘1’. 3. Press START. ‘5h00’ will show in the display. PROOF MENU INSTRUCTIONS Weight Initial Code...
HOW TO USE KEEP WARM The Keep Warm function will keep hot, cooked food at serving temperature. Always start with hot food. Use microwave-safe utensils. Example: Keep warm manually To warm food at high level in 90 minutes 1. Press STOP/Cancel. Proof/Warm Notes : Press...
HOW TO USE INVERTER DEFROST Four defrost sequences are preset in the oven. • The length of defrosting time varies according to The INVERTER DEFROST feature provides you how solidly the food is frozen. with the best defrosting method for frozen foods. •...
USING THE SMART DIAGNOSIS™ FUNCTION Use this function if you need an accurate diagnosis by an LG Electronics service centre when the product malfunctions or fails. Use this function only to contact the service representative, not during normal operation.
Page 30
After cooking is complete, the fan may operate to cool the oven. The display will show 'Cool' . If you open the door or press once STOP/Cancel before the cooking time is complete, the remaining cooking time will show on the display. This is not a malfunction. When operating the microwave oven, If you use a product such as radio, TV, wireless LAN, Bluetooth, medical equipment, wireless equipment etc.
/or capacitive coupling, for the treatment of material or inspection/analysis purposes. Class B equipment is equipment suitable for use in domestic establishments and in establishments directly connected to a low voltage power supply network which supplies buildings used for domestic purposes. You can download a owner's manual at http://www.lg.com...
