GRAVITY
Latch
one-Way
START
Access
Left or
Right?
The Latch is set-up for Right-
Handed gates. With some simple
steps the Latch is ready for
Left-Handed gates.
- Lockable
- Suits 40mm + Posts
- Hi-Impact
Polymer
View from inside the Property
Make these changes for
Left-Hand Gates.
Rotate the base 180°
on both Latch and the
Button.
IMPORTANT: Be
careful not to disturb
inner components.
Sit Striker in Latch and mark the Striker's centre on gate.
Drill pilot holes and mount.
DPG100
Test the locking and unlocking of the Latch and Button.
Maintenance
• Inspect Latch annually or more frequently if the gate is used often.
• Only lubricate with powdered graphite lubricant. No petroleum-based lubricants, oils etc.
• Keep Latch free of contaminants
GRAVITY
GRAVITY
Latch
Latch
one-Way
one-Way
Access
Access
- Lockable
- Lockable
- Suits 40mm + Posts
- Hi-Impact
- Suits 40mm + Posts
- Hi-Impact
Polymer
Polymer
To protect the
Latch from slam
damage add a
Gate Stop.
DPG100
180°
Undo
screws
DPG100
05/09/16
