CYP MED-VPR-3420 Operation Manual

Multiviewer with streaming solution for video conferencing
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MED-VPR-3420
Multiviewer with Streaming Solution
for Video Conferencing
Operation Manual
Operation Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MED-VPR-3420 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CYP MED-VPR-3420

Summary of Contents for CYP MED-VPR-3420

  • Page 1 MED-VPR-3420 Multiviewer with Streaming Solution for Video Conferencing Operation Manual Operation Manual...
  • Page 2 ® registered trademarks of HDMI licensing Administrator, Inc.
  • Page 3 DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. Cypress Technology assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document.
  • Page 4 SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: Always follow basic safety precautions to reduce the risk of fire, •...

  • Page 5: Table Of Contents

    CONTENTS 1. Introduction ...............1 2. Applications ..............2 3. Package Contents ............2 4. System Requirements ............2 5. Features................3 5.1 Multiviewer Component Features .........3 5.2 Video Capture Component Features ......4 6. Operation Controls and Functions .........5 6.1 Front Panel ..............5 6.2 Rear Panel..............7 6.3 RS-232 Pinout and Defaults (Multiviewer)....8 6.4 OSD Menu (Multiviewer) ..........9 6.5 WebGUI Control (Multiviewer) ........26...
  • Page 6 7. Connection Diagram ........61 8. Specifications ..........62 8.1 Technical Specifications ......62 8.2 Video Specifications ........63 8.3 Audio Specifications ........65 8.3.1 Digital Audio ........65 8.3.2 Analog Audio ........66 8.4 Cable Specifications ........66 9. Acronyms ............67...

  • Page 7: Introduction

    1. INTRODUCTION Video conferencing is an important and convenient way to communicate with people around the globe. If you want to express your thoughts clearly by sharing a variety of rich images, an integrated machine with multi- windowing and video capture functions is a splendid idea. This Multiviewer with Streaming Solution for Video Conferencing is just the thing to meet your requirements.

  • Page 8: Applications

    2. APPLICATIONS • Medical procedure multiview recording and distribution • Live video streaming and recording • Distance learning • Security camera recording • Gameplay video webcasting and archival • Entertainment room & home theater matrixing • Lecture hall presentations • Public commercial displays 3.

  • Page 9: Features

    5. FEATURES 5.1 Multiviewer Component Features • HDMI 2.0 and DVI 1.0 compliant (with the use of an HDMI-DVI adapter) • HDCP 1.x and 2.2 compliant • 4 HDMI inputs and 2 HDMI outputs • Supports up to 4K UHD (18Gbps, 4K@50/60Hz 4:4:4, 8-bit) video input and output Note: HDR bypass is not supported.

  • Page 10: Video Capture Component Features

    5.2 Video Capture Component Features • HDMI input and output with HDR, 3D & 4K@60Hz support, DVI 1.0 compatible • HDCP 2.2 and HDCP 1.x compliant • Supports up to 4K UHD (18Gbps, 4K@50/60Hz 4:4:4, 8-bit) video input and bypass output •...

  • Page 11: Operation Controls And Functions

    6. OPERATION CONTROLS AND FUNCTIONS 6.1 Front Panel SERVICE POWER VIDEO IN 1 IN 2 IN 3 IN 4 IN 1 IN 2 IN 3 IN 4 MODE MENU ENTER 1080P SERVICE Port: This port is reserved for firmware update and user EDID/ logo upload use only.
  • Page 12 IN 1/MENU Button: When not in source selection mode, press to enter the OSD menu, or to back out from menu items. When source selection is active, pressing this button will either select input 1 (Matrix mode) or sequentially switch through all 4 inputs for window 1 (PiP/PoP/Quad/ Preset modes).

  • Page 13: Rear Panel

    6.2 Rear Panel AUDIO IN USB 3.0 CAPTURE OUT CAPTURE IN HDMI IN HDMI OUT A HDMI OUT B CONTROL RS-232 DC 24V USB 3.0 Port: Connect directly to a PC’s USB 3.0 port to control and power the video capture component of the unit. Note: If connected via USB 2.0, use of a Y-cable connected to 2 USB 2.0 ports is required in order to properly power the video capture component of the unit.

  • Page 14: Rs-232 Pinout And Defaults (Multiviewer)

    HDMI OUT B Port: Secondary HDMI output of the multiviewer component of the unit. To capture video from the multiviewer component of the unit, connect this port to the CAPTURE IN port located directly above it. CONTROL Port: Connect directly, or through a network switch, to your PC/laptop to control the multiviewer component of the unit via Telnet/ WebGUI.

  • Page 15: Osd Menu (Multiviewer)

    6.4 OSD Menu (Multiviewer) All functions of this unit can be controlled by using the OSD (On Screen Display) which is activated by pressing the MENU button on the front of the unit. Use the + (PLUS), − (MINUS), and ENTER buttons to navigate the OSD menu.
  • Page 16 VIDEO MODE 2ND LEVEL 3RD LEVEL Matrix Video Mode QUAD Preset 1 Preset 2 Preset 3 Preset 4 PiP/PoP/Quad/Preset Mode In 1~4 (In 1) WIN 1 Source In 1~4 (In 2) WIN 2 Source In 1~4 (In 3) WIN 3 Source In 1~4 (In 4) WIN 4 Source Matrix Mode...
  • Page 17 WINDOW LAYOUT (Matrix Mode) 2ND LEVEL 3RD LEVEL In 1~4 (In 1) Input Select FULL Aspect Ratio 16:9 16:10 Best Fit Mirror Border On/Off Border Color Black GREEN Blue Yellow Magenta Cyan White Dark Red Dark Green Dark Blue Dark Yellow Dark Magenta Dark Cyan Gray...
  • Page 18 1) Input Select: Select the input to modify. Note: All settings are individually saved, per-input. 2) Aspect Ratio: Select a fixed aspect ratio for the currently selected window. Selecting the “Full” aspect ratio will stretch the source to fill the output, regardless of original aspect.
  • Page 19 WINDOW LAYOUT (PiP/PoP/Quad/Preset Modes) 2ND LEVEL 3RD LEVEL Border Color Black GREEN Blue Yellow Magenta Cyan White Dark Red Dark Green Dark Blue Dark Yellow Dark Magenta Dark Cyan Gray Window Reset 1) Window Select: Select the window to modify. Note: All settings are individually saved, per-window/per-mode.
  • Page 20 mode’s default size and shape for that window. Selecting “Best Fit” will automatically set the ratio based on the window’s current source resolution. 7) Mirror: Selecting “On” will flip the currently selected window horizontally. 8) Border On/Off: Enables or disable the color border around the currently selected window.
  • Page 21 AUDIO (Matrix Mode) 2ND LEVEL 3RD LEVEL WINDOW OUT A Source In 1 In 2 In 3 In 4 OUT A Mute WINDOW OUT B Source In 1 In 2 In 3 In 4 OUT B Mute 1) OUT A Source: Select the audio source to pair with video output A. 2) OUT A Mute: Enable or disable muting audio output A.
  • Page 22 AUDIO (PiP/PoP/Quad/Preset Modes) 2ND LEVEL 3RD LEVEL WIN 1 OUT A Source Win 2 Win 3 Win 4 In 1 In 2 In 3 In 4 OUT A Mute WIN 1 OUT B Source Win 2 Win 3 Win 4 In 1 In 2 In 3...
  • Page 23 INPUT EDID 2ND LEVEL 3RD LEVEL EDID Mode Appoint FHD 2CH All EDID 4K UHD 2CH 4K UHD+ 2CH Sink OUT A Sink OUT B User 1 User 2 User 3 User 4 IN 1 EDID Same as [All EDID] IN 2 EDID Same as [All EDID] IN 3 EDID...
  • Page 24 3) In 1~4 EDID: Select the EDID to assign to the specified input. Note: Only available in the “Appoint” EDID Mode. 4) User 1~4 EDID: To update any of the unit’s 4 User EDIDs via USB, select “Yes” next to the appropriate User EDID and then insert a USB stick containing the new EDID into the Service port.
  • Page 25 OUTPUT RESOLUTION 2ND LEVEL 640×480p59 1920×1080p25 480p60 1920×1080p30 576p50 1920×1080p50 1920×1080P60 800×600p60 848×480p60 1920×1200RB 1024×768p60 3840×2160p24 1280×720p50 3840×2160p25 1280×720p60 3840×2160p30 4K p24 (DCI) 1280×768p60 4K p25 (DCI) 1280×800p60 4K p30 (DCI) 1280×960p60 4K p50 (DCI) 1280×1024p60 4K p59 (DCI) 1360×768p60 4K p60 (DCI) 1366×768p60 1400×1050p60...
  • Page 26 OSD SETTINGS 2ND LEVEL 3RD LEVEL TOP LEFT Menu Position Top Right Bottom Right Bottom Left Menu Timeout 5~60 (10) Info. Timeout 5~60 (5) Info. Display Transparency 1~10 Background Black GRAY Blue 1) Menu Position: Set the position of the OSD menu on the output. 2) Menu Timeout: Set the length of time, in seconds, that the OSD menu will continue to be displayed if there is no user input, or disable the timeout completely.
  • Page 27 LOGO SETTINGS 2ND LEVEL 3RD LEVEL Logo On/Off 0~100 (10) Position X 0~100 (10) Position Y Load Default Logo Logo Update 1) Logo On/Off: Enable or disable displaying the logo graphic. 2) Position X/Y: Sets the position of the logo’s upper left corner, within the output.
  • Page 28 ETHERNET 2ND LEVEL 3RD LEVEL STATIC IP Mode DHCP Static IP Config x.x.x.x (192.168.1.50) IP Address x.x.x.x (255.255.255.0) Subnet Mask x.x.x.x (192.168.1.254) Gateway Link Status IP Mode [Current IP Mode] IP Address Subnet Mask [Current Network Info] Gateway MAC Addr. [Unit’s MAC Address] 1) IP Mode: Set the unit’s IP address mode to Static or DHCP.
  • Page 29 PRESET 2ND LEVEL 3RD LEVEL PRESET 1 Save Preset 2 Preset 3 Preset 4 PRESET 1 Recall Preset 2 Preset 3 Preset 4 1) Save Preset 1~4: Select a preset and then press the “ENTER” button to store the unit’s current video window configuration to the currently selected preset.
  • Page 30 SETUP 2ND LEVEL 3RD LEVEL Firmware Update User EDID Reset Factory Reset 1) Auto Sync Off: Set the amount of time to continue outputting sync with a black screen if there are no live sources and no operations have been executed on the unit.
  • Page 31 INFORMATION 2ND LEVEL 3RD LEVEL IN 1 IN 2 [Current Input Resolutions] IN 3 IN 4 [Current Output Resolution] Video Mode [Current Mode] Sink A Native [Native resolutions as reported by EDID] Sink B Native Firmware [Current Firmware Versions] RX3/RX4 Firmware 1) Information: Shows the currently detected details for all inputs and both outputs as well as listing the status of a few critical system settings and relevant firmware versions.

  • Page 32: Webgui Control (Multiviewer)

    6.5 WebGUI Control (Multiviewer) • Device Discovery Please obtain the “Device Discovery” software from your authorized dealer and save it in a directory where you can easily find it. Connect the unit and your PC/Laptop to the same active network and execute the “Device Discovery”...
  • Page 33 • WebGUI Overview After connecting to the WebGUI’s address in a web browser, the login screen will appear. Please enter the appropriate user name and password then click “Submit” to log in. Note: The default user name and password is “admin”. On the left side of the browser you will see the following menu tabs where all primary functions of the unit are controllable via the built in WebGUI.

  • Page 34: Upper Tab Windows

    6.5.1 Upper Tab Windows This upper section of the web interface is visible on every tab and provides control over the unit’s operational mode, source selection, and output resolution as well as containing basic information about the currently connected source and display devices. 1) Source: This section displays the currently detected resolution for the sources connected to each input.

  • Page 35: Window Layout Tab

    6.5.2 Window Layout Tab This tab provides control over the position, size, aspect, priority, and other settings of each window in multi-viewer modes. A graphical representation of the layout is also provided. When the unit is in Matrix mode, only a limited selection of controls are available.
  • Page 36 5) Priority: Select the layer priority of the currently selected window. Priority 1 is at the front and priority 4 is at the back. Note: Not available in Matrix mode. 6) Aspect Ratio: Use the dropdown to select a fixed aspect ratio for the currently selected window or input.

  • Page 37: Picture Tab

    6.5.3 Picture Tab This tab provides controls over each input’s contrast, brightness, saturation, hue, and sharpness levels. Note: All picture settings are per-input and are mode-independent. 1) Input Select: Use the dropdown to select the input to modify. 2) Reset: Reset the current input to its default settings. 3) Contrast: This slider provides control over the overall contrast of the currently selected source video.

  • Page 38: Audio Tab

    6.5.4 Audio Tab This tab provides control over the audio output behavior of the unit, including routing selection and muting. Note: Due to Matrix mode only supporting a single “window”, changing modes between a multi-windowing mode and Matrix mode when an audio source is set to windows 2~4 will result in the source reverting to window 1.

  • Page 39: Input Edid Tab

    6.5.5 Input EDID Tab This unit provides the option of three standard EDIDs, two sink sourced EDIDs and four user uploaded EDIDs that can be assigned to all inputs at the same time, or to each input independently. Note: In most cases, assigning a new EDID to an input will cause the affected input to briefly blink out while the source adapts to the new information.

  • Page 40: Hdcp Mode & Status Tab

    This unit provides the following 3 default EDIDs: Unit’s default EDIDs FHD 2CH 1920×1080p@60Hz (4.95Gbps) & 8-bit color, LPCM 2.0 UHD 2CH 3840×2160p@30Hz (10.2Gbps) & Deep Color (8/10/12-bit), LPCM 2.0 UHD+ 2CH 3840×2160p@60Hz (18Gbps) & Deep Color (8/10/12-bit), LPCM 2.0 Note: In some rare cases it is possible for custom or external EDIDs to cause compatibility issues with certain sources.

  • Page 41: Osd Settings Tab

    6.5.7 OSD Settings Tab This tab provides control over the behavior of the OSD menu and informational display. 1) Menu Position: Use the dropdown to set the position of the OSD menu on the output. Available choices are: Top Left, Top Right, Bottom Right, and Bottom Left.

  • Page 42: Logo Settings Tab

    6.5.8 Logo Settings Tab This tab provides control over the user uploaded logo graphic. Controls include positioning, an uploading a new logo directly from the WebGUI and an option to reset the logo to a built in default image that can be used for testing.

  • Page 43: Ethernet Tab

    6.5.9 Ethernet Tab This tab provides controls to change the network settings for the unit. You can manually set the IP address, netmask and gateway address in “Static IP” mode, or you can obtain an IP address automatically by enabling DHCP. Note: The unit’s default Static IP address is 192.168.1.50.

  • Page 44: Setup Tab

    6.5.10 Setup Tab Provides a way to update firmware and reset various sections within the unit. Control over the unit’s Auto Sync Off feature, storing/recalling presets as well as configuring the WebGUI login settings is also provided here. 1) Preset Save: Select a preset from the dropdown list and then click the “Save”...

  • Page 45: Information Tab

    „ Timeout: Set the length of time to wait, in minutes, before logging out a user due to inactivity. Setting this to “0” disables the timeout. 6.5.11 Information Tab This tab displays the unit’s serial number as well as the current firmware versions.

  • Page 46: Video Capture Control & Configuration

    6.6 Video Capture Control & Configuration 6.6.1 USB Video Capture Configuration The USB Video Capture Control software provides control over a selection of basic functions of the unit, including: audio source, HDCP, video settings and volume. An option to return the unit to its factory defaults is also provided. Note: Please obtain the “USB Video Capture Control”...
  • Page 47 2) HDCP: Enable or disable HDCP support on the HDMI input. Note: Disabling HDCP support may enable the recording of the output of some source devices (typically PCs/Macs) that enable HDCP encryption even when it is not required by the current video content. Once HDCP support is disabled on this unit, the connected device should automatically switch to a non-HDCP mode as long as the playing content allows it.

  • Page 48: Video Capture

    6.6.2 Video Capture Video capture and recording/streaming is accomplished using 3rd party software. The choice of video capture software is entirely up to the user. This unit adheres to the UAC (USB Audio Class) and UVC (USB Video Class) standards, allowing the unit to support most common video capture, chat, or streaming software, including support for the Free OBS (Open Broadcaster Software) streaming software, among many other choices.

  • Page 49: Telnet Control (Multiviewer)

    6.7 Telnet Control (Multiviewer) Before attempting to use Telnet control, please ensure that both the unit and the PC are connected to the same active networks. Start your preferred Telnet/Console client, or use the built in client provided by most modern computer operating systems. After starting the client, connect by using the current IP address of the unit and port 23 (if the communication port number used by the unit has not been changed previously).
  • Page 50 COMMAND Description and Parameters get model name Show the unit’s model name. get model type Show the unit’s product type. set feedback broadcast N1 Enable or disable the broadcast of console command feedback. Available values for N1: [Enabled] [Disabled] get feedback broadcast Show the current console command feedback broadcast state.
  • Page 51 COMMAND Description and Parameters get static ipaddr Show the unit’s static IP address. set static netmask N1 Set the unit’s static IP address. N1 = X.X.X.X [X = 0~255, Netmask] get static netmask Show the unit’s static netmask. set static gateway N1 Set the unit’s static IP address.
  • Page 52 COMMAND Description and Parameters set telnet login N1 Enable or disable allowing Telnet logins. Available values for N1: [Enabled] [Disabled] get telnet login Show the current state of Telnet login allowance. set telnet username N1 Set the Telnet login username. N1 = {Username} [16 characters max] get telnet username...
  • Page 53 COMMAND Description and Parameters set window N1 route N2 Set the input to route to the specified window. N1 = 1~4 [Window number] N2 = 1~4 [Input port] Note: Valid in multi-windowing modes only. get window N1 route Show the input currently routed to the specified window. N1 = 1~4 [Window number] Note: Valid in multi-windowing modes only.
  • Page 54 COMMAND Description and Parameters get window N1 display Show the visibility status of the specified window, N1 = 1~4 [Window number] Note: Valid in multi-windowing modes only. set window N1 hposition N2 Set the horizontal position of the specified window. N1 = 1~4 [Window number] N2 = 0~{Max res}...
  • Page 55 COMMAND Description and Parameters get window N1 hsize Show the current horizontal size of the specified window. N1 = 1~4 [Window number] Note: Valid in multi-windowing modes only. set window N1 vsize N2 Set the vertical size of the specified window. N1 = 1~4 [Window number] N2 = 1~{Max res}...
  • Page 56 COMMAND Description and Parameters set window N1 aspect N2 Set the aspect of the specified window. N1 = 1~4 [Window number] Available values for N2: [Full] [16:9] [16:10] [4:3] [Best Fit] [User] get window N1 aspect Show the current aspect of the specified window. N1 = 1~4 [Window number] set window N1 mirror N2...
  • Page 57 COMMAND Description and Parameters set window N1 border color N2 Set the border color of the specified window. N1 = 1~4 [Window number] Available values for N2: [Black] [Red] [Green] [Blue] [Yellow] [Magenta] [Cyan] [White] [Dark Red] [Dark Green] [Dark Blue] [Dark Yellow] [Dark Magenta] [Dark Cyan]...
  • Page 58 COMMAND Description and Parameters set in N1 brightness N2 Set the brightness level of the specified input. N1 = 1~4 [Input port] N2 = 0~100 [Brightness level] get in N1 brightness Show the current brightness level of the specified input. N1 = 1~4 [Input port] set in N1 saturation N2...
  • Page 59 COMMAND Description and Parameters get in N1 sharpness h Show the current horizontal sharpness level of the specified input. N1 = 1~4 [Input port] set in N1 sharpness v N2 Set the vertical sharpness level of the specified input. N1 = 1~4 [Input port] N2 = 0~20 [Vertical sharpness level]...
  • Page 60 COMMAND Description and Parameters set audio out N1 route N2 Route the specified audio source to the specified audio output. N1 = A~B [Output port] Available values for N2: [Input 1] [Input 2] [Input 3] [Input 4] [Window 1] [Window 2] [Window 3] [Window 4] get audio out N1 route...
  • Page 61 COMMAND Description and Parameters get all in edid Show the current EDID used by the “All” EDID mode. set in N1 edid N2 Set the EDID to use on the specified input. N1 = 1~4 [Input port] Available values for N2: [FHD 2-Channel] [4K UHD 2-Channel] [4K UHD+ 2-Channel]...
  • Page 62 COMMAND Description and Parameters set out A timing N1 Set the output resolution to use for both outputs. Available values for N1: [640x480p59] [480p60] [576p50] [800x600p60] [848x480p60] [1024x768p60] [1280x720p50] [1280x720p60] [1280x768p60] [1280x800P60] [1280x960p60] [1280x1024p60] [1360x768P60] [1366x768p60] [1400x1050p60] [1440x900p60] [1600x900p60rb] [1600x1200p60] [1680x1050p60] [1920x1080p24] [1920x1080p25]...
  • Page 63 COMMAND Description and Parameters [3840x2160p60] [Native OUT A] [Native OUT B] get out A timing Show the current resolution used by both outputs. set out A osd position N1 Set the OSD menu location. Available values for N1: [Top Left] [Top Right] [Bottom Right] [Bottom Left]...
  • Page 64 COMMAND Description and Parameters set out A osd info timeout N1 Set the OSD info’s timeout value (in seconds). Available values for N1: [Disabled] 5~60 [Timeout in seconds] get out A osd info timeout Show the current OSD info’s timeout value. set out A osd transparency N1...
  • Page 65 COMMAND Description and Parameters get out A osd logo hposition Show the current horizontal position of the graphical logo overlay. set out A osd logo vposition N1 Set the vertical position of the graphical logo overlay. N1 = 0~100 [Vertical position] get out A osd logo vposition...
  • Page 66 COMMAND Description and Parameters set firmware update Initiates the firmware update process via USB. set factory user edid default Restore the unit’s User EDIDs to their factory default settings. set factory ipconfig default Reset the unit’s network settings to the factory defaults. set factory default...

  • Page 67: Connection Diagram

    7. CONNECTION DIAGRAM Ultrasound Endoscope Vital Sign Conference PC Microphone Stereo Input Environment Camera AUDIO IN USB 3.0 HDMI OUT B HDMI IN HDMI OUT A CAPTURE CONTROL RS-232 DC 24V HDMI Input HDMI Input HDMI Input HDMI Input HDMI Output HDMI Output...

  • Page 68: Specifications

    8. SPECIFICATIONS 8.1 Technical Specifications HDMI Bandwidth 18Gbps Input Ports 5×HDMI (Type-A) 1×Stereo Audio (3.5mm) Output Ports 3×HDMI (Type-A) 1×USB 3.0 (Type-B) Control Ports 1×RS-232 (3.5mm) 1×IP Control (RJ-45) Service Port 1×USB 2.0 (Type-A) Baud Rate 19200 Power Supply (Multiviewer) 24V/2.7A DC (US/EU standards, CE/FCC/UL certified) Power Supply (Vid Capture) Powered via USB 3.0 (0.9A minimum)

  • Page 69: Video Specifications

    8.2 Video Specifications Multiviewer Video Capture HDMI HDMI HDMI HDMI Bypass Supported Resolutions (Hz) Input Output Input Output 720×400p@70/85     640×480p@60/72/75/85 60Hz    720×480i@60     720×480p@60     720×576i@50  ...
  • Page 70 Multiviewer Video Capture HDMI HDMI HDMI HDMI Bypass Supported Resolutions (Hz) Input Output Input Output 1920×1200p@60RB     2560×1440p@60RB     2560×1600p@60RB     2048×1080p@24/25/30     2048×1080p@50/60     3840×2160p@24/25/30 ...

  • Page 71: Audio Specifications

    8.3 Audio Specifications 8.3.1 Digital Audio Multiviewer HDMI Inputs 1~2/ Outputs A~B LPCM Max Channels 8 Channels Sampling Rate (kHz) 32, 44.1, 48, 88.2, 96, 176.4, 192 Bitstream Supported Formats Standard & High-Definition Multiviewer HDMI Inputs 3~4 LPCM Max Channels 2 Channels Sampling Rate (kHz) Bitstream...

  • Page 72: Analog Audio

    8.3.2 Analog Audio Video Capture Analog Input Max Audio Level 2Vrms Impedance 10kΩ Type Unbalanced 8.4 Cable Specifications 1080p 4K30 4K60 (4:4:4) (4:4:4) Cable Length 8-bit 12-bit 8-bit 8-bit High Speed HDMI Cable HDMI Input HDMI Output Bandwidth Category Examples: •...

  • Page 73: Acronyms

    9. ACRONYMS ACRONYM COMPLETE TERM Analog-to-Digital Converter ASCII American Standard Code for Information Interchange Cat.5e Enhanced Category 5 cable Cat.6 Category 6 cable Cat.6A Augmented Category 6 cable Cat.7 Category 7 cable Command-Line Interface Decibel DHCP Dynamic Host Configuration Protocol Digital Visual Interface EDID Extended Display Identification Data...
  • Page 74 ACRONYM COMPLETE TERM Transmission Control Protocol THD+N Total Harmonic Distortion plus Noise TMDS Transition-Minimized Differential Signaling USB Audio Class 4K UHD 4K Ultra-High-Definition (10.2Gbps max) 4K UHD 4K Ultra-High-Definition (18Gbps max) UHDTV Ultra-High-Definition Television Universal Serial Bus USB Video Class Video Graphics Array WUXGA (RB) Widescreen Ultra Extended Graphics Array (Reduced...
