- Page 1 EVY7800AA EVY7800AO EVY7800ZO EVY7805AA EVY7805AO Microwave combi-oven User Manual...
-
Page 2: Table Of Contents
15. TECHNICAL INFORMATION................. 43 WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time. -
Page 3: Safety Information
ENGLISH SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damages. Always keep the instructions with the appliance for future reference. 1.1 Children and vulnerable people safety This appliance can be used by children aged from 8 •... - Page 4 Ensure that the appliance is switched off before • replacing the lamp to avoid the possibility of electric shock. Do not use a steam cleaner to clean the appliance. • Do not use harsh abrasive cleaners or sharp metal •...
-
Page 5: Safety Instructions
ENGLISH The contents of feeding bottles and baby food jars • shall be stirred or shaken and the temperature checked before consumption, in order to avoid burns. Eggs in their shell and whole hard-boiled eggs should • not be heated in the appliance since they may explode, even after microwave heating has ended. - Page 6 • The electrical installation must have – do not put aluminium foil directly an isolation device which lets you on the bottom of the appliance. disconnect the appliance from the – do not put water directly into the mains at all poles. The isolation hot appliance.
-
Page 7: Product Description
ENGLISH • Clean regularly the appliance to • Before replacing the lamp, disconnect prevent the deterioration of the the appliance from the power supply. surface material. • Only use lamps with the same • Fat and food remaining in the specifications. -
Page 8: Control Panel
3.2 Accessories Baking tray Wire shelf For cakes and biscuits. For cookware, cake tins, roasts. 4. CONTROL PANEL 4.1 Electronic programmer 9 10 Use the sensor fields to operate the appliance. Sensor Function Comment field ON / OFF To activate and deactivate the appliance. - Page 9 ENGLISH Sensor Function Comment field Up key To move up in the menu. Down key To move down in the menu. Time and addi‐ To set different functions. When a heating func‐ tional functions tion operates, touch the sensor field to set the timer or the functions: Function Lock, Favourite Programme, Heat + Hold, Set + Go.
-
Page 10: Before First Use
Symbol Function Heat-up Indicator The display shows the temperature in the appliance. Fast Heat Up Indicator The function is active. It decreases the heat up time. Weight Automatic The display shows that the automat‐ ic weight system is active or that weight can be changed. - Page 11 ENGLISH 6.2 The menus in overview Main menu Sym‐ Menu item Application Heating Functions Contains a list of heating functions. Assisted Cooking Contains a list of automatic programmes. Favourite Programme Contains a list of favourite cooking pro‐ grammes created by the user. Basic Settings Used to set other settings.
- Page 12 6.3 Heating Functions Heating function Application True Fan Cooking To bake on up to 2 shelf positions at the same time and to dry food. Set the temperature 20 - 40 °C lower than for the function: Conventional Cooking.
- Page 13 ENGLISH Heating function Application Dough Proving For controlled rising of yeast dough before bak‐ ing. Plate Warming To preheat your plate for serving. Preserving To make vegetable preserves such as pickles. Drying To dry sliced fruit (e.g. apples, plums, peach‐ es) and vegetables (e.g.
-
Page 14: Microwave Mode
The residual heat inside Cooking with the lamp off the oven will continue to cook. Deactivate the lamp during the cooking and activate only when you need it. Use the residual heat to warm up other foods. - Page 15 ENGLISH room temperature. This gives a more Ready meals: even result. Remove all metal or • Ready meals in metal packaging or aluminium packaging or parts before plastic trays with metal covers can defrosting. only be defrosted or heated in the Defrosting fruit, vegetables: microwave if they are expressively designated as suitable for use in the...
- Page 16 Cookware / Material Microwave Grilling Defrost‐ Heating Cooking Browning cookware, e.g. crisp pan or crunch plate Ready meals in packaging 1) With no silver, gold, platinum or metal plating / decorations. 2) Without quartz or metal components, or glazes which contain metals 3) You must follow the manufacturer’s instructions about the maximum temperatures.
- Page 17 ENGLISH 7.2 Microwave functions Functions Description Microwave Creates the heat directly in the food. Use it to heat pre-prepared meals and drinks, to defrost meat or fruit, and to cook vegeta‐ bles and fish. Combi Use it to operate the heating function and the microwave mode together.
-
Page 18: Clock Functions
7.5 Setting the Quick Start 3. Touch to set the time for the function function: Duration. Refer to "Setting the clock functions". 1. If necessary, touch to deactivate 7.6 Examples of cooking the appliance. applications for power settings 2. Touch to activate the Quick Start function. - Page 19 ENGLISH Clock function Application Duration To set the length of an operation (max. 23 h 59 min). End Time To set the switch-off time for a heating function (max. 23 h 59 min). If you set the time for a clock function, •...
-
Page 20: Automatic Programmes
9. AUTOMATIC PROGRAMMES 9.3 Assisted Cooking with WARNING! Weight Automatic Refer to Safety chapters. This function automatically calculates the 9.1 Recipes online roasting time. To use it, it is necessary to input the food weight. You can find the recipes for 1. -
Page 21: Additional Functions
ENGLISH Wire shelf and baking tray together: Push the baking tray between the guide bars of the shelf support and the wire shelf on the guide bars above. Baking tray: All accessories have small indentations at the top of the Push the baking tray between the guide right and left side to increase bars of the shelf support. - Page 22 5. Press again and again until the Activating the programme display shows: Set + Go. 1. Activate the appliance. 6. Press to confirm. 2. Select the menu: Favourite Programme. Press any symbol (except for ) to start the function: Set + Go. The set heating 3.
-
Page 23: Hints And Tips
ENGLISH 11.7 Cooling fan the day brightness mode for the next 10 seconds. When the appliance operates, the – if the appliance is deactivated and cooling fan activates automatically to you set the function: Minute keep the surfaces of the appliance cool. Minder. - Page 24 12.4 Tips on baking Baking results Possible cause Remedy The bottom of the cake is The shelf position is incor‐ Put the cake on a lower not browned sufficiently. rect. shelf. The cake sinks and be‐ The oven temperature is...
- Page 25 ENGLISH Food Function Temper‐ Time (min) Shelf posi‐ ature tion (°C) Flan base - short pas‐ True Fan 170 - 180 10 - 25 Cooking Flan base - sponge True Fan 150 - 170 20 - 25 mixture Cooking Apple pie / Apple pie (2 True Fan 70 - 90 tins Ø...
- Page 26 Food Function Tempera‐ Time (min) Shelf posi‐ ture (°C) tion Fruit flans (made with Conventional 35 - 55 yeast dough / sponge Cooking mixture) Fruit flans made with True Fan 160 - 170 40 - 80 short pastry Cooking Yeast cakes with deli‐...
- Page 27 ENGLISH 12.6 Bakes and gratins Food Function Temperature Time (min) Shelf position (°C) Pasta bake Conventional 180 - 200 45 - 60 Cooking Lasagne Conventional 180 - 200 25 - 40 Cooking Vegetables au Turbo Grilling gratin Baguettes top‐ True Fan Cook‐ 160 - 170 15 - 30 ped with mel‐...
- Page 28 Food Temperature (°C) Time (min) Shelf posi‐ tion Pastries made with 80 - 100 130 - 170 1 / 3 egg white, meringues Macaroons 100 - 120 40 - 80 1 / 3 Biscuits made with 160 - 170...
- Page 29 ENGLISH Food Temperature (°C) Time (min) Shelf position Apple cake, covered 150 - 170 50 - 60 Vegetable pie 160 - 180 50 - 60 10 - 20 Unleavened bread 160 - 180 45 - 55 Puff pastry flan 12 - 20 Flammekuchen Piroggen (Russian ver‐...
- Page 30 Food Func‐ Quantity Power Tempera‐ Time (min) Shelf po‐ tion (kg) (Watts) ture (°C) sition Meat loaf Turbo 0.75 - 1 160 - 170 35 - 50 Grilling Pork Turbo 0.75 - 1 150 - 170 60 - 75...
- Page 31 ENGLISH Dishes Food Func‐ Quantity Power Tempera‐ Time (min) Shelf tion (kg) (Watts) ture (°C) position Dishes True 160 - 180 20 - 35 sweet Cook‐ Savoury True 400 - 160 - 180 20 - 45 dishes with Cook‐ cooked in‐ gredients (noodles, vegeta‐...
- Page 32 Fast Grilling Food Time (min) Shelf position 1st side 2nd side Burgers / Burgers 9 - 13 8 - 10 Pork fillet 10 - 12 6 - 10 Sausages 10 - 12 6 - 8 Fillet steaks / veal...
- Page 33 ENGLISH Frozen Ready Meals Table Food Function Tempera‐ Time (min) Shelf position ture (°C) Conventional as per as per manufac‐ Frozen pizza Cooking manufac‐ turer's instruc‐ turer's in‐ tions structions Conventional 200 - 220 as per manufac‐ Chips (300 - Cooking or Turbo turer's instruc‐...
- Page 34 12.15 Preserving • The jars cannot touch each other. • Put approximately 1/2 litre of water • Use only preserve jars of the same into the baking tray to give sufficient dimensions available on the market. moisture in the oven.
- Page 35 ENGLISH Food Temperature (°C) Time (h) Shelf position Herbs 40 - 50 2 - 3 Plums 60 - 70 8 - 10 Apricots 60 - 70 8 - 10 Apple slices 60 - 70 6 - 8 Pears 60 - 70 6 - 9 12.17 Bread Baking Preheating is not recommended.
- Page 36 Food Power Quantity (g) Time (min) Standing Comments (Watts) time (min) Goulash 10 - 15 10 - 15 Turn halfway through, re‐ move de‐ frosted parts. Defrosting poultry Food Power Quantity (g) Time (min) Standing Comments (Watts) time (min)
- Page 37 ENGLISH Defrosting sausage Food Power Quantity (g) Time (min) Standing Comments (Watts) time (min) Sliced saus‐ 2 - 4 20 - 40 Turn halfway through. Defrosting dairy products Food Power Quantity (g) Time (min) Standing Comments (Watts) time (min) Quark 10 - 15 25 - 30 Remove alu‐...
- Page 38 Food Power Quantity Time (min) Standing Comments (Watts) time (min) Fruit cake 1 piece 1 - 2 15 - 20 Turn plate halfway through. Bread 1000 g 15 - 20 10 - 15 Turn halfway through. Sliced bread 100...
- Page 39 ENGLISH Food Power Quantity Time (min) Standing Comments (Watts) time (min) Baby milk 1000 200 g 0:20 - 0:40 Put spoon (bottle, 180 into bottle, stir and check tem‐ perature. Conven‐ 400 - 500 g 14 - 20 Remove any ience food aluminium lids, turn...
- Page 40 Food Power Quantity Time (min) Standing Comments (Watts) time (min) Vegetables, 500 g 12 - 16 Add approx. short cook‐ 50 ml water, ing time, cook cov‐ ered, stir fresh halfway through. Vegetables, 500 g 14 - 18 Add approx.
-
Page 41: Care And Cleaning
ENGLISH Food Ovenware Pow‐ Tem‐ Time Shelf Comments pera‐ (min) posi‐ (Watt ture tion (°C) 2 chicken Glass dish with strain‐ Turn after 20 halves (2 x min, standing 600 g) time 5 min. au gratin po‐ Gratin dish 10 min tatoes (1 kg) standing time. -
Page 42: Troubleshooting
1. Deactivate the appliance. WARNING! 2. Remove the fuses from the fuse box Danger of electrocution! or deactivate the circuit breaker. Disconnect the fuse before you replace the lamp. The top lamp The lamp and the lamp glass cover can be hot. -
Page 43: Technical Information
ENGLISH Problem Possible cause Remedy The display shows an error There is an electrical fault. • Deactivate the oven code that is not in this ta‐ with the house fuse or ble. the safety switch in the fuse box and activate it again. - Page 44 www.electrolux.com/shop...
