LOCATION AND FUNCTION OF CONTROLS DISPLAY PLAYBACK STOP 14 15 16 1.POWER BUTTON Press it to turn on or off the unit. 2. TUNING KNOB Rotate it to select your desired broadcasting station. 3.CD COMPARTMENT 4.FREQUENCY COUNTER By the pointer, the display shows the frequency of the broadcasting station being received.
Page 3
(CD PLAY,PAUSE )BUTTON At tuner mode, press button to switch to CD mode. At CD mode, press it to pause the CD playing and press it again to resume CD playback. 9,17. TRACK UP/DOWN BUTTONS a. During CD mode, press button to allow you to track forward.
Page 4
15.RPT BUTTON During CD mode, press RPT button to repeat a single track. 16.STOP BUTTON Press it for stop CD playing. 18.FM LIGHT The frequency in the FM station ,the FM light be lighted. 19.AM LIGHT The frequency in the AM station ,the AM light be lighted.
DISC PLAY: Cleaning discs Before playing ,clean the disc with a clean, lint-free, Flip the disc in the direction of the arrow. Note: Do not use so solvents such as benzine, thinners, commercially available cleaners or anti static spray damage the unit: insert a disc with the label surface down, Doing so may damage the unit.
TROUBLE SHOOTING Before going through the check list, wiring connection, should any of the problem persist after check list has been made , consult your nearest service dealer. Symptom Cause Solution The car ignition is not on. If the power supply is properly connected to the car accessory No power switch the ignition key to “ACC”...
SPEAKER CONNECTION Speaker connection ANTENNA PLUG WHITE (L) RCA LINE OUT PLUG RED (R) POWER SUPPLY FUSE BLACK GROUND AUTO ANTENNA YELLOW +GREEN GREY+ -GREEN/WHITE GREY/WHITE- NOTE: In spite of having any kinds of speaker system ,must use 4 ohms impedance of speaker to reduce the distortion during high volume level.
