- Page 1 55cm Wide Fridge Freezer Instruction Manual Model number(s): RH55FF171-ML (B-ML) (R-ML) (SS-ML) (W-ML) For Customer Services & Spare Parts please call 0345 208 8750 or visit us at https://mda.russellhobbs.com IMPORTANT: RETAIN FOR FUTURE REFERENCE...
-
Page 2: Table Of Contents
Contents Safety Instructions ………………………………………. Electrical Safety ………………………………………. Transportation & Handling ………………………………………. Installing & Switching on your Appliance ………………………………………. Before Switching On ………………………………………. Product Overview ………………………………………. Unit & Spare Parts ………………………………………. Usage ………………………………………. 9-10 Temperature Selection ………………………………………. 9-10 Door Reversal ………………………………………. 11-14 Replacing the Bulb ………………………………………. -
Page 3: Safety Instructions
Safety Instructions Important note: Please read this booklet before installing and switching on this appliance. The manufacturer assumes no responsibility for incorrect installation and usage as described in this booklet. Warning: When positioning the appliance, ensure the supply cord is not trapped or damaged. - Page 4 • D o not plug in damaged plugs. • D o not pull, twist or damage the power cable. • D o not plug-in or un-plug the appliance with wet hands to prevent electrical shock. • T his appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards...
-
Page 5: Electrical Safety
• One-, two- and three -star compartments (if they are presented in the appliance) are not suitable for the freezing of fresh food. • If the appliance is left empty for long periods, switch off, defrost, clean, dry and leave the door open to prevent mount developing within the appliance. -
Page 6: Installing & Switching On Your Appliance
Installing and Switching on Your Appliance • Operating voltage for your appliance is 220-240V at 50Hz. • Before plugging in the power supply, ensure that the voltage on the rating label corresponds to the working voltage of your electrical system in your home. •... -
Page 7: Before Switching On
Before Switching On • Before using your appliance, add a teaspoon of bicarbonate of soda to warm water and with a damp cloth wipe down all parts of the new appliance, then repeat the process with a clean damp cloth and dry. (ensure the appliance is not connected to the power when performing this task). -
Page 8: Product Overview
Product Overview Light & thermostat Freezer drawers Adjustable shelves Adjustable feet Drainage hole Door racks Non-adjustable shelf Egg rack & Ice cube tray Crisper Unit Parts & Spare Parts Before installation, check that all parts detailed in the product overview are present. -
Page 9: Usage
Usage Allow to stand for a minimum of 3 hours before plugging in to the mains The temperature in the appliance is controlled by the temperature control buttons located inside the fridge at the top of the cavity. Press the control buttons to regulate the temperature inside the fridge. - Page 10 Usage Door open alarm If the doors of the appliance are open for more than 3 minutes the LED light at the top of the fridge compartment will flicker until the door(s) is closed. Power cut memory In case of a power failure, when the power is restored the appliance will retain its settings.
-
Page 11: Door Reversal
Door Reversal You will need to tilt the appliance backward to access the lower hinge which holds screws. Do not tilt more than 45 degrees and do not lay the appliance flat on its side. For your own safety, a minimum of 2 people should lift or tilt this product. Tools Required: Cross headed screwdriver, flat headed screwdriver and hexagonal spanner. - Page 12 Door Reversal 3. Take off the middle hinge by removing the screws, support the door and remove the hinge and then the door. Place the door on a cushioned surface. Remove the screw cap covers that are on the left of the unit and fix them on to the opposite side 4.
- Page 13 Door Reversal 5. Tilt the appliance carefully, no more than 45 degrees and remove the adjustable foot from the left side. Take off the bottom hinge by removing the screws. Remove the hinge pin and install it on the opposite side of the hinge. Then reattach the hinge to the left side of the appliance, reinstall the adjustable foot to the right side and place the freezer door back on.
- Page 14 Door Reversal 7. Remove the hinge stopper from the bottom of the fridge door and fix the spare hinge stopper that is supplied as an accessory (packaged with the IB) to the opposite side of the fridge door, ensuring it is fixed securely. Then . remove the hinge plug from the top of fridge door and fix it to the opposite side.
-
Page 15: Replacing The Bulb
Replacing the Bulb The light is an energy efficient, long life LED. Therefore should not need replacing throughout the life of the product however if it does it has to be replaced by a qualified engineer. Please call the service team on 0345 208 8750. -
Page 16: Food Storage Advice
Freezer Storage Advice • Store fresh food in airtight boxes or wrap in bags or foil which are suitable for freezing. • Do not allow frozen food in to direct contact with food to be frozen. • Pre-frozen food must be placed in the freezer as quickly as possible after purchasing. -
Page 17: Energy Saving Advice
Energy Saving Advice • Do not install the appliance close to sources of heat, such as a cooker, dishwasher or radiator. • Locate the appliance in a cool well-ventilated room and make sure that the air vents are clear. • Try to avoid keeping the doors open for a long time, warm air will enter the cabinet and may cause a build-up of ice as well as affecting the energy consumption. -
Page 18: Maintenance & Cleaning
Maintenance & Cleaning Disconnect the appliance from the power supply before cleaning. Internal Cleaning • Do not pour water over the appliance. • The cavity should be cleaned periodically using a solution of bicarbonate of soda and lukewarm water (5ml to 0.5 litre of water) •... -
Page 19: Defrosting
Maintenance & Cleaning Defrosting Note: Care must be taken when performing the following procedure. Defrost twice a year or when a frost layer of approximately 7 mm (1/4”) has formed. • 2 hours before the defrosting process, set the thermostat to 2 to make sure the food is at the lowest temperature before removing the frozen foods. -
Page 20: Fault Codes
Fault Codes Thermostat setting 2 & 5 flashing – the refrigerator has a fault contact customer services Trouble shooting Problem Solution Check that the appliance is switched on. Check that there has not been a power cut. Check that the plug is not faulty. Check that the fuse has not blown. - Page 21 Trouble shooting Problem Solution The inner surfaces of the appliance Caused by condensation - dry the inside of the appliance. are wet The outer surfaces of the appliance Caused by condensation - dry the outer of the appliance are wet carefully.
-
Page 22: Connection To The Mains Supply
Connection to the Mains Supply WARNING- THIS APPLIANCE MUST BE EARTHED This appliance is designed to operate from a mains supply of AC220V - 240V; 50HZ. Check that the voltage marked on the product corresponds with your supply voltage. For UK use only – Plug fitting details (where applicable): As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: The GREEN/YELLOW wire is the EARTH and must be connected to the terminal which... -
Page 23: Guarantee
Guarantee This product is guaranteed for 12 months from the date of the original purchase. If any defect arises due to faulty materials or workmanship you must contact Product Care with the original proof of purchase so a replacement or refund can be arranged. Refund or replacement is at the discretion of Product Care. -
Page 24: Technical Specification
Technical Specification Model number RH55FF171-ML (B-ML) (R-ML) (SS-ML) (W-ML) Rated Voltage 220V – 240V ~ 50Hz Capacity 262L External Dimensions(HxWxD) 1755mm x 540mm x 542mm... -
Page 25: Product Fiche
Product Fiche Model RH55FF171-ML/B-ML/R-ML/SS-ML/W-ML Fresh Food Storage Compartment Volume (L) Frozen Food Storage Volume (L) Storage Temperature ( ° C) 0 – 8 & -12 to -26 Energy Consumption (kWh/per year) 269Kwh/y Energy Consumption (kWh/per year), based on standard test results for 24 hours... -
Page 26: Notes
Notes... - Page 27 Notes...
- Page 28 For Customer Services & Spare Parts please call 0345 208 8750 or visit us at https://mda.russellhobbs.com This symbol is known as the 'Crossed-out wheelie bin Symbol'. When this symbol is marked on a product/batteries, it means that the product/batteries should not be disposed of with your general household waste. Only discard electrical/electronic/battery items in separate collection schemes, which cater for the recovery and recycling of materials contained within.
