- Page 1 PureWaterCooler Owners Installation Manual PureChill PWC-900 Countertop Water Dispenser Water Products...
-
Page 3: Table Of Contents
Table of Contents Page 1.0 Introduction 2.0 Receiving 3.0 Product Description 4.0 Installation 5.0 Operation 6.0 Leak detection 7.0 Filter Replacement 8.0 Trouble Shooting Guide 9.0 Specifications 10 Warranty List of Figures Fig. 1 Flow Schematic Fig. 2 PWC-900 Assembly Fig. -
Page 4: Introduction
1.0 Introduction The Vertex PureWaterCooler™ products are a means to produce good-tasting, safe water without using bottles of stored water. The PureChill model PWC-900 described here is made for counter top use. Its low height permits it to fit under cabinets. Please read all the instructions in this manual before operating the PureWater- Cooler™. -
Page 5: Product Description
3.0 Description 3.1 Assembly The PWC-900 assembly drawing is shown in Figure 1. The cooler has one chilling chamber and one hot tank. This chilling chamber water tank holds one gallon of water. and is automatically filled at start-up. The cold water drink- ing line is comprised of an array of sealed stainless steel coils and is sub- merged inside this tank . -
Page 6: Fig. 2 Pwc-900 Assembly
Screws Figure 2. PWC-900 assembly... -
Page 7: Fig. 3 Back View Of Cooler
3.2 Rear View On the back of the cooler are the main power switches; one for heat- ing and one for cooling. When heating or cooling is occurring, indicator lights on the front panel will turn on. The hot temperature is fixed at a nominal 180°F and is controlled with a thermostat mounted on the outside of the hot tank. -
Page 8: Installation
4.0 Installation 4.1 Positioning the Cooler There are some precautions to take when positioning and using the PureWaterCooler™. See the items in Figure 4a and 4b. In addition, the cooler must be located near the supply water. Flexible 1/4-inch plastic tubing may be used for the feed connection. - Page 9 Do not place cooler next to Be sure to use correct power oven or dishwasher. Keep voltage. Plug power cord out of direct sunlight. directly into electrical socket. Figure 4b. Installation Precautions 4.2 Cooler Water Connections When received, the water connections on the back have color coded tube sections with red shipping caps on them.
-
Page 10: Fig. 5 Saddle Valve
Figure 5. Saddle Valve... - Page 11 4.5 Quick Connect Fittings The standard tubing connections on the PureWaterCooler™ are of Quick Connect 0-ring seal design and manufacture. Use the tubing and follow the instructions below to make the connections. If you cut the tubing make sure it is a square cut, fits squarely in the fitting, and seals properly.
-
Page 12: Operation
5.0 Operation 5.1 Start Up a. The PWC 900 Cooler is shipped to you complete and ready to operate. Connect feed water line and all tubing according to instructions. b. Make sure Cold and Hot power switches at back of cooler are OFF before plugging the cooler into 110-volt wall socket. - Page 13 h. The temperature of cold water is set at the factory. Using a flat screwdriver, the temperature can be adjusted, if needed, by turning the temperature control slot Clockwise for colder and Counter clock wise for warmer (See Figure 3). CAUTION: If you turn the COLD POWER button off, wait at least 3 minutes before turning on again to protect the compressor from dam- age.
-
Page 14: Fig. 8 Tank Drain
5.2 Tank Drain Occasionally, it may be desirable to drain both tanks, the hot tank and chilling chamber. There are drain plugs on the back of the cooler. See Figure 8. First, make sure all power is off. The cooler must be moved so that the wa- ter can be drained into a container to collect the water (about 1 1/4 gal). -
Page 15: Leak Detection
7.0 Leak Detection System There are 2 leak detection systems installed in the cooler, one is me- chanical, and is mounted in the base of the filter compartment side. (RHS ) the other is electronic and is located in the base at the rear LHS (see figure 9A) . If water leaks to the base of the cooler cabinet on the right hand side or from the filters, the mechanical leak detector valve will close and shut off the feed water to the filters and the cooler. - Page 16 7.1 Electronic Leak Detection system The electronic water leak detection system is installed in the rear left had corner of the cooler. If a water leak should occur inside the cooler and wa- ter collects in the leak probe tray the power will automatically be shut off. When power is cut off due to water leak: a.
-
Page 17: Filter Replacement
8.0 Filter Replacement The filter elements must be replaced at regular intervals to maintain the quality of the water. The “F” Model 900F has 2-stages of mechanical filtration. A 1st stage 5-micron sediment filter and a 2nd stage activated carbon filter. Both stages must be replaced every 6-12 months. -
Page 18: Trouble Shooting Guide
9.0 Trouble Shooting Guide Problem Cause Solution Check that power cord is plugged • Panel Not Lit No Power Confirm that no water is at leak • probes. Controls Not Set Turn on cold power switch on back • Will Not Cool Thermostat in rear •... -
Page 19: Specifications
8.0 Specifications S516 Model No. PWC-900 Voltage/Frequency AC110V Dimensions (L) 16 x (W) 13 x (H) 16 1/2 Weight (empty) 42 lb. .5 gal. Hot Water Tank Capacity .25 gal. Cold Water tank Capacity 1.0 gal. Power Consumption Hot Water: 500W Cold Water: 100W mkmk Electric Power Cord Length... -
Page 20: Warranty
LIMITED WARRANTY Vertex Water Products (“Manufacturer”) sell its products through independent retailer dealers (“Dealer”) who re- sell to the end-user customer. In this limited warranty, “Vertex” refers to Vertex Water Products and not to the Dealer. WHO IS COVERED BY THIS WARRANTY This limited warranty covers only the first purchaser of the Vertex PureWaterCooler™... - Page 21 SHALL INCLUDE, BUT NOT BE LIMITED TO, LOSS OF ANTICIPATED PROFITS, BUSINESS INTERRUPTION, LOSS OF USE OR REVENUE, COST OF CAPITAL, OR LOSS OR DAMAGE TO PROPERTY OR EQUIPMENT. Contact information: Vertex Water Products 5138 Brooks Street Montclair, California 91763 800-627-2146 www.vertexwater.com email: inquiries@vertexwater.com...
- Page 24 M o n t c l a i r, C a l i f o r n i a PWCM-900_revA_05.17 © 2017 Vertex Water Products...
