- Page 1 Megapixel HD-SDI Indoor Dome Camera CLEBO-HD AID-2301 IR ABOUT MANUAL Before installing and using the camera, please read this manual carefully. Be sure to keep it handy for future reference. 05212012...
- Page 2 PRECAUTIONS Do not open or modify. Do not open the case except during maintenence and installation, for it may be dangerous and can cause damages. Do not put objects into the unit. Keep metal objects and flammable substances from entering the camera. It can cause fire, short-circuits, or other damages.
- Page 3 Table of Contents Introduction Features Parts and Descriptions Dimensions Installation Included Accessories Easy Installations 8~10 Mounting on Electrical Junction Box Connecting to Monitors Adjusting the Camera Adjusting the 3-Axis Gimbal Camera OSD Menu and Glossary 15-26 Troubleshooting Specifications...
- Page 4 720P / 1080P Mode selectable 4x Auto-Focus 3.5~16mm Lens Double Shutter WDR (Wide Dynamic Range) at 15fps Settings 70ft Range IR with Intelligent Camera Sync ( CLEBO-HD AID-2301 IR Electronic Day and Night ( CLEBO-HD AID-2301 True Day and Night (...
- Page 5 PART & DESCRIPTIONS* Lens Power input Connctor 12VDC Voltage RS485, Alarm Yellow (485+) Black (485-) White (Alarm 1) (Alarm 2) BNC (HD-SDI) Bubble w/o IR Upper Case Camera Control Board 2nd Video Connector Mounting Screws...
- Page 6 DIMENSIONS IN MILLIMETERS(INCHES)* Surface Mount Indoor (4.25”) 40,5 (1.59”) 96,8 3.50”) (3.81”) 56,3 (2.21”) TOP VIEW (4.25”)
- Page 7 INSTALLATION* Included with Value Line Vandal Dome Camera 1. User Manual 2. Mounting Template 3. Second Video Jack 4. Four(4) Screw and Four(4) Dry Wall Anchors...
- Page 8 EASY INSTALLATION*...
- Page 9 SURFACE MOUNT INSTALLATION INSTRUCTIONS* Squeeze the sides of the Use the camera’s mounting Drill holes into the drywall and camera and separate the template or your camera to insert the drywall mounts into camera module from the mark the holes as required. the holes.
- Page 10 WALL MOUNT INSTALLATION INSTRUCTIONS* Check to see all parts are in Use the mount to mark the Secure the wall mount to the the box. pilot holes required. Drill wall using the mounting holes into the drywall and screws. insert the drywall mounts. Attach the base of the camera Adjust the camera lens, and to the wall mount with the...
- Page 11 MOUNTING ON ELECTRICAL JUNCTION BOX* NO IR Philips #8-32 x 0.75 NOTE : Screws required for electrical junction boxes are not supplied.These screws are readily available at an electrical supply store.
- Page 12 CONNECTING TO MONITORS*...
- Page 13 ADJUSTING THE CAMERA LENS* Adjusting Auto Focus Lens If pushing the OSD joystick to ‘UP’, the lens will start zoom-in. If pushing the OSD joystick to ‘DOWN’, the lens will start zoom-out. If you keep pushing the joystick, zoom in/out will be continuously operated. When you find the right angle, take off your finger from the joystick and wait.
- Page 14 ADJUSTING THE 3-AXIS GIMBAL* The Gimbal mechanism yields maximum rotation and placement as show below. NO IR NO IR Rotation 360 Panning 360 NO IR Tilting 82 Tilting 90...
- Page 15 MODULE OSD MENU* PROPERTY EXPOSURE LENS BRIGHTNESS LENS TYPE CAMERA ID 0~20 MANUAL, DC, AF 0~255 SHUTTER MODE TITLE OUTDOOR,INDOOR/FLK,Deblur120,Deblur240 AUTO, MANUAL(Indoor, Deblur120, OPTIC ZOOM Deblur240, Outdoor) TELE, WIDE DISPLAY FOCUS MODE MANUAL, AUTO NON, ID,, TITLE OFF, x2, x3, x4 FOCUSING FAR, NEAR PROTOCOL...
- Page 16 PROPERTY CAMERA ID 1 PROPERTY 0~255 You can define the camera ID no. from 0~255 CAMERA ID TITLE TITLE(1-) DISPLAY NONE (1-) After setting the camera ID, you also can make the PROTOCOL PELCO-D title for each camera ID no. Title is total 8 figures BAUDRATE 9600 BPS RETURN...
- Page 17 EXPOSURE BRIGHTNESS 2 EXPOSURE 0~20 You can adjust the brightness. Higher number means brighter images. BRIGHTNESS The default is 10. SHUTTER AUTO SHUTTER RETURN AUTO It’s a defualt. Shutter speed is adjusted properly. MANUAL Shutter speed is selectable from 1/30 ~ 1/60000 but it’s related to the menu LENS-MODE.
- Page 18 LENS LENS TYPE 3 LENS AF mode is supported for Auto Focus Lens. AF LENS DC mode is supported for Auto-iris Varifocal lens. DC LENS LENS TYHPE AF LENS Manual mode is supported for Manual iris or Fixed MANUAL MODE DEBLUR120 board lens.
- Page 19 LENS FOCUS MODE AUTO When using Auto Focus Lens, Focus can be adjusted automatically. Also, you can set-up the TIMER to repeat the automatic focusing after finishing the installation. TIMER is OFF and from 1 ~ 10min. If you want to adjust the focus manually, select MANUAL mode. MANUAL In this case, TIMER menu will be changed to FOCUSING and you can adjust the focus Far / Near.
- Page 20 FUNCTION DZOOM 0~112 Digital Zoom function (Level 0~112) 4 FUNCTION DZOOM AUTO AUTO White Balance is automatically adjusted. PRIVACY MIDDLE AUTO_H White Balance is automatically adjusted in the MOTION condition of Color temperature is high. RETURN White Balance is automatically adjusted in the AUTO_L condition of Color temperature is low.
- Page 21 FUNCTION PRIVACY You can hide some parts of the screen for privacy masking. Total 30 different OFF / ON privacy zone maskings are available. PRIVACY ZONE NO 30 different privacy masking zones are available. ZONE OP Zone Display. ON/OFF ZONE NO 0~29 X-POS X-Position (0~57)
- Page 22 IMAGE CHROMA 5 IMAGE 0~20 It’s color chroma level 0~20. The default is 7. CHROMA SHARPNESS SHARPNESS MIRROR 0~10 It’s to make the image sharper. FLIP High number means sharper image. The default is 10. E-Edge HLMASK MIRROR CONTRAST NORMAL COLOR SET COLOR1 ON/OFF...
- Page 23 IMAGE CONTRAST NORMAL/ HIGH/ HIGHEST You can adjust the contrast level - Normal, High, and Highest. COLOR Color 1 is the default. If the color reproduction on the monitor is not COLOR 1,2,3 satisfied, try other modes - Color 2 or 3. There are total 3 different color display Color 1,2, and 3.
- Page 24 WDR/BLC MAX-DR OFF/ ON MAX Dynamic Range provides clear images 6 WDR/BLC even when strong backlighting is present. Select MAX-DR ON or OFF. MAX DR MODE MODE WDR_WGT BLC OSD OFF/ BLC/ WDR BLC POS-X BLC - Back Light Compensation Mode BLC POS-Y WDR - Wide Dynamic Range (15fps Only) BLC SIZ-X...
- Page 25 DAY&NIGHT TDN MODE 7 DAY&NIGHT AUTO The camera switches between day and night COLOR automatically depending on the certain light level. BW to C C to BW COLOR The camera always stays at day mode. CDS SET BW LOW RETURN The camera always stays at night mode.
- Page 26 SETUP DEFECT DET OFF / ON Dead Pixel Cancellation automatically removes 8 SETUP defective pixels. Note : It’s not recommand to use from the customer side. DEFECT DET 2.0M MODE 1080P 2.0M MODE 720P MODE 60/50FPS 1080P / 720P 1080P is the default. If you want to have low LANGUAGE TDN TEST TEST OFF...
- Page 27 TROUBLESHOOTING Before sending your camera for repair, check the following or contact one of our technical specialists. No VIDEO Check the coaxial cable and make sure it is connected securely. Check the osd menu setup of the camera. Check the power supply and make sure the camera has the proper voltage and current. Out-of-Focus VIDEO Check the clear dome cover and the lens for dirt or fingerprints.
- Page 28 SPECIFICATIONS* MODEL CLEBO-HD AID-2301 (IR) GENERAL SPEC CMOS TYPE 1/2.8" 2.0M Pixels Color Pixels 2000 (H) x 1241(V) 1920x1030 pixels (at COLOR) 30fps Resolution 1920x1030 pixels (at TDN-BW) 30fps Min illumination 0.1Lux [(F1.6, 30IRE), (at COLOR)] (F1.6, 30IRE) 0.01Lux [(F1.6, 30IRE), (at TDN(B/W)]...
