- Page 1 Megapixel HD-SDI Outdoor Dome Camera CLEBO-HD AOD-2301 CLEBO-HD AOD-2301 IR ABOUT MANUAL Before installing and using the camera, please read this manual carefully. Be sure to keep it handy for future reference. 05212012...
-
Page 2: Fcc Compliance
PRECAUTIONS Do not open or modify. Do not open the case except during maintenence and installation, for it may be dangerous and can cause damages. Do not put objects into the unit. Keep metal objects and flammable substances from entering the camera. It can cause fire, short-circuits, or other damages. - Page 3 Table of Contents Introduction Features Parts and Descriptions Dimensions Installation Included Accessories Easy Installations 9~13 Insstallation Connecting to Monitor Adjusting the camera lens 3Axis Gimbal Adjustment Camera OSD Menu and Glossary 17-28 Troubleshooting Specifications...
- Page 4 720P / 1080P Mode selectable 4x Auto-Focus 3.5~16mm Lens Double Shutter WDR (Wide Dynamic Range) at 15fps Settings 70ft Range IR with Intelligent Camera Sync ( CLEBO-HD AOD-2301 IR Electronic Day and Night ( CLEBO-HD AOD-2301 True Day and Night (...
-
Page 5: Part & Descriptions
PART & DESCRIPTIONS* Lens Power input Connctor 12VDC Voltage RS485, Alarm Yellow (485+) Black (485-) White (Alarm 1) (Alarm 2) BNC (HD-SDI) Camera Control Board Bubble Upper Case Flush Mount Case Surface Mount Case Assembly Screws #8 - 32 x 0.75 w/o IR 2nd Video Connector Safety Wire... -
Page 6: Dimensions In Millimeters(Inches)
DIMENSIONS IN MILLIMETERS(INCHES)* Flush Mount 98,8 Surface Mount (I) Indoor, (V) Vandalproof 118,8 53,8... -
Page 7: Installation
INSTALLATION* Included with Outdoor Dome Camera 1. User Manual 5. L-Wrench 2. Mounting Template 6. TORX-T20 Bolt 7. TORX-T20 Wrench 3. Second Video Jack 4. Three (3) Screws and Three (3) Dry Wall Anchors... -
Page 8: Easy Installation
EASY INSTALLATION*... -
Page 9: Surface Mount Installation Instructions
SURFACE MOUNT INSTALLATION INSTRUCTIONS* 1. Use the camera’s mounting 2. Drill holes into the drywall and 3. Pull wires through and make template or your camera to insert the drywall mounts into connections. If you need to keep the wiring within the mark the holes as required. - Page 10 6. Secure the three (3) assembly 7. Adjust the camera’s position 8. Tighten the three locking screws. by using the 3-Axis Gimbal. screws with the L-Wrench to secure the cover dome over the camera. Flush Mount Installation For a flush mount housing, remove the surface mount base (junction box).
-
Page 11: Wall Mount Installation Instructions
WALL MOUNT INSTALLATION INSTRUCTIONS* 1. Verify all parts are in the box. 2. Insert the wires from the 3. Use the mounting template to camera through the wall make pilot holes. Use the dry mount housing. wall anchors and woods screws to attach the assembly. -
Page 12: Pendant Mount Installation Instructions
PENDANT MOUNT INSTALLATION INSTRUCTIONS* 1. Verify all parts are in the box. 2. Attach the top shield to the 3. Run all necessary cables pendant mount. from the ceiling to the mount. 4. Use the mounting template 5. Connect all cables and verify 6. -
Page 13: Corner Mount Installation Instructions
CORNER MOUNT INSTALLATION INSTRUCTIONS* 1. Verify all parts are in the box. 2. Attach the two compression fittings to the corner bracket. 3. Attach the wall mount bracket to the corner 4. Mount the camera assembly to the corner of mount using the machine screws. -
Page 14: Connecting To Monitors
CONNECTING TO MONITORS*... -
Page 15: Adjusting The Camera Lens
ADJUSTING THE CAMERA LENS* Adjusting Auto Focus Lens If pushing the OSD joystick to ‘UP’, the lens will start zoom-in. If pushing the OSD joystick to ‘DOWN’, the lens will start zoom-out. If you keep pushing the joystick, zoom in/out will be continuously operated. When you find the right angle, take off your finger from the joystick and wait. -
Page 16: Adjusting The 3-Axis Gimbal
ADJUSTING THE 3-AXIS GIMBAL* The Gimbal mechanism yields maximum rotation and placement as show below. NO IR NO IR Rotation 360 Panning 360 NO IR Tilting 82 Tilting 90... -
Page 17: Module Osd Menu
MODULE OSD MENU* PROPERTY EXPOSURE LENS BRIGHTNESS LENS TYPE CAMERA ID 0~20 MANUAL, DC, AF 0~255 SHUTTER MODE TITLE OUTDOOR,INDOOR/FLK,Deblur120,Deblur240 AUTO, MANUAL(Indoor, Deblur120, OPTIC ZOOM Deblur240, Outdoor) TELE, WIDE DISPLAY FOCUS MODE MANUAL, AUTO NON, ID,, TITLE OFF, x2, x3, x4 FOCUSING FAR, NEAR PROTOCOL... - Page 18 PROPERTY CAMERA ID 1 PROPERTY 0~255 You can define the camera ID no. from 0~255 CAMERA ID TITLE TITLE(1-) DISPLAY NONE (1-) After setting the camera ID, you also can make the PROTOCOL PELCO-D title for each camera ID no. Title is total 8 figures BAUDRATE 9600 BPS RETURN...
- Page 19 EXPOSURE BRIGHTNESS 2 EXPOSURE 0~20 You can adjust the brightness. Higher number means brighter images. BRIGHTNESS The default is 10. SHUTTER AUTO SHUTTER RETURN AUTO It’s a defualt. Shutter speed is adjusted properly. MANUAL Shutter speed is selectable from 1/30 ~ 1/60000 but it’s related to the menu LENS-MODE.
- Page 20 LENS LENS TYPE 3 LENS AF mode is supported for Auto Focus Lens. AF LENS DC mode is supported for Auto-iris Varifocal lens. DC LENS LENS TYHPE AF LENS Manual mode is supported for Manual iris or Fixed MANUAL MODE DEBLUR120 board lens.
- Page 21 LENS FOCUS MODE AUTO When using Auto Focus Lens, Focus can be adjusted automatically. Also, you can set-up the TIMER to repeat the automatic focusing after finishing the installation. TIMER is OFF and from 1 ~ 10min. If you want to adjust the focus manually, select MANUAL mode. MANUAL In this case, TIMER menu will be changed to FOCUSING and you can adjust the focus Far / Near.
- Page 22 FUNCTION DZOOM 0~112 Digital Zoom function (Level 0~112) 4 FUNCTION DZOOM AUTO AUTO White Balance is automatically adjusted. PRIVACY MIDDLE AUTO_H White Balance is automatically adjusted in the MOTION condition of Color temperature is high. RETURN White Balance is automatically adjusted in the AUTO_L condition of Color temperature is low.
- Page 23 FUNCTION PRIVACY You can hide some parts of the screen for privacy masking. Total 30 different OFF / ON privacy zone maskings are available. PRIVACY ZONE NO 30 different privacy masking zones are available. ZONE OP Zone Display. ON/OFF ZONE NO 0~29 X-POS X-Position (0~57)
- Page 24 IMAGE CHROMA 5 IMAGE 0~20 It’s color chroma level 0~20. The default is 7. CHROMA SHARPNESS SHARPNESS MIRROR 0~10 It’s to make the image sharper. FLIP High number means sharper image. The default is 10. E-Edge HLMASK MIRROR CONTRAST NORMAL COLOR SET COLOR1 ON/OFF...
- Page 25 IMAGE CONTRAST NORMAL/ HIGH/ HIGHEST You can adjust the contrast level - Normal, High, and Highest. COLOR Color 1 is the default. If the color reproduction on the monitor is not COLOR 1,2,3 satisfied, try other modes - Color 2 or 3. There are total 3 different color display Color 1,2, and 3.
- Page 26 WDR/BLC MAX-DR OFF/ ON MAX Dynamic Range provides clear images 6 WDR/BLC even when strong backlighting is present. Select MAX-DR ON or OFF. MAX DR MODE MODE WDR_WGT BLC OSD OFF/ BLC/ WDR BLC POS-X BLC - Back Light Compensation Mode BLC POS-Y WDR - Wide Dynamic Range (15fps Only) BLC SIZ-X...
- Page 27 DAY&NIGHT TDN MODE 7 DAY&NIGHT AUTO The camera switches between day and night COLOR automatically depending on the certain light level. BW to C C to BW COLOR The camera always stays at day mode. CDS SET BW LOW RETURN The camera always stays at night mode.
- Page 28 SETUP DEFECT DET OFF / ON Dead Pixel Cancellation automatically removes 8 SETUP defective pixels. Note : It’s not recommand to use from the customer side. DEFECT DET 2.0M MODE 1080P 2.0M MODE 720P MODE 60/50FPS 1080P / 720P 1080P is the default. If you want to have low LANGUAGE TDN TEST TEST OFF...
- Page 29 TROUBLESHOOTING Before sending your camera for repair, check the following or contact one of our technical specialists. No VIDEO Check the coaxial cable and make sure it is connected securely. Check the osd menu setup of the camera. Check the power supply and make sure the camera has the proper voltage and current. Out-of-Focus VIDEO Check the clear dome cover and the lens for dirt or fingerprints.
-
Page 30: Specifications
SPECIFICATIONS* MODEL CLEBO-HD AOD-2301 (IR) GENERAL SPEC CMOS TYPE 1/2.8" 2.0M Pixels Color Pixels 2000 (H) x 1241(V) 1920x1030 pixels (at COLOR) 30fps Resolution 1920x1030 pixels (at TDN-BW) 30fps Min illumination 0.1Lux [(F1.6, 30IRE), (at COLOR)] (F1.6, 30IRE) 0.01Lux [(F1.6, 30IRE), (at TDN(B/W)]...
