- Page 1 High Defini n Digital Set Top Box MPF3574HU INSTRUCTIONS MANUAL SAVE THESE INSTRUCTIONS IN A SAFE PLACE FOR FUTURE REFERENCE...
- Page 2 Important Safety Instructions 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with dry cloth. 7) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
- Page 3 This symbol indicates that dangerous voltages constituting a risk of electric shock are present within this unit. This symbol indicates that there are important operating and maintenance instructions in the literature according this unit. This symbol indicates that this product incorporate& double insulation between hazardous mains voltage and user accessible parts.
-
Page 4: Table Of Contents
Table of Contents Front and Rear Panel ………………………………………………………………………………5 Remote Control ……………………………………………………………………………………6 Connecting to a Television…………………………………………………………………………8 First Time Installation ……………………………………………………………………………9 Troubleshooting …………………………………………………………………………………20... -
Page 5: Front And Rear Panel
Front and Rear Panel 1. Front panel 2.Rear panel... -
Page 6: Remote Control
Remote Control 1.MUTE 2.FAV 3.SUBTITLE 4.<0>-<9> 5.MENU 6.OK/CH+/CH-/VOL-/VOL+ 7.PAGE- 8.REW/FWD 9.TV SETUP:POWER/SET/TV/AV/VOL-/VOL+ 10.PLAY 11.PAUSE 12.RECORD 13.EPG 14.USB 15.ASPECT 16.POWER 17.TTX 18.INFO 19.RECALL 20.GOTO 21.EXIT 22.PAGE+ 23.PREV/NEXT 24.AUDIO 25.STOP 26.REPEAT 27.TV/RADIO 28.TIMER 29.V-FORMAT Programming the remote control The decoder's remote control has 4 programmable keys via learning mode. For each of these keys, you can copy the functions in some buttons on the TV remote control. - Page 7 Installing the Batteries Remove the battery cover from the rear of the Remote Control and place 2xAAA size batteries inside the compartment. Please make sure the battery polarities match the polarity markings inside the compartment.
-
Page 8: Connecting To A Television
Connec ng to a Television Antenna RF cable Make the connec ons as shown in the figure. -
Page 9: First Time Installation
First Time Installation After all connections have been made properly, switch on TV and make sure the unit is connected to the Main Power. Press Power button to switch the unit on. If you are using the unit for the first time or have restored the unit to factory default, the installation guide menu will appear on your TV screen. - Page 10 Set Favorite Channels You can create a short list of favorite programs that you can easily access. Set Favorite TV or Radio program: 1.Select your desired channel then press the FAVOURITE button. Choose a category to assign the channel and confirm with OK button. 2.Repeat the previous step to select more Favorite channels.
- Page 11 First Time Installa on Lock a TV or Radio channel: 1.Select the preferred channel then press the YELLOW bu on. A lock-shaped symbol is displayed. The channel is now marked as locked. 2.Repeat the previous step to select more channels. 3.To confirm your se ngs and exit the menu, press the EXIT bu on.
- Page 12 (c).Sort [By Service Name] - Sort the channels in alphabe cal order. [By Service ID] - Sort the channels according to the sta on. [By ONID] - Sort the channels according to ONID. (d) LCN (Logical channel number) Set LCN on or off (suggested as ON) (2).Picture Se ng To access the Menu, press MENU then select [Picture] using the RIGHT/LEFT key.
- Page 13 First Time Installation (3)Channel Search To access the menu, press MENU and select [Search Channel] using the RIGHT/LEFT keys. This menu provides options to adjust the search channel settings. Press UP/DOWN to select an option and press RIGHT/LEFT to adjust the setting. Press EXIT to exit the menu.
- Page 14 2.Press the RIGHT/LEFT key to select the channel frequency. 3.Press OK to start searching channels. If a channel is found, it is saved and added to the channels list. If channels can not be found during searching, the unit will exit automatically. (c) Country Select your country of residence.
- Page 15 (a) OSD (On Screen Display) Language Select an OSO language. (b) Digital Audio Select the digital audio for watching TV channels. [PCM], [RAW HDMI ON], [RAW HDMI OFF], [OFF]. (6).System Setting To access the menu, press MENU and select [System] using the RIGHT/LEFT keys. The menu provides options to adjust the system settings.
- Page 16 (a) Parental control When DVB-T box is used by children it is possible to block certain programs, which are for adults. NOTE: this func on must be supported by the channel. (b) Set Password Set or change the password for locked programs. Enter your old password or the default password ‘000000’...
- Page 17 (a) Multimedia: When a USB device is attached you can select from the Music, Photo, Movie or REC opitons in this menu using the RIGHT/LEFT keys and OK to select. If a USB device is not connected, the warning message “No USB device is Found” will appear. (b) Photo Configure: -Slide Time: adjust slide show interval to 1-8 seconds.
- Page 18 Sub tle Font Color: [Red]: Displays Sub tle in red font. [Blue]: Displays Sub tle in blue font. [Green]: Displays Sub tle in green font. [White]: Displays Sub tle in white font. [Black]: Displays Sub tle in black font. (d)PVR Configure -Record Device:View the device information.
- Page 19 •Select “OTHER RECORDING” in the “Mode” op on. •Press EXIT. A few seconds before star ng to record, a warning message with a count-down is displayed on screen, which will change to the programmed channel when the count-down ends. Once the recording has finished, a confirma on message appears on screen.
-
Page 20: Troubleshooting
When you are playing the program, you can insert the USB, and at any time you can press the [Time shift] button, the frame will be paused, and you may press the [PLAY] button after a second, it will start to timeshift now. - Page 21 Technical Specifica ons Item Sub Item Parameter 170～230MHz Input Frequency 470～860MHz Tuner RF Input Level -78～20dBm IF Band width 7MHz/8MHz Modula on QPSK, 16QAM, 64QAM MPEG4 AVC/H.264 HP@L4 Decoder Video Formats MPEG2 MP@ML.HL Video Video Formats 576P, 720P, 1080I, 4:3 and 16:9 Output Port HDMI(V1.4)/SCART MPEG-1/MPEG-2/layer...
- Page 22 NOTICE ABOUT RECYCLING Your product is designed and manufactured with high quality materials and components which can be recycled and reused. This symbol means that electrical and electronic equipment, at their end-of-life, should be disposed of separately from your household waste. Please dispose of this equipment at your local community waste collection/ recycling centre.
