User's Manual
Under Cabinet Series
VEHOOD3610
NOTE: PLEASE INSPECT HOOD
IMMEDIATELY UPON RECEIVING.
CLAIM OF DAMAGE AFTER 7 DAYS
OF DELIVERY WILL BE DENIED.
This unit is designed for indoor
residential use only. DO NOT USE
OVER A WOOD GRILL OR MOUNT
IN OUTDOOR ENVIRONMENT.
Please read this manual thoroughly before installing
your range hood. Store it in a safe location for when
you need to reference it in the future.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Verona Under Cabinet Series
Summary of Contents for Verona Under Cabinet Series
- Page 1 User’s Manual Under Cabinet Series VEHOOD3610 NOTE: PLEASE INSPECT HOOD IMMEDIATELY UPON RECEIVING. CLAIM OF DAMAGE AFTER 7 DAYS OF DELIVERY WILL BE DENIED. This unit is designed for indoor residential use only. DO NOT USE OVER A WOOD GRILL OR MOUNT IN OUTDOOR ENVIRONMENT.
-
Page 2: Table Of Contents
EPLACEMENT ................15 IRING IAGRAM ............. 16-17 ARRANTY ONTACT Verona Hood VEHOOD3610 can be installed using outside venting or by use of a re-circulating kit. HOOD SPECIFICATIONS 36” W x 10” H x 22” D 600 CFM ... -
Page 3: Safety Information
SAFETY INFORMATION SAFETY INFORMATION TO REDUCE THE RISK OF A FIRE, ELECTRICAL SHOCK, AND/OR INJURY OBSERVE THE FOLLOWING: Unit is intended for indoor residential use only. If you should have questions, contact the manufacturer at the address or telephone number listed in the warranty. - Page 4 SAFETY INFORMATION TO REDUCE THE RISK OF FIRE, OR ELECTRIC SHOCK, DO NOT USE THIS FAN WITH ANY SOLID-STATE SPEED CONTROL DEVICE. Regardless of heat level, never leave any surface materials unattended while operating an open flame. Always turn hood ON when cooking at high heat. ...
-
Page 5: Content Checklist
CONTENT CHECKLIST CONTENTS INCLUDED (1) VEHOOD3610 - 36” hood assembly (1) User’s manual (1) Black 6” collar & (1) 6” – 7” Transition (3) Mesh filters (1) Screw packet CONTENTS NOT INCLUDED Recirculation Kit (Purchased separately) 6” or 7” Metal ducting TOOLS REQUIRED (NOT INCLUDED) Safety gloves Safety glasses... -
Page 6: Measurements
MEASUREMENTS Fig. 1a Keyhole 2 ¼” from Rear 16 ⅝” from Center Centerline 10 ⅜” from Rear Electrical Opening 17 ⅞” 1 ⅞” from Rear 13 ⅝” from Center 24”-36”... -
Page 7: Preparation
PREPARATION BEFORE YOU START **DO NOT INSTALL IF DAMAGED** **RETURN OR EXCHANGE WILL BE DENIED IF INSTALLED** Confirm you have all parts and required tools for this installation. Installation may take at least 2 to 3 hours from start to finish. Minimize the number of duct elbows (turns) used to maximize hood performance Duct elbows should be no closer than 12”... - Page 8 PREPARATION Use Fig. 1a and 1b on page 5 for measurements Electrical Opening 1 ⅞” from Rear 13 ⅜” from Centerline Center Line Install wood strips to level if cabinet bottoms are recessed. Cabinet opening for exhaust should be 6½” diameter if using collar ONLY ...
-
Page 9: Installation
INSTALLATION 1. UNDER CABINET OR SOFFIT INSTALLATION Make sure all preparation steps are completed. Connect 6” black collar to hood. (1) Using screws provided If using transition, connect transition with damper to 6” black collar, wider part to front (2) Secure collar and transition with sheetmetal screws and/or duct tape for an air-tight seal. - Page 10 INSTALLATION 3. ELECTRICAL CONNECTION Electrical Connection can be done by installing an outlet in the cabinet and securing a plug onto the wires from hood or bringing wires into hood as shown below. Verify that power is turned off at the source. Make electrical connections with wire nuts (Purchased Separately) as shown.
-
Page 11: R E - Circulating Kit (Option ) Installation
Optional Recirculation Kit * Installation Electrical Opening 1-3. Optional Recirculating Kit Purchased Separately from your Dealer Place Recircutating Vent under cabinet and mark position of holes allowing for unit to slide back in the keyhole slots. (1) Drive screws into underside of cabinet leaving a ⅛” protrusion. Install metal vent to underside of cabinet onto mounting screws and slide back to rear wall. -
Page 12: Operation & Features
OPERATION & FEATURES EASY ACCESS CONTROL SWITCH (from left to right) Button 0 – Fan Off Button 1 – Low 0 1 2 3 Button 2 – Medium Button 3 – High Light On/Off Control MESH FILTERS (3) 10-3/4”... -
Page 13: Cleaning & Maintenance
CLEANING & MAINTENANCE WARNING!!! To prevent the possibility of a fire and explosion, do not use flammable liquids or solvents to clean the unit or any of its parts. Check to make sure all power sources are disconnected before servicing or taking unit apart for cleaning. Please thoroughly clean the unit weekly RANGE HOOD Use household cleaner to remove grease or dirt from the outer shell... -
Page 14: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING WARNING!!! Check to make sure all power sources are disconnected before starting any troubleshooting. Safety gloves and glasses should be worn when working on the unit. Serious injury or death may occur if safety precautions are not followed. VEHOOD3610 Series 1. -
Page 15: Parts List / Replacement
Parts / Replacement & Wiring Diagram PARTS LIST Item Name Part Number B101-7236-09 Spacer B101-7236-06 Lamp Panel LED Lamp C1-0403-0306 Switch C1-0405-0303 Capacitor C1-0401-A250-22 LED Driver C1-0402-D001 Motor / Blower C1-0302-A110-06A Aluminum Filter C1-0604-0107 Recirculating Kit RK36 (Optional) Charcoal Filters for C1-0603-0303 Recirculating Kit How to Order Parts... -
Page 16: Wiring Diagram
Parts / Replacement & Wiring Diagram... -
Page 17: Warranty / Contact Us
For a period of one (1) year from the date of purchase, if the product is determined to be defective, Verona will attempt to repair the product, at its option, at no charge. After the warranty period, customer must pay for all labor charges. - Page 18 Damage resulting from natural disasters (earthquake, flood, storm, etc.) Aluminum Filters, Charcoal Filters and Light Bulbs CONTACT US Verona 41 Mercedes Way, Suite 25 Edgewood, NY 11717 TEL: (866) 844 - 6566 FAX: (631) 254 - 3426 E-mail: info@veronaappliances.com...
