- Page 1 Laptop Thin HDD 7200 RPM SATA Product Manual Standard models Self-Encryption models ST500LM021 ST500LM023 ST320LM010 SED FIPS 140-2 models ST500LM024 100737930, Rev. H Gen 3.0 - September 2017...
- Page 2 Seagate, Seagate Technology and the Wave logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. Momentus and SeaTools are either trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. The FIPS logo is a certification mark of NIST, which does not imply product endorsement by NIST, the U.S., or Canadian governments.
-
Page 3: Table Of Contents
Seagate® Technology Support Services ........ - Page 4 S.M.A.R.T. commands ............. .33 Seagate Laptop Thin HDD Product Manual, Rev. H...
- Page 5 Example of FIPS tamper evidence labels............22 Seagate Laptop Thin HDD Product Manual, Rev. H...
-
Page 6: Seagate® Technology Support Services
For information regarding online support and services, visit: http://www.seagate.com/contacts/ For information regarding Warranty Support, visit: http://www.seagate.com/support/warranty-and-replacements/ For information regarding data recovery services, visit: http://www.seagate.com/services-software/recover/ For Seagate OEM, Distribution partner and reseller portals, visit: http://www.seagate.com/partners/ Seagate Laptop Thin HDD Product Manual, Rev. H... -
Page 7: Introduction
Introduction This manual describes the functional, mechanical and interface specifications for the following Seagate® Laptop Thin HDD model drives: Standard models Self-Encryption models SED FIPS 140-2 models ST500LM021 - 1KJ152 ST500LM023 - 1RR152 ST500LM024 - 1RS152 ST320LM010 - 1KJ15C Previous generations of Seagate Self-Encrypting Drive models were called... -
Page 8: Drive Specifications
40.0°C max (nonoperating) Altitude, operating –304.8 m to 3048 m (–1000 ft to 10,000+ ft) Altitude, nonoperating –304.8 m to 12,192 m (–1000 ft to 40,000+ ft) (below mean sea level, max) Seagate Laptop Thin HDD Product Manual, Rev. H... -
Page 9: Formatted Capacity
512 (logical) / 4096 (physical) 320GB model 320 GB 625,142,448 One GB equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment and formatting. Seagate Laptop Thin HDD Product Manual, Rev. H... -
Page 10: Lba Mode
69.85 +/- 0.25 mm (2.750 +/- 0.010 in) All models Length 100.35 +0.20 / -0.25 mm (3.951 +0.008 / -0.010 in) Typical weight <95 g (0.209 lb) Cache buffer 32 MB (32,384 KB) Seagate Laptop Thin HDD Product Manual, Rev. H... -
Page 11: Seek Time
Idle mode power is measured with the drive up to speed, with servo electronics active and with the heads in a random track location. Standby mode • During standby mode, the drive accepts commands, but the drive is not spinning, and the servo and read/write electronics are in power-down mode. Seagate Laptop Thin HDD Product Manual, Rev. H... - Page 12 Standby power is measured at steady state (after 200ms from transition) 2.7.1.1 Typical current profiles The typical 5V startup and operation current profile is shown in Figure Figure 1 Typical 5V Startup and Operation Current Profile Seagate Laptop Thin HDD Product Manual, Rev. H...
-
Page 13: Conducted Noise
If the standby timer reaches zero before any drive activity is required, the drive makes a transition to standby mode. In both Idle and standby mode, the drive accepts all commands and returns to active mode when disk access is necessary. Seagate Laptop Thin HDD Product Manual, Rev. H... -
Page 14: Environmental Specifications
The nonoperating shock level that the drive can experience without incurring physical damage or degradation in performance when subsequently put into operation is 1000 Gs based on a nonrepetitive half-sine shock pulse of 1 ms duration. Seagate Laptop Thin HDD Product Manual, Rev. H... -
Page 15: Vibration
Test for prominent discrete tones (PDTs) Seagate follows the ECMA-74 standards for measurement and identification of PDTs. An exception to this process is the use of the absolute threshold of hearing. Seagate uses the lower limit for the threshold curve* to discern tone audibility and to compensate for the inaudible components of sound prior to computation of tone ratios according to Annex D of the ECMA-74 standards. -
Page 16: Electromagnetic Immunity
From this page, click on the “Is my Drive under Warranty” link. The following are required to be provided: the drive serial number, model number (or part number) and country of purchase. The system will display the warranty information for the drive. Seagate Laptop Thin HDD Product Manual, Rev. H... -
Page 17: Agency And Safety Certifications
Seagate drives are tested in representative end-user systems. Although CE-marked Seagate drives comply with all relevant regulatory requirements and standards for the drives, Seagate cannot guarantee that all system-level products into which the drives are installed comply with all regulatory requirements and standards applicable to the system-level products. The drive is designed for operation inside a properly designed system (e.g., enclosure designed for the drive), with properly shielded I/O cable (if... -
Page 18: Morocco Commodity Mark
2.12.6 Morocco Commodity Mark To satisfy our OEM customers, Seagate has added the Moroccan Commodity Mark to the drives provided to the OEM for the sale of Customer Kits produced by our OEM customers that are intended to be incorporated into the OEM's finished system-level product by an end user. -
Page 19: Environmental Protection
2.13.1.1 Restriction of Hazardous Substances in Electrical and Electronic Equipment Seagate drives are designed to be compliant with the European Union RoHS "Recast" Directive 2011/65/EU (RoHS 2) as amended by Directive (EU) 2015/863. The RoHS2 restricts the use of certain hazardous substances such as Lead, Cadmium, Mercury, Hexavalent Chromium, Polybrominated Biphenyls (PBB) and Polybrominated Diphenyl Ether (PBDE), BisBis(2-Ethylhexyl) phthalate (DEHP), Benzyl butyl phthalate (BBP), Dibutyl phthalate (DBP), and Diisobutyl phthalate (DIBP) in electrical and electronic equipment (EEE). -
Page 20: Taiwan Requirements - Taiwan Rohs
Users should use caution exposing any electronic components to uncontrolled chemical pollutants and corrosive chemicals as electronic drive component reliability can be affected by the installation environment. The silver, copper, nickel and gold films used in Seagate products are especially sensitive to the presence of sulfide, chloride, and nitrate contaminants. Sulfur is found to be the most damaging. In addition, electronic components should never be exposed to condensing water on the surface of the printed circuit board assembly (PCBA) or exposed to an ambient relative humidity greater than 95%. -
Page 21: Configuring And Mounting The Drive
Figure Figure 2 Attaching SATA Cabling Signal connector Power connector Signal cable Power cable Each cable is keyed to ensure correct orientation. Laptop Thin HDD drives support latching SATA connectors. Seagate Laptop Thin HDD Product Manual, Rev. H... -
Page 22: Drive Mounting
6.81 ± .203 mm 2X .118 in 2.99 mm BOTH SIDES .230 in 3.567 in 5.84 mm 90.60 mm .551 in 13.99 mm .263 in 6.68 mm 2.430 in 61.72 mm .160 in 4.06 mm Seagate Laptop Thin HDD Product Manual, Rev. H... -
Page 23: About Fips
Figure 4 Example of FIPS tamper evidence labels. For reference only. May not represent actual drive. Note Seagate Laptop Thin HDD Product Manual, Rev. H... -
Page 24: About (Sed) Self-Encrypting Drives
The Trusted Computing Group (TCG) is an organization sponsored and operated by companies in the computer, storage and digital communications industry. Seagate's SED models comply with the standards published by the TCG. To use the security features in the drive, the host must be capable of constructing and issuing the following two SATA commands: Trusted Send •... -
Page 25: Random Number Generator (Rng)
In addition to providing a locking mechanism to prevent unwanted firmware download attempts, the drive also only accepts download files which have been cryptographically signed by the appropriate Seagate Design Center. Three conditions must be met before the drive will allow the download operation: 1. -
Page 26: Serial Ata (Sata) Interface
There are three power pins for each voltage. One pin from each voltage is used for pre-charge when installed in a blind-mate backplane configuration. All used voltage pins (V ) must be terminated. Seagate Laptop Thin HDD Product Manual, Rev. H... -
Page 27: Supported Ata Commands
Set Max Features register as defined to the right. Password: Lock: Unlock: Freeze Lock: Set Max Address Ext Set Multiple Mode S.M.A.R.T. Disable Operations B0h/D9h S.M.A.R.T. Enable/Disable Autosave B0h/D2h Seagate Laptop Thin HDD Product Manual, Rev. H... - Page 28 ATA-standard power-management commands Check Power Mode Idle Idle Immediate Sleep Standby Standby Immediate ATA-standard security commands Security Set Password Security Unlock Security Erase Prepare Security Erase Unit Security Freeze Lock Security Disable Password Seagate Laptop Thin HDD Product Manual, Rev. H...
-
Page 29: Identify Device Command
Number of current logical heads xxxx Number of current logical sectors per logical track xxxx 57–58 Current capacity in sectors xxxx Number of sectors transferred during a xxxx Read Multiple or Write Multiple command Seagate Laptop Thin HDD Product Manual, Rev. H... - Page 30 Hardware reset value (see description following this table) xxxx Auto acoustic management setting xxxx Stream Min. Request Size 0000 Streaming Transfer Time - DMA 0000 Streaming Access Latency - DMA and PIO 0000 98-99 Streaming Performance Granularity 0000 Seagate Laptop Thin HDD Product Manual, Rev. H...
- Page 31 0000 Transport major version number 101F 223–254 ATA-reserved 0000 Integrity word xxA5 See the bit descriptions below for words 63, 88 and 93 of the Identify Drive data. (on next page) Note Seagate Laptop Thin HDD Product Manual, Rev. H...
- Page 32 Ultra DMA mode 5 is currently active. Ultra DMA mode 6 is currently active. Word 93 1 = 80-conductor cable detected, CBLID above VIH 0 = 40-conductor cable detected, CBLID below VIL Seagate Laptop Thin HDD Product Manual, Rev. H...
-
Page 33: Set Features Command
Disable the Free Fall Protection feature (41 above enables the Free Fall Protection feature) Report full capacity available At power-on, or after a hardware or software reset, the Note default values of the features are as indicated above Seagate Laptop Thin HDD Product Manual, Rev. H... -
Page 34: Commands
) that eliminates unnecessary drive returns. The diagnostic software ships with all new drives and is also available at: http://www.seagate.com/support/downloads/seatools/. This drive is shipped with S.M.A.R.T. features disabled. Users must have a recent BIOS or software package that supports S.M.A.R.T. to enable this feature. - Page 35 ASIA/PACIFIC Seagate Singapore International Headquarters Pte. Ltd. 7000 Ang Mo Kio Avenue 5, Singapore 569877, 65-6485-3888 EUROPE, MIDDLE EAST AND AFRICA Seagate Technology SAS 16-18 rue du Dôme, 92100 Boulogne-Billancourt, France, 33 1-4186 10 00 Publication Number: 100737930, Rev. H...
