VANITY WITH TOP
MODEL #1605VA-48-201-925
1
•
inspiring
ITEM #2694504
Français p. 11
Español p. 21
Advertisement
Table of Contents
Related Manuals for Allen + Roth 1605VA-48-201-925
Summary of Contents for Allen + Roth 1605VA-48-201-925
- Page 1 • sophisticated • inspiring ALLEN + ROTH and logo design are trademarks or registered ITEM #2694504 trademarks of LF, LLC. All rights reserved. VANITY WITH TOP MODEL #1605VA-48-201-925 Français p. 11 Español p. 21 ATTACH YOUR RECEIPT HERE Serial Number__________________ Purchase Date__________________ Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-866-439-9800, 8 a.m.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Package Contents...........................3 Hardware Contents..........................3 Safety Information..........................3 Preparation............................4 Assembly or Installation Instructions ....................4 Care and Maintenance........................9 Warranty............................9 Replacement Parts List........................10... -
Page 3: Package Contents
PACKAGE CONTENTS PART DESCRIPTION QUANTITY Vanity Top (preassembled to vanity (A)) Backsplash Left Door (preassembled to Vanity (A)) Right Door (preassembled to Vanity (A)) Shelf HARDWARE CONTENTS (NOT SHOWN ACTUAL SIZE) Touch Up Pen Qty. 1 SAFETY INSTRUCTIONS Please read and understand this entire manual before attempting to assemble, operate or install the product. -
Page 4: Preparation
PREPARATION Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product. Estimated Installation Time: 35 minutes (24 hours for silicone caulk to dry). Tools Required for Installation (not included): Phillips screwdriver, utility knife or scissors, silicone caulk, power drill with drill bit Helpful Tools (not included): Measuring tape, level... - Page 5 INSTALLATION INSTRUCTIONS 2. To remove drawers preassembled in vanity (A), fully extend drawers. Locate plastic levers on metal glide tracks at left and right sides of drawer box. To disengage drawer box from glides, push on plastic levers. Then, gently lift drawer up to remove it from vanity (A).
- Page 6 INSTALLATION INSTRUCTIONS Note: A t this stage it may be easier to install the faucet and drain kit (not included) to top (B) per the manufacturer’s instructions, before moving on to Step 4. 4. Apply stain free silicone caulk (not included) to the top edge of vanity (A).
- Page 7 INSTALLATION INSTRUCTIONS 6. To reinstall drawers into vanity (A), fully extend metal glide tracks. Gently lower and slide drawer box into rear glide catch. Next lower drawer box down to completely rest on extended glides. Then, push plastic levers to lock the drawer box in place.
- Page 8 INSTALLATION INSTRUCTIONS 8. If you need to adjust the doors, do so in the following manner. To adjust door up or down, loosen screws (a) on both hinges, adjust door, and retighten screws. To adjust door left or right, turn screws (b) on both hinges, in or out. To adjust door in or out, loosen screws (c) on both hinges, adjust door, and retighten screws.
-
Page 9: Care And Maintenance
CARE AND MAINTENANCE • Dust the vanity regularly with a soft, non-lint producing cloth or household dusting product. • You can clean the vanity with a gentle, non-abrasive household cleaner. • Make sure to dry the wood immediately with a soft cloth or towel. •... -
Page 10: Replacement Parts List
1605VA-48-201-SHELF Touch-up pen OF-0010 Shelf Pin B1044 Pull (with screw) 1605VA-201-BN HANDLE Drawer glide set PUDTC-14X3-HANDLE Printed in Vietnam Hinge C-90-108-5 ALLEN + ROTH and logo design are trademarks or registered Leveler T-1007 trademarks of LF, LLC. All rights reserved.
