- Page 1 OWNER’S MANUAL MICROWAVE OVEN PLEASE READ THIS OWNER’S MANUAL THOROUGHLY BEFORE OPERATING. MC7647B MC7647BS MC-7847B MC-7847BS MC7847BS www.lg.com P/No. : MFL38119702...
- Page 3 Precautions Precautions to avoid possible exposure to excessive microwave energy. You cannot operate your oven with the door open due to the safety interlocks When heating liquids, e.g. soups, sauces and beverages in your microwave built into the door mechanism. These safety interlocks automatically switch off oven, delayed eruptive boiling can occur without evidence of bubbling.
-
Page 4: Table Of Contents
Contents How the Microwave Oven Works Precautions Contents Microwaves are a form of energy similar to radio and television waves and Unpacking & Installing ordinary daylight. Normally, microwaves spread outwards as they travel Setting the Clock through the atmosphere and disappear without effect. Microwave ovens, Child Lock however, have a magnetron which is designed to make use of the energy in Micro Power Cooking... -
Page 5: Unpacking & Installing
Unpacking & By following the basic steps on these two pages you will be able to quickly check that your oven is operating correctly. Please pay particular attention to the guidance on where to install your oven. W hen unpacking your Installing oven make sure you remove all accessories and packing. - Page 6 O pen your oven door by pulling the DOOR HAN DLE. Plug your oven into a standard household Place the ROTATIN G RIN G inside the oven and place the socket. Make sure your oven is the only GLASS TRAY on top. appliance connected to the socket.
-
Page 7: Setting The Clock
Setting the You can set either12 hour clock or 24 hour clock. Clock In the following example I will show you how to set the time for 14:35 when using the 24 clock. Make sure that you have removed all packaging from your oven. Make sure that you have correctly installed your oven as described earlier in this book. -
Page 8: Child Lock
Child Lock Press STOP/CLEAR. Your oven has a safety feature that Press and hold STOP/CLEAR until “L” appears on the display and BEEP sounds. prevents accidental running of the oven. The CHILD LOCK is now set. Once the child lock is set, you will be unable to use any functions and no The time will disappear on the display but will reappear on cooking can take place. -
Page 9: Micro Power Cooking
Micro Power In the following example I will show you how to cook some food on 720 power for 5 minutes and 30 seconds. Cooking Make sure that you have correctly installed your oven as described earlier in this book. Press STOP/CLEAR. - Page 10 Micro Power Your microwave oven is equipped with 5 power levels to give you maximum flexibility and control over Level cooking. The table below shows the examples of food and their recommended cooking power levels for use with this microwave oven. OUTPUT POWER LEVEL 900W...
-
Page 11: Two Stage Cooking
Two stage Cooking In the following example I will show you how to cook some food in two stages. The first stages will cook your food for 11 minutes on HIGH; the second will cook for 35 minutes on 360 power. Press STOP/CLEAR. -
Page 12: Quick Start
Quick Start In the following example I will show you how to set 2 minutes of cooking on high power. Press STOP/CLEAR. Press QUICK START four times to select 2 minutes on HIGH power. The QUICK START feature allows you to Your oven will start before you have finished the fourth press. -
Page 13: More Or Less Cooking
More or Less In the following example I will show you how to change the preset AUTO COOK programmes for a Cooking longer or shorter cooking time. Press STOP/CLEAR. Set the required AUTO COOK programme. If you find that your food is over or * See AUTO COOK (page 24) undercooked when using the AUTO Select weight of food. -
Page 14: Grill Cooking
Grill In the following example I will show you how to use the grill to cook some food for 12 minutes and 30 seconds. Cooking Press STOP/CLEAR. This model is fitted with a SHEATH Press GRILL. HEATER, so preheating is not needed. This feature will allow you to brown and crisp food quickly. -
Page 15: Convection Cooking
Convection In the following example I will show you how to preheat the oven at a temperature of 230°C. Cooking 1. To preheat. Press STOP/CLEAR. Press CONVECTION. The convection oven has a temperature range of 40°C and 100°C~230°C (180°C is automatically available when convection mode is selected). - Page 16 Convection In the following example I will show you how to preheat the oven first, then cook some food at a Cooking temperature of 230°C for 50 minutes. 2. To cook. Press STOP/CLEAR. Press CONVECTION. If you do not set a temperature your oven will automatically select 180°C.
-
Page 17: Combination Cooking
Combination In the following example I will show you how to programme your oven with micro power 360 power and grill Cooking for a cooking time of 25 minutes. 1. GRILL COMBINATION. Press STOP/CLEAR. Press COMBI. Your oven has a combination cooking Press GRILL. - Page 18 Combination In the following example I will show you how to programme your oven with:- micro power 360 power and at a convection temperature 200°C for a cooking time of 25 minutes. Cooking 2. CONVECTION COMBINATION. Press STOP/CLEAR. Press COMBI. Press CONVECTION.
-
Page 19: Auto Defrost
The temperature and density of food varies, I would recommend that the food is checked before cooking Auto commences. Pay particular attention to large joints of meat and chicken, some foods should not be completely thawed before cooking. For example fish cooks so quickly that it is sometimes better to begin cooking while still slightly frozen. - Page 20 DEFROSTING GUIDE * Food to be defrosted should be in a suitable microwave proof container and place uncovered on the glass turntable. * If necessary, shield small areas of meat or poultry with flat pieces of aluminum foil. This will prevent thin areas becoming warm during defrosting. Ensure the foil does not touch the oven walls.
-
Page 21: Quick Defrost
Quick Use this function to thaw only 0.5kg of Minced meat very quickly. This will require a standing time to allow the center to thaw. In the following example will show you how to Defrost defrost 0.5kg of forzen minced meat. Press STOP/CLEAR. - Page 22 QUICK DEFROST GUIDE Use this function to defrost quickly for minced meat. Remove the meat completely from its wrapping. Place the mince onto a microwave-safe plate. When beeps, at this point remove the mince from the microwave oven, turn the mince over and return to the microwave oven. Press start to continue. At the end of the program remove the mince from the microwave oven, cover with foil and allow to stand 5-15 minutes or until completely thawed.
-
Page 23: Auto Cook
Auto In the following example I will show you how to cook 0.5kg of jacket potato . Cook Press STOP/CLEAR. AUTO COOK allows you to cook most of Press AUTO COOK once to select Jacket Potato. your favorite food easily by selecting the “Ac 1”... - Page 24 Function Category Weight Limit Utensil Food Temp. Instructions Auto Cook Jacket Potato ~ 1.0kg Metal tray Room Choose medium sized potatoes 200 -220g. Wash and dry potatoes. Pierce the potatoes several times with fork. Place the (Ac 1) potatoes on the metal tray. Adjust weight and press start. After cooking, remove the potatoes from the oven.
- Page 25 Function Category Weight Limit Utensil Food Temp. Instructions Frozen Pizza 0.1 ~ 0.5kg Low rack & Frozen This function is for cooking frozen pizza. Remove all package and place on Auto Cook low rack over the metal tray. Metal tray (Ac 6) After cooking, stand for 1~2 minutes.
-
Page 26: Auto Roast
Auto Roast In the following example I will show you how to cook 1.4kg of roast beef. Press STOP/CLEAR. AUTO ROAST cook allows you to cook Press AUTO ROAST once to select ROAST BEEF. most of your favorite food easily by “Ar 1”... - Page 27 AUTO ROAST GUIDE Function Category Weight Limit Utensil Food Temp. Instructions Auto Roast 0.5 ~ 1.5 kg Low rack & Refrigerated Brush the beef with melted margarine or butter. Place on the low rack Roast Beef (Ar 1) Metal tray over the metal tray.
-
Page 28: Important Safety Instructions
Important safety instructions WARNING Please ensure cooking times are correctly set as Read carefully and keep for future reference over cooking may result in FIRE and subsequent DAMAGE to the OVEN. 1 Do not attempt to tamper with, or make any adjustments or repairs to the 12 Before cooking, pierce the skin of potatoes, apples or any such fruit or door, control panel, safety interlock switches or any other part of the oven. -
Page 29: Read Carefully And Keep For Future Reference
Important safety instructions WARNING Please do not let the POWER Read carefully and keep for future reference CORD touch the BACK COVER. 33 Only use the temperature probe recommended for this oven (for 24 Only use utensils that are suitable for use in microwave ovens. appliances having a facility to use a temperature-sensing probe). -
Page 30: Microwave-Safe Utensils
Microwave-safe Utensils Never use metal or metal trimmed utensils in your Paper microwave oven Paper plates and containers are convenient and safe to use in your microwave oven, Microwaves cannot penetrate metal. They will bounce off any metal object in the provided that the cooking time is short and foods to be cooked are low in fat and oven and cause arcing, an alarming phenomenon that resembles lightning. -
Page 31: Food Characteristics& Microwave Cooking
Food characteristics& Microwave cooking Moisture content of food Keeping an eye on things Since the heat generated from microwaves tends to evaporate moisture, relatively dry food The recipes in the book have been formulated with great care, but your success in such as roasts and some vegetables should either be sprinkled with water prior to cooking preparing them depends on how much attention you pay to the food as it cooks. - Page 32 Food characteristics & Microwave cooking. Stirring Stirring is one of the most important of all microwaving techniques. In conventional cooking, To Clean Your Oven food is stirred for the purpose of blending. Microwaved food, however, is stirred in order to 1 Keep the inside of the oven clean spread and redistribute heat.
-
Page 33: Questions & Answers
Questions & Answers Q What’s wrong when the oven light will not glow? Q Is it possible to pop corn in a microwave oven? A There may be several reasons why the oven light will not glow. A Yes, if using one of the two methods described Light bulb has blown below Door is not closed... -
Page 34: Plug Wiring Information/Technical Specifications
Plug wiring information/ Technical Specifications Warning Technical Specification Technical Specification This appliance must be earthed MC7647B/ MC7647BS/ MC-7847B/ The wires in this mains lead are colored in accordance with the MC-7847BS/ MC7847BS following codes Power Input 230 V AC 50Hz...
