Smeg Concert SUK92CMX9 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
1. INSTRUCTIONS FOR USE ..................................................................................................... 4
2. SAFETY PRECAUTIONS ........................................................................................................ 6
3. ENVIRONMENTAL CARE ....................................................................................................... 8
3.1 Our environmental care .................................................................................................................................. 8
3.2 Your environmental care ................................................................................................................................. 8
4. GET TO KNOW YOUR APPLIANCE ....................................................................................... 9
4.1 Description of the controls on the front panel ............................................................................................... 10
5. AVAILABLE ACCESSORIES ................................................................................................. 11
5.1 Using the rack or tray .................................................................................................................................... 12
5.2 Using the support rack .................................................................................................................................. 12
6. USING THE COOKING HOB ................................................................................................. 13
6.1 General warnings and advice ....................................................................................................................... 13
6.2 Using the cooking zones ............................................................................................................................... 13
6.3 Residual heat indicator lights ........................................................................................................................ 13
7. USING THE OVEN ................................................................................................................ 14
7.1 Before using the appliance ........................................................................................................................... 14
7.2 Oven runners ................................................................................................................................................ 14
7.3 Storage compartment (on some models only) .............................................................................................. 14
7.4 Cooling system ............................................................................................................................................. 14
7.5 Internal light .................................................................................................................................................. 14
7.6 General warnings and advice for use ........................................................................................................... 15
7.7 Electronic programmer (on some models only) ............................................................................................ 16
8. COOKING WITH THE OVEN ................................................................................................ 18
8.1 Cooking advice and instructions ................................................................................................................... 19
8.2 Cooking information table ............................................................................................................................. 20
9. CLEANING AND MAINTENANCE ......................................................................................... 21
9.1 Cleaning stainless steel ................................................................................................................................ 21
9.2 Ordinary daily cleaning ................................................................................................................................. 21
9.3 Food stains or residues ................................................................................................................................. 21
9.4 Cleaning the glass ceramic hob .................................................................................................................... 22
9.5 Weekly cleaning ............................................................................................................................................ 22
9.6 Cleaning the oven ......................................................................................................................................... 23
9.7 VAPOR CLEAN: assisted oven cleaning (on some models only) ................................................................. 24
10. EXTRAORDINARY MAINTENANCE .................................................................................. 26
10.1 Replacing the light bulb (main oven) ........................................................................................................... 26
10.2 Replacing the light bulb (auxiliary oven) ..................................................................................................... 26
10.3 Removing the door ...................................................................................................................................... 27
10.4 Removing the door seal (not on pyrolitic models) ....................................................................................... 27
10.5 Removing the internal glass panels ............................................................................................................ 28
11. INSTALLATION .................................................................................................................. 29
11.1 Installing in kitchen units ............................................................................................................................. 29
11.2 Wall mounting brackets (where present) ..................................................................................................... 30
11.3 Electrical connection ................................................................................................................................... 31
11.4 Positioning the skirt (on some models only) ................................................................................................ 33
11.5 Positioning and levelling the appliance ....................................................................................................... 33
INSTRUCTIONS FOR THE USER: these contain user advice, the description of the controls and
the correct procedures for cleaning and maintenance of the appliance.
INSTRUCTIONS FOR THE INSTALLER: these are intended for the qualified technician who must
install the appliance, set it functioning and carry out an inspection test.
@
Further information about the products can be found at www.smeg.com
