Summary of Contents for Bruno ELECTRA-RIDE SRE-2000
- Page 1 SRE-2000 ELECTRA-RIDE™ ELITE STAIRWAY ELEVATOR Operator’s Manual Technical Service email: service@bruno.com www.bruno.com 1780 EXECUTIVE DR., P.O. BOX 84, OCONOMOWOC, WI 53066 USA TELEPHONE:(262) 567-4990 FAX: (262) 953-5501 1-800-882-8183 REV. 03-14-2007...
- Page 2 Bruno reserves the right to use comments indicated on this form in its on-line, video, audio and printed materials. Names will be abbreviated to ensure the privacy and anonymity of the individual. Best wishes from the Bruno Team.
-
Page 3: Table Of Contents
Warranty ....... . 19-20 ©2007,2001 Bruno Independent Living Aids, Inc.®... - Page 4 (armrest and two remotes) Maximum Incline: 45 degrees Seat Swivel: 0, 30 ,60 and 90 degrees, both directions, at top and bottom Power Supply: 24VDC battery charger powered by 120V outlet ©2007,2001 Bruno Independent Living Aids, Inc.® SRE-2000 Operator 03-14-2007...
-
Page 5: Safety
• Make sure the seat is locked in the correct riding position. • Be certain the seat swivel is locked in place before attempting to get on or off the stairway elevator. ©2007,2001 Bruno Independent Living Aids, Inc.® SRE-2000 Operator 03-14-2007... - Page 6 Only in the event of a prolonged power outage (more than one hour) will it be necessary to turn the power off (circuit breaker switch on the carriage) and unplug the charger from the wall outlet to conserve battery charge. ©2007,2001 Bruno Independent Living Aids, Inc.® SRE-2000 Operator 03-14-2007...
- Page 7 SRE-2000 ElEctRa-RiDE™ ElitE UP / DOWN rocker switch armrest swivel release positioning belt folding seat in riding position folding footrest with obstruction sensors ©2007,2001 Bruno Independent Living Aids, Inc.® SRE-2000 Operator 03-14-2007...
-
Page 8: Circuit Breaker
Reset it, if necessary. Possible causes of circuit breaker tripping: • foreign object jamming the rail or gear rack; • exceeding the rated weight capacity of the stairway elevator. ©2007,2001 Bruno Independent Living Aids, Inc.® SRE-2000 Operator 03-14-2007... -
Page 9: Seating
To lower the seat assembly from a folded, up position, simply push down on the seat UP/DOWN cushion to lower it to the riding position. rocker switch seat swivel (one on each armrest) ©2007,2001 Bruno Independent Living Aids, Inc.® SRE-2000 Operator 03-14-2007... -
Page 10: Operation
7. Press and hold the rocker switch (located stair rail, or until the switch is on the front edge of one of the armrests) released. to travel UP / DOWN the rail. ©2007,2001 Bruno Independent Living Aids, Inc.® SRE-2000 Operator 03-14-2007... - Page 11 10. Release the seat swivel lever and allow the seat to lock in this position. 11. Unbuckle the positioning belt and carefully exit the seat. ©2007,2001 Bruno Independent Living Aids, Inc.® SRE-2000 Operator 03-14-2007...
-
Page 12: Charging
Using the transmitter, call it back to the other end of the stairs when needed. ©2007,2001 Bruno Independent Living Aids, Inc.® SRE-2000 Operator 03-14-2007... - Page 13 SLOW BLINK SLOW BLINK batteries close to being fully charged batteries fully charged BLINK low voltage indication FAST BLINK battery defective or heavily sulfated ©2007,2001 Bruno Independent Living Aids, Inc.® SRE-2000 Operator 03-14-2007...
- Page 14 3. Twist the fuseholder cap and pull out to charger power switch remove the fuse. 4. Replace with the same size and type fuse: (BUSS # GSL 2) 5 x 20mm. ©2007,2001 Bruno Independent Living Aids, Inc.® SRE-2000 Operator 03-14-2007...
- Page 15 Transmitter Battery Replacement To replace the battery in the call/send transmitters, remove the access panel on the back of the trans- mitter. One 9V battery required. 9V battery (access panel removed) ©2007,2001 Bruno Independent Living Aids, Inc.® SRE-2000 Operator 03-14-2007...
- Page 16 TROUBLESHOOTING Your SRE-2000 is not operating correctly. What should you do? Before calling your Bruno dealer, refer to the solutions listed below. This could save you an unnecessary service call! • Seat swivel. Is the seat locked in the riding position? •...
-
Page 17: Battery Charger
• Visual check. Do you notice anything about your elevator that is different or out of place? If your SRE-2000 continues to function improperly or not at all after completing the preceding checklist, contact an authorized Bruno dealer to perform all required service, repair and maintenance operations. ©2007,2001 Bruno Independent Living Aids, Inc.®... -
Page 18: Vacation And Long-Term Storage
To recharge, simply turn on the circuit breaker, reconnect the charger to the wall outlet and wait until the charger LED’s indicate that the batteries are fully recharged. ©2007,2001 Bruno Independent Living Aids, Inc.® SRE-2000 Operator 03-14-2007... -
Page 19: Warranty
The exclusive remedy for a defect in a Bruno Stairlift shall be the repair or replacement, at the option of Bruno, of the defective part or component. After the irst 30 days of this war- ranty, only parts and components are covered. This warranty does not cover labor and other services after the initial 30 days. - Page 20 Bruno, damage in shipment, or repairs undertaken by anyone other than Bruno factory employees or authorized distributors. The “original purchaser” of a Bruno Stairlift that is leased or rented shall be the person or entity acting as the lessee or rental provider.
- Page 22 • • ©2006 Bruno Independent Living Aids, Inc. ® All illustrations and specifications in this brochure are based on the latest product information available at the time of publication. Bruno Independent Living Aids, Inc ® . reserves the right to make changes at any time without notice. Manual Back Cover 8/06-2.
