Thanks for purchasing our 72MHz assitive listening system. It helps millions of people
hear focused audio in places where sound matters most, especially in school and
churches where concentrations are needed. The 72MHz mini wireless audio system
allows multi-transmitters and multi-receivers to be used in the same field. Simply
plug the microphone or other audio sources into the MIC jack on the transmitters.
The person holding the receiver can choose the channel that they want to hear and
it can amplify the sound loud enough. They are very small, light-weighted and
user-friendly. All of our products re designed to provide many years of reliable
service.
We are commited to provide the best assistive listening system to the users who
have hearing problem.
This manual contains basic product information to ensure trouble free operation so
please take time to read through this manual thoroughly before using your new
assitive listening system.
Every Word.........Every Sound........Heard, Understood
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
Advertisement
Table of Contents
Related Manuals for ARG TX72M
Summary of Contents for ARG TX72M
- Page 1 All manuals and user guides at all-guides.com Thanks for purchasing our 72MHz assitive listening system. It helps millions of people hear focused audio in places where sound matters most, especially in school and churches where concentrations are needed. The 72MHz mini wireless audio system allows multi-transmitters and multi-receivers to be used in the same field.
- Page 2 All manuals and user guides at all-guides.com FCC Compliance Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
- Page 3 All manuals and user guides at all-guides.com Operations ARG-TX72M Transmitter Diagram Transmitter Programming Instructions POWER UP Switch the transmitter to ON position. The display will show the volume level for a seond then change to the Channel Number. The backlit turns off automatically after ten seconds.
- Page 4 In case the problem persists, please consult your dealer or ARG. Repairs In the event that there is need for a repair, please contact your dealer or ARG for a Return Authorization. Technical Specifications Frequency Range: 72.1-72.9MHz, 74.7MHz, 75.3 – 75.9MHz Modulation: Wide-band FM, 75 kHz pk Frequency Response: 200Hz to 13KHz, ±3 dB at 1% max.
- Page 5 All manuals and user guides at all-guides.com FREQUENCY CHART FREQ 72.1MHz 72.5MHz 72.9MHz 75.7MHz 74.7MHz 75.3MHz 75.9MHz 72.2MHz 72.3MHz 72.4MHz 72.6MHz 72.7MHz 72.8MHz 75.4MHz 75.5MHz 75.6MHz 75.8MHz...
