IMAGE 16i/ix

Operator's Manual

Manuel d'utilisation

Libro de Instrucciones

230V

READ THIS BOOK

This book has important information for the use and safe operation of this machine. Failure to read

this book prior to operating or attempting any service or maintenance procedure to your Clarke

Technology machine could result in injury to you or to other personnel; damage to the machine or

to other property could occur as well. You must have training in the operation of this machine before

using it. If your operator(s) cannot read this manual, have it explained fully before attempting to

operate this machine.

All directions given in this book are as seen from the operator's position at the rear of the machine.

For new books write to: ALTO U.S. INC., 2100 Highway 265, Springdale, Arkansas 72764.

Form No. 70340A

5/03

CLARKE TECHNOLOGY

Printed in the U.S.A.

Need help?

Do you have a question about the ALTO ErgoEX IMAGE 16i and is the answer not in the manual?

Questions and answers

Summary of Contents for Clarke Technology ALTO ErgoEX IMAGE 16i

Page 1 All directions given in this book are as seen from the operator’s position at the rear of the machine. For new books write to: ALTO U.S. INC., 2100 Highway 265, Springdale, Arkansas 72764. Form No. 70340A 5/03 CLARKE TECHNOLOGY Printed in the U.S.A.
Page 2 Section II - PARTS AND SERVICE MANUAL Authorized Personnel Maintenance ....................32 How to Correct Problems in the Machine ..................36 Authentic Clarke Technology Products ..................... 39 Final Assembly Drawing (Standard & Deluxe) ................... 40 Parts List ..........................41 Recovery Tank Assembly Drawings & Parts List ................42 Brush Housing Assembly Drawing &...
Page 3 Todas las indicaciones de dirección dadas en estre libro están dadas desde la posición del operador en la parte de atrás de la máquina. Puede Ud. conseguir libros suplementarios dirigiéndose a su distribuidor CLARKE TECHNOLOGY. INDICE PRIMERA PARTE: LIBRO DE INSTRUCCIONES Instrucciones de seguridad para el operador ....................
Page 4 Toutes les indications de direction figurant dans ce manuel sont visualisées depuis la position du conducteur, à l’arrière de la machine. Des manuels supplémentaires peuvent être obtenus auprès de votre revendeur CLARKE TECHNOLOGY. INDEX Instructions pour la sécurité du conducteur ................. 3 Introduction et caractéristiques techniques de la machine ............
Page 5 Electrocution or fire could occur if the machine is used on a power circuit that repeatedly trips or is undersized. Have a licensed electrician check the fuse, circuit breaker or power supply, and/or contact your local Clarke Technology distributor for assistance.
Page 6 Read all machine labels before attempting to operate. Make sure all of the labels and instructional information are attached or fastened to the machine. Get replacement labels and plates from your Clarke Technology distributor. WARNING: Always use a three-wire electrical system connected to the electrical ground. For maximum protection against electric shock, use a circuit that is protected by a ground fault circuit interrupter.
Page 7 Peligro de lesiones y daños materiales. Pare la máquina sólo en una superficie plana. Al parar la máquina, compruebe que todos los mandos estén en la posición ‘O’. CLARKE TECHNOLOGY Image 16 230V Operator's Manual Page 7...
Page 8 óptima contra los choques eléctricos, conecte la máquina con un circuito provisto de un desconectador de cortocircuitos con la tierra. Si tiene alguna duda o algún problema, sírvase acudir a un eléctrico cualificado y/o a su distribuidor Clarke Technology. ¡AVISO! Para reducir el peligro de choque eléctrico, use esta máquina sólo en alfombras...
Page 9 ! DANGER ! Ne jamais conduire la machine en se trouvant ailleurs qu’à l’arrière. Risque de blessures ou de dégâts matériels. Le conducteur doit toujours se trouver à l’arrière de la machine. CLARKE TECHNOLOGY Image 16 230V Operator's Manual Page 9...
Page 10 électriques, branchez la machine sur un circuit muni d’un déclencheur de courts-circuits à la terre. En cas de doute ou de problème, adressez-vous à un électricien qualifié et/ou à votre revendeur Clarke Technology. AVERTISSEMENT Pour réduire les risques de choc électrique, utilisez la machine sur des tapis qui n’ont été...
Page 11 7.6 x 33 Brush Motor Size (W) Dimensions (cm) 84 x 117 x 41 84 x 117 x 41 Weight (kg) 44.5 44.5 Shipping WeightZ (kg) Sound Level (dBA) Vibration (m/s/s) <2.5 <2.5 CLARKE TECHNOLOGY Image 16 230V Operator's Manual Page 11...
Page 12 84 x 117 x 41 cm 84 x 117 x 41 cm Peso 45,5 kg 45,5 kg Peso entrega 52 kg 52 kg Ruido 80 dBA 80 dBA Vibración <2.5 m/s/s <2.5 m/s/s Page 12 CLARKE TECHNOLOGY Image 16 230V Operator's Manual...
Page 13 84 x 117 x 41 cm 84 x 117 x 41 cm Poids 45,5 kg 45,5 kg Poids livraison 52 kg 52 kg Bruit 80 dBA 80 dBA Vibration <2.5 m/s/s <2.5 m/s/s CLARKE TECHNOLOGY Image 16 230V Operator's Manual Page 13...
Page 14 Connect the plug to the receptacle. The green and yellow conductor in the cord is the ground wire. Never connect this wire to any terminal other than the ground terminal. Page 14 CLARKE TECHNOLOGY Image 16 230V Operator's Manual...
Page 15 If the receptacle or connector body does not fit the plug, see your autho- rized Clarke Technology dealer to get an authorized person to make the con- nection. CLARKE TECHNOLOGY Image 16 230V Operator's Manual Page 15...
Page 16 Procure que la distribuidor Clarke Technology para máquina nunca pase por encima del cable de conseguir la ayuda de un técnico cualificado. alimentación. Levante siempre el cable por encima de la máquina. Page 16 CLARKE TECHNOLOGY Image 16 230V Operator's Manual...
Page 17 Introduire la fiche dans la qualifié. prise. Le fil jaune et vert est le fil de terre. Ne jamais faire passer la machine sur le câble d’alimentation. Soulevez toujours le câble au-dessus de la machine. CLARKE TECHNOLOGY Image 16 230V Operator's Manual Page 17...
Page 18 The control knob is located on the right side of the control panel. To increase pump pressure turn the knob clock- wise; to decrease pump pressure turn the knob counter- clockwise. If streaking occurs, increase pressure setting. Page 18 CLARKE TECHNOLOGY Image 16 230V Operator's Manual...
Page 19 Si observa huellas, aumente el reglaje de la presión del cepillo. CLARKE TECHNOLOGY Image 16 230V Operator's Manual Page 19...
Page 20 ® No. 398421. To order Clarkare Defoamer, order Part No. 398420. ® For instructions for preparation and operation of your floor tool, read the operator's manual supplied with your floor tool. Page 20 CLARKE TECHNOLOGY Image 16 230V Operator's Manual...
Page 21 Para la preparación y la utilización correcta de los accesorios para Pour la préparation et l’utilisation correctes des accessoires pour le el suelo, se ruega consultar el manual adjunto. sol, veuillez consulter le manuel qui y est joint. CLARKE TECHNOLOGY Image 16 230V Operator's Manual Page 21...
Page 22 When the solution tank is empty, the recovery tank must be emptied. If the solution in the recovery tank is foamy, the recovery tank may need to be emptied before the solution tank is refilled. Page 22 CLARKE TECHNOLOGY Image 16 230V Operator's Manual...
Page 23 9. Terminer le nettoyage de cette deuxième moitié. 8. Siga trabajando con fajas paralelas que solapan por 2,5 cm. ATTENTION : Clarke Technology ne peut en 9. Termine la limpieza de esta segunda mitad. aucun cas être tenu pour responsable des dégâts ou des CUIDADO: De ningún modo Clarke Technology...
Page 24 8. As you make passes, overlap one inch of the area already cleaned. 9. Make more passes until all of the room is cleaned. CAUTION: Clarke Technology will not be held li- able for damage to the carpet, or poor results because of the operator's lack of ability.
Page 25 9. Terminer le nettoyage de cette deuxième moitié. 8. Siga trabajando con fajas paralelas que solapan por 2,5 cm. ATTENTION : Clarke Technology ne peut en 9. Termine la limpieza de esta segunda mitad. aucun cas être tenu pour responsable des dégâts ou des CUIDADO: De ningún modo Clarke Technology...
Page 26 (mixed as directed). 9. Remove any lint on the vacuum intake screen. The screen is located behind the recovery lid and on the end of the stand pipe. (See Figure 4) Page 26 CLARKE TECHNOLOGY Image 16 230V Operator's Manual...
Page 27 Este filtro se encuentra fixe, derrière le couvercle du réservoir de récupération. en el extremo del tubo fijo detrás de la tapa del depósito de recuperación. (Véase Figura 4) CLARKE TECHNOLOGY Image 16 230V Operator's Manual Page 27...
Page 28 WARNING: Electrical repairs must be done by au- thorized personnel only. WARNING: After electrical repairs are done to the machine, the machine must be tested for electrical safety. Page 28 CLARKE TECHNOLOGY Image 16 230V Operator's Manual...
Page 29 ! AVERTISSEMENT! Après toute réparation électrique, la machine doit être testée du point- de-vue de la sécurite électrique. CLARKE TECHNOLOGY Image 16 230V Operator's Manual Page 29...
Page 30 NOTES...
Page 31 IMAGE 16 ® 230V Section II Parts and Service Manual (70340A)
Page 32 6. Disconnect wiring and place brush housing on bench. 7. Remove bottom plate by removing nine (9) 10-32 screws. 8. Remove motor and reverse procedure to reinstall. 9. Check wiring diagram for proper connections when reinstall- ing electrical parts. Page 32 CLARKE TECHNOLOGY Image 16 230V Operator's Manual...
Page 33 Saque el motor y invierta las operaciones para volver a instalarlo. Compruebe que las conexiones eléctricas son correctas refiriéndose al diagrama de conexiones. CLARKE TECHNOLOGY Image 16 230V Operator's Manual Page 33...
Page 34 5. Carefully pry brush pivot out from bearing (applying pressure unevenly can break brush pivot). 6. Add a small amount of grease to face of seal and bearing on I.D. of brush core. 7. Reassemble in reverse order. Page 34 CLARKE TECHNOLOGY Image 16 230V Operator's Manual...
Page 35 à hermétiser le los rodamientos sean hermetizados. corps de la brosse et les roulements. 7. Monte de nuevo el conjunto siguiendo el orden 7. Remonter l’ensemble en suivant l’ordre inverse. inverso. CLARKE TECHNOLOGY Image 16 230V Operator's Manual Page 35...
Page 36 Brush motor doesn't run. 1. Circuit breaker tripped... 1. Reset circuit breaker. 2. Switch is bad... 2. Contact an authorized service person. 3. Motor is bad..3. Contact an authorized service person. Page 36 CLARKE TECHNOLOGY Image 16 230V Operator's Manual...
Page 37 1. El térmico se desconectó 1. Vuelve a conectar el térmico 2. El interruptor es defectuoso 2. Avise a un técnico autorizado 3. El motor es defectuoso 3. Avise a un técnico autorizado CLARKE TECHNOLOGY Image 16 230V Operator's Manual Page 37...
Page 38 1. Le thermique a déclenché 1. Réenclencher le thermique ne fonctionne pas 2. L’interrupteur est défectueux 2. Faire appel à un technicien agréé 3. Le moteur est défectueux 3. Faire appel à un technicien agréé Page 38 CLARKE TECHNOLOGY Image 16 230V Operator's Manual...
Page 39 52953A General Purpose Spot Cleaner 1 case 55173A 4" Hand Tool and 10' Hose Asm. 1 68204A Coupler, 1½" Hose Connector * 4, 1 gallon bottles **Required to use any accessory CLARKE TECHNOLOGY Image 16 230V Operator's Manual Page 39...
Page 40 CLARKE TECHNOLOGY Image 16i/ix Drawing, Final Assembly 2/02 Page 40 CLARKE TECHNOLOGY Image 16 230V Operator's Manual...
Page 41 Tip, Pink Metering 3 oz/gal. Disconnect 170673 Tie, Cable 80134A Swivel Fitting **FIFQD = Fully 85815A Screw Insulated Female 962308 Screw Quick Disconnect 980692 Washer 50248A Hoseclamp 699202 Cable, Tie 14656A Literature Kit CLARKE TECHNOLOGY Image 16 230V Operator's Manual Page 41...
Page 42 752020 Clamp, Hose 962943 Screw, 8-18 x ½ 82100A Nut, ½ Conduit 839401 Drain, Valve 833407 Gasket, Drain 833901 Handle, Drain, Valve 962987 Screw, 10-24 x 52206A Chain 839410 Valve Asm. Page 42 CLARKE TECHNOLOGY Image 16 230V Operator's Manual...
Page 43 (#20, 21, 22, 25a) 66188C Pivot, Bearing 30076A Strainer 53047A Seal * When servicing these items (#'s 21, 22, and 25) see page 30 (Brush Maintenance). * = Fully Insulated Female Quick Disconnect CLARKE TECHNOLOGY Image 16 230V Operator's Manual Page 43...
Page 44 Washer 84237A Screw, 10-32 x ½ 40149A Cord Asm. 36' 230V (includes 11, 12, 13, 14) 61088A Belt 80156A Screw 81112A 699202 Cable Tie *FIFQD = Fully Insulated Female Quick Disconnect Page 44 CLARKE TECHNOLOGY Image 16 230V Operator's Manual...
Page 45 980666 Washer 47712A Terminal, ¼ Female 40150A Cord Asm 75' (incl 11,13,14,27) 47708A Terminal, 1/4 Male 47711A Terminal, 1/4 Female 52505A Control, Speed 55502A Knob 77187C Label, Increase 699202 Cable Tie CLARKE TECHNOLOGY Image 16 230V Operator's Manual Page 45...
Page 46 Cap w/Gasket Asm. 30042A Gasket, Spray 54157A Nozzle 110° x 1.0 Brass Q.D. 962333 Screw 10-32 x 49067A Wire, Ground 980603 Washer, Star Lock 63061C Bracket, Brush Adj. 30076A Strainer 70369A Label Page 46 CLARKE TECHNOLOGY Image 16 230V Operator's Manual...
Page 47 Plate, Rear Cover 54369A Gasket, Viton 49068A Wire, Ground 50018A Bowl, Clear Filter 10367A Plumbing Asm. (includes 85383A Screw, 10-32 1, 2, 9,19, 20, 21, 22, 23 and 30) 732870 Elbow, Brass CLARKE TECHNOLOGY Image 16 230V Operator's Manual Page 47...
Page 48 Elbow, Brass 10299A Plumbing Asm. (incl. 9, 22, 1, 19, 980603 Washer, #10 Ext. Lock 920224 Nut, 10-32 Hex 21, 18, 20, 31, 33, 32, 30, 23) 962987 Screw, 10-24 x Page 48 CLARKE TECHNOLOGY Image 16 230V Operator's Manual...
Page 49 Part No. Description 53056A Kit, Switch - Viton 80/100 psi 55374A Kit, Dual Check Valves 54881A Housing, Upper 59783A Kit, Valve 53205A Kit, Diaphragm 54882A Housing, Lower 52907A Kit, Drive Assembly CLARKE TECHNOLOGY Image 16 230V Operator's Manual Page 49...
Page 50 53995A Fan, Air Seal 50618A Bracket, End Com. Fan, Stationary Bearing Fan, Rotating 672714 Disc Washer Bearing Washer NOTE: #'s 1,2,3,8,10,11,12,13,14,15,16,17,20,21,22 are Bracket, Fan End not available at this time. Spacer Page 50 CLARKE TECHNOLOGY Image 16 230V Operator's Manual...
Page 51 CLARKE TECHNOLOGY Image 16i/ix Electrical Schematic 4/99 CLARKE TECHNOLOGY Image 16 230V Operator's Manual Page 51...
Page 52 CLARKE TECHNOLOGY Image 16i/ix Wiring Connection Diagram 4/99 Page 52 CLARKE TECHNOLOGY Image 16 230V Operator's Manual...
Page 53 CLARKE TECHNOLOGY Image 16 i ErgoEX Flow Diagram 2/02 CLARKE TECHNOLOGY Image 16 230V Operator's Manual Page 53...
Page 54 CLARKE TECHNOLOGY Image 16i Flow Diagram 2/02 Page 54 CLARKE TECHNOLOGY Image 16 230V Operator's Manual...
Page 55 NL-4131 NJ Vianen 1355 West Oak Common Lane +31 347 324000 (770) 973-5225 ALTO Sverige AB, Molndal (Sweden) Aminogatan 18 CLARKE TECHNOLOGY Box 4029 AMERICAN SANDERS TECHNOLOGY S-431 04 Molndal A.L. COOK TECHNOLOGY +46 31 706 73 00 Customer Service Headquarters and Factory...
Page 56 (b). Return the product to the nearest Clarke Technology repair location. Transportation charges to and from the repair location must be prepaid by the purchaser. (c). Clarke Technology will repair the product and or replace any defective parts without charge within a reasonable time after receipt of the product.
