OWNER'S MANUAL
GAS RANGE
Read this owner's manual thoroughly before operating the appliance
and keep it handy for reference at all times.
WArnInG
If the information in this manual is not followed exactly, a fire or explosion
may result causing property damage, personal injury or death.
• Do not store or use gasoline or other flammable vapors and liquids in the
vicinity of this or any other appliance.
• WHAT TO DO IF YOU SMELL GAS
- Do not try to light any appliance.
- Do not touch any electrical switch.
- Do not use any phone in your building.
- Immediately call your gas supplier from a neighbor's phone. Follow the
gas supplier's instructions.
- If you cannot reach your gas supplier, call the fire department.
• Installation and service must be performed by a qualified installer, service
agency, or the gas supplier.
LSG4515**
LSG4513**
LSG4511**
MFL68920518_06
Copyright © 2017 - 2018 LG Electronics Inc. All Rights Reserved.
www.lg.com

Advertisement

Table of Contents
loading

Related Manuals for LG LSG4515 Series

Summary of Contents for LG LSG4515 Series

  • Page 1 - If you cannot reach your gas supplier, call the fire department. • Installation and service must be performed by a qualified installer, service agency, or the gas supplier. LSG4515** LSG4513** LSG4511** www.lg.com Copyright © 2017 - 2018 LG Electronics Inc. All Rights Reserved. MFL68920518_06...

  • Page 2: Table Of Contents

    Checking Ignition of the Surface Burners (For model : LSG4515) Leveling the Range Engaging the Anti-tip Device SMArT FUnCTIOnS OPErATIOn LG SmartThinQ Application Smart Diagnosis™ Function Gas Surface Burners FCC Notice (For transmitter module contained in Burner Locations this product)

  • Page 3: Product Features

    PRODUCT FEATURES PrODUCT FEATUrES Multiple Gas Burner Sizes Choose a burner to fit the size of your cookware. Cooking multiple items at once is possible by using different burners at the same time. Safe and Convenient Gas range Provides safety and convenience for cooking. Self Clean &...

  • Page 4: Important Safety Instructions

    Always contact your service agent or manufacturer about problems that you do not understand. Download this owner's manual at: http://www.lg.com This is the safety alert symbol. This symbol alerts you to potential hazards that can result in property damage and/or serious bodily harm or death.
  • Page 5 IMPORTANT SAFETY INSTRUCTIONS • Do not rest large, heavy items such as whole turkeys on the open oven door. The range could tip forward and cause injury. • Reengage the anti-tip device after pulling the range out for cleaning, service, or any other reason.
  • Page 6 IMPORTANT SAFETY INSTRUCTIONS WArnInG • Never cover any slots, holes or passages in the oven bottom or cover an entire rack with materials such as aluminum foil. Doing so blocks air flow through the oven and may cause carbon monoxide poisoning. Aluminum foil linings may also trap heat, causing a fire hazard.
  • Page 7 IMPORTANT SAFETY INSTRUCTIONS InSTALLATIOn SAFETY PrECAUTIOnS Have the installer show you the location of the range gas shut-off valve and how to shut it off if necessary. WArnInG • Make sure your range is properly installed and grounded by a qualified installer, according to the installation instructions.
  • Page 8 IMPORTANT SAFETY INSTRUCTIONS WArnInG • To shut off the gas supply to the range, close the range gas shutoff valve by turning it clockwise. Gas pressure regulator valve " Adapter " Adapter Range gas shutoff valve Installer: Inform the consumer of the location of the gas shut-off valve. •...
  • Page 9 IMPORTANT SAFETY INSTRUCTIONS CAUTIOn • Be sure that all surface controls are set in the Off position prior to supplying gas to the range. • Never leave the surface burners unattended at high flame settings. Boilovers may cause smoke and greasy spillovers that may ignite. •...
  • Page 10 10 IMPORTANT SAFETY INSTRUCTIONS BrOILEr Always use a broiler pan and a grid for excess fat and grease drainage. This will help to reduce splatter, smoke, and flare-ups. WArnInG When using your broiler, the temperature inside the oven will be extremely high. Take caution to avoid possible burns by: •...
  • Page 11 IMPORTANT SAFETY INSTRUCTIONS WArnInG • Do not use the oven for storage. Items stored in the oven can catch on fire. • Keep the oven free from grease buildup. • Insert the oven racks in the desired position while the oven is cool. •...

  • Page 12: Product Overview

    Non-scratch scouring pad (1ea) NOTE • Contact LG Customer Service at 1-800-243-0000 (1-888-542-2623 in Canada) if any accessories are missing. • For your safety and for extended product life, only use authorized components. • The manufacturer is not responsible for product malfunction or accidents caused by the use of separately purchased, unauthorized components or parts.

  • Page 13: Installation

    INSTALLATION InSTALLATIOn Product Specifications The appearance and specifications listed in this manual may vary due to constant product improvements. Oven range Models LSG4515, LSG4513, LSG4511 Description Gas Slide In Oven Range Electrical requirements LSG4515: 1 kW 120 VAC / LSG4513: 0.5 kW 120 VAC / LSG4511: 0.5 kW 120 VAC "...

  • Page 14: Installing The Range

    14 INSTALLATION Installing the range Choosing the Proper Location Do not locate your range where it may be subject to Unpacking and Moving the range strong drafts. Any openings in the floor or wall behind the range should be sealed. Make sure the openings CAUTIOn around the base of the range that supply fresh air •...
  • Page 15 INSTALLATION Dimensions and Clearances Provide proper clearance between the range and adjacent combustible surfaces. These dimensions must be met for safe use of your range. The location of the electrical outlet and pipe opening (see Gas Pipe and Electrical Outlet Locations, page 14) may be adjusted to meet specific requirements. The range may be placed with 0" clearance (flush) at the back wall.

  • Page 16: Optional Rear Filler

    16 INSTALLATION Optional rear Filler Installing the Anti-tip Device If the counter does not bridge the opening at the rear Anti-tip Wall plate wall the rear filler kit, that is provided with the slide in bracket range, will be needed. Screw must enter wood or nOTE...

  • Page 17: Connecting The Range To Gas

    INSTALLATION For LP gas, the pressure supplied to the regulator Connect a flexible metal appliance connector to must be between 10" and 13" of water column. When the adapter on the range. Position the range to checking for correct operation of the regulator, the permit connection at the shut-off valve.

  • Page 18: Electrical Connections

    18 INSTALLATION Electrical Connections Do not use an adapter plug. Disconnecting of the power cord places undue strain on the adapter and leads to eventual failure of the adapter ground Electrical requirements terminal. 120 Volt, 60 Hz, properly grounded dedicated circuit Installation must conform with local codes or, in the protected by a 15 or 20 Amp circuit breaker, or slow absence of local codes, with the National Fuel Gas...

  • Page 19: Assembling The Surface Burners

    INSTALLATION Assembling the Surface Quality of Flames Burners The combustion quality of the burner flames needs to be confirmed visually. A Yellow flames - Call for service. CAUTIOn Do not operate the burners without all parts in B Yellow tips on outer cones - This place.

  • Page 20: Leveling The Range

    20 INSTALLATION Leveling the range Checking Operation of Bake / Broil Burners Level the range by adjusting the leveling legs. To check ignition of the Bake burner, follow the steps Extending the legs slightly may also make it easier to insert the rear leg into the anti-tip bracket.

  • Page 21: Operation

    OPERATION OPErATIOn Burner Locations Your gas range cooktop has four or five sealed gas burners, depending on the model. These can be Gas Surface Burners assembled and separated. Follow the guide below. Before Use Read all instructions before using. Make sure that all burners are properly placed. LSG4513, LSG4515 Make sure that all grates are properly placed before using the burner.

  • Page 22: Using The Gas Surface Burners

    22 OPERATION Using the Gas Surface Burners In Case of Power Failure In case of a power failure, you can light the gas Be sure that all of the surface burners and grates surface burners on your range with a match. are placed in the correct positions.

  • Page 23: Using A Wok

    OPERATION Using a Wok nOTE • The wok grate and griddle cannot be used at If using a wok, use a 14-inch or smaller flat-bottomed the same time. piece of wok. Make sure that the wok bottom sits flat • For best performance, place the wok grate over on the grate.

  • Page 24: Using The Griddle

    24 OPERATION Using the Griddle Preheat the griddle according to the guide below and adjust for the desired setting. (For Model : LSG4513, LSG4515) Preheat Cook Type of Food Conditions Setting Warming Tortillas 5 (MED) Pancakes HI 5 min. Hamburgers HI 5 min.

  • Page 25: The Oven

    OPERATION The Oven Do not block, touch or place items around the oven vent during cooking. Before Use Your oven is vented through ducts at the center above the burner grate. Do not block the oven vent when Read all instructions before using. cooking to allow for proper air flow.

  • Page 26: Control Panel Overview

    26 OPERATION Control Panel Overview For Model : LSG4515 seconds For Model : LSG4513 / LSG4511 For Model : LSG4513 For Model : LSG4511 seconds...
  • Page 27 OPERATION 1 Smart Diagnosis 8 - /+ Use during the Smart Diagnosis feature. Press the plus button to increase cooking time or oven temperature. 2 Cook Time / Clock Press the minus button to decrease cooking time or • Press the button to set the desired amount of time oven temperature.

  • Page 28: Changing Oven Settings

    28 OPERATION Changing Oven Settings Minimum & Maximum Default Settings Clock All of the features listed have a minimum and a The clock must be set to the correct time of day in maximum time or temperature setting that can be order for the automatic oven timing functions to work entered into the control.

  • Page 29: Timer On/Off

    OPERATION Timer On/Off Settings The Timer On/Off serves as an extra timer in the Set the oven mode knob to the Off position. kitchen that beeps when the set time has run out. It Press and hold Start Time for three seconds(LSG4515 model only) or press Setting does not start or stop cooking.

  • Page 30: Adjusting The Oven Thermostat

    30 OPERATION Adjusting the Oven Thermostat Adjusting the Beeper Volume Your new oven may cook differently from the one Set the oven mode knob to the Off position. it replaced. Use your new oven for a few weeks to become more familiar with it before changing the Press Setting repeatedly until Beep appears in temperature settings.

  • Page 31: Start Time (Delayed Timed Cook)

    OPERATION Start Time (Delayed Timed Cook) Cook Time (Timed Cook) The automatic timer of the Delayed Timed Cook Set the oven to cook for a specific length of time function turns the oven on and off at the time you using the Timed Cook feature.

  • Page 32: Removing And Replacing The Oven Racks

    32 OPERATION removing and replacing the Oven recommended Baking and roasting racks Guide • Center pans on racks for best baking results. If CAUTIOn baking with more than one pan, place the pans so • Replace the oven racks before turning the oven that each one has at least 1"...

  • Page 33: Bake

    OPERATION Bake Baking Chart This chart is only for reference and can be used for Bake is used to prepare foods such as pastries, oven. Adjust the cook time according to your recipe. breads and casseroles. The oven can be programmed to bake at any temperature from 170 °F (80 °C) to Food Oven Temperature...

  • Page 34: Convection Mode

    34 OPERATION Convection Mode Convection Baking Chart If auto conversion is disabled, reduce standard The convection system uses a fan to circulate heat recipe temperature by 25 °F (14 °C) for Convection evenly within the oven. This improves heat distribution Bake.

  • Page 35: Cookware For Convection Cooking

    OPERATION Cookware for Convection Cooking Convection roast Any cookware safe for use in a conventional oven will The Convection Roast feature is designed to give work in a convection oven. But for best results, keep optimum roasting performance. Convection Roast the following in mind.

  • Page 36: Broil

    36 OPERATION Broil Setting the oven to Broil Turn the oven mode knob to select Broil High or Your oven is designed for closed-door broiling. Broil uses an intense heat radiation from the upper gas Broil Low. burner. Press Start. The Broil function works best when broiling thin, tender cuts of meat (1"...
  • Page 37 OPERATION recommended Broiling Guide The size, weight, thickness, starting temperature, and your preference of doneness will affect broiling times. This guide is based on meats at refrigerator temperature. For best results when broiling, use a pan designed for broiling. Second rack First Side Food...

  • Page 38: Favorite (For Model : Lsg4511)

    38 OPERATION Favorite (For model : LSG4511) Pizza Use the Favorite feature to record and recall favorite This function automatically sets the oven temperature recipe settings. Favorite can store and recall up to to cook either frozen pizza with regular or rising crust, three settings.

  • Page 39: Warm

    OPERATION Warm Meat Probe (For model : LSG4515) This function will maintain an oven temperature of The meat probe accurately measures the internal 170 °F. The Warm function will keep cooked food temperature of meat, poultry and casseroles. It should warm for serving up to three hours after cooking has not be used during broiling, self clean, warming or finished.

  • Page 40: Remote Start

    40 OPERATION IMPOrTAnT nOTE Setting remote Start Turn the oven mode knob to the Off position to Open the oven door to make sure the oven is cancel the Meat Probe function at any time. To avoid empty and ready for pre-heating. Close the oven breaking the probe, make sure food is completely door.

  • Page 41: Operating The Warming Drawer

    OPERATION Setting the Warming Drawer Control Touch and hold Start Time for three seconds. Sb appears in the display when the Sabbath Press Warming Drawer Set/Off. The indicator mode is activated. light will flash. (If no further buttons are pressed within 25 seconds, the display will clear.) To stop Sabbath mode, touch and hold Start Time for three seconds.

  • Page 42: Smart Functions

    → Cellular → Cellular Data. Installing the LG SmartThinQ Application Search for the LG SmartThinQ application from the Connect your smartphone to the wireless router. Google Play Store or Apple App Store on a smart phone. Follow instructions to download and install the application.

  • Page 43: Smart Diagnosis™ Function

    Use the Smart Diagnosis feature in the LG SmartThinQ application. SmartThinQ application for help diagnosing issues with the appliance without the assistance of the LG Customer Information Center. Follow the instructions in the LG SmartThinQ application to perform a Smart Diagnosis using your smartphone.

  • Page 44: Fcc Notice (For Transmitter Module Contained In This Product)

    Operation is subject to the following two conditions: available for download. 1) this device may not cause harmful interference LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of...

  • Page 45: Maintenance

    MAINTENANCE MAInTEnAnCE Cleaning Burner Heads/Caps For even and unhampered flame, the slits in the CAUTIOn burner heads must be kept clean at all times.The burner heads and caps (and the oval burner head • Do not clean this appliance with bleach. and cap assembly) can be lifted off.
  • Page 46 46 MAINTENANCE Burner Grates Cleaning the Cooktop Surface The range consists of three separate professional- CAUTIOn style grates. For maximum stability, these grates • To avoid burns, do not clean the cooktop should only be used when in their proper position. The surface until it has cooled.

  • Page 47: Cleaning The Exterior

    1-800-243-0000 (USA), 1-888-542-2623(CANADA) or visit our website at: www.lg.com Oven Door • Use soapy water to thoroughly clean the oven door. Rinse well. Do not immerse the door in water.

  • Page 48: Door Care Instructions

    Compared to the more intense Self Clean process, your LG oven gives you the option of cleaning with LESS HEAT, LESS TIME, and virtually NO SMOKE OR FUMES.
  • Page 49 MAINTENANCE When to Use EasyClean ® Suggested Types of Common Food Items Example of Oven Soiling Soil Pattern Cleaning Method Soils That Can Soil Your Oven Cheese Small drops or or other Pizza spots ingredients Steaks, broiled EasyClean ® Fish, broiled Light splatter Fat/grease Meat roasted at low...

  • Page 50: Self Clean (For Model : Lsg4513, Lsg4515)

    50 MAINTENANCE Spray or pour the remaining 1 cup (8 oz or 250 If some light soils remain, repeat the above ml) of water onto the bottom center of the oven steps, making sure to thoroughly soak the cavity. The indentation on the oven bottom soiled areas.
  • Page 51 MAINTENANCE Setting Self Clean CAUTIOn The Self Clean function has cycle times of 2, 3 or 5 • Do not leave small children unattended near hours. the appliance. During the Self Clean cycle, the outside of the range can become very hot to Self Clean Soil Guide the touch.

  • Page 52: Changing The Oven Light

    52 MAINTENANCE During Self Clean WArnInG • The Self Clean cycle uses extremely hot • Make sure that the oven and bulb are cool. temperatures to clean the oven cavity. While • Disconnect the electrical power to the range at running the Self Clean cycle, you may notice the main fuse or circuit breaker panel.
  • Page 53 MAINTENANCE removing the Drawer Firmly grasp both sides of the door at the top. CAUTIOn Close the door to the removal position (approximately five degrees) which is halfway Disconnect the electrical power to the range at between the broil stop position and fully closed. the main fuse or circuit breaker panel.

  • Page 54: Troubleshooting

    54 TROUBLESHOOTING TrOUBLESHOOTInG Can I use aluminum foil to catch drippings in my oven cavity? Never use aluminum foil to line the bottom or sides of FAQs the oven or the warming drawer. The foil will melt and stick to the bottom surface of the oven and will not be What types of cookware are recommended for removable.
  • Page 55 TROUBLESHOOTING My range is still dirty after running the Is it safe for my convection fan, broil burner or ® ® EasyClean cycle. What else should I do? heater element to get wet during EasyClean ® The EasyClean cycle only helps to loosen light soils Yes.

  • Page 56: Before Calling For Service

    56 TROUBLESHOOTING Before Calling for Service Before you call for service, review this list. It may save you time and expense. The list includes common occurrences that are not the result of defective workmanship or materials in this appliance. Symptoms Possible Cause / Solutions •...
  • Page 57 TROUBLESHOOTING Symptoms Possible Cause / Solutions Too much soil in the oven. Open the windows to get rid of the smoke from the Too much smoke room. Turn the oven mode knob to select Self Clean. Wait until the light goes off during the Self Clean before trying to open the oven door.
  • Page 58 58 TROUBLESHOOTING Symptoms Possible Cause / Solutions • The password for the Wi-Fi network was entered incorrectly. - Delete your home Wi-Fi network and begin the registration process again. • Mobile data for your smartphone is turned on. - Turn off the Mobile data on your smartphone before registering the appliance. •...

  • Page 59: Limited Warranty

    PERMITTED. PLEASE SEE THE SECTION TITLED “PROCEDURE FOR RESOLVING DISPUTES” BELOW. Should your LG Gas Range ("Product") fail due to a defect in materials or workmanship under normal and proper use, during the warranty period set forth below, LG Electronics (“LG”) will, at its option, repair or replace the Product.
  • Page 60 60 LIMITED WARRANTY • Any noises associated with normal operation. • Use of accessories, components, or consumable cleaning products that are not authorized by LG. • Replacement of light bulbs, filters, fuses or any other consumable parts. • When Product is used for other than normal and proper household use (e.g. commercial or industrial use, offices, and recreational facilities or vehicles) or contrary to the instructions outlined in the Product’s owner’s...
  • Page 61 LIMITED WARRANTY Problem Cause Prevention • Knobs melt Improper usage • Do not leave door at stop position during Broil/Bake mode or right after cooking. • Oven or racks are Aluminum foil has melted in the oven • Never cover the oven bottom stained after using or cover an entire rack with aluminum foil...
  • Page 62 The cost of repair or replacement under the above excluded circumstances shall be borne by the consumer. TO OBTAIN WARRANTY SERVICE AND ADDITIONAL INFORMATION Call 1-800-243-0000 and select the appropriate option from the menu. Or visit our website at http://www.lg.com Or by mail: LG Electronics Customer Service P.O. Box 240007 Huntsville, AL 35813 ATTN: CIC...
  • Page 63 If you and LG are unable to resolve the dispute within 30 days, either party may proceed to file a claim for arbitration.
  • Page 64 Opt Out. You may opt out of this dispute resolution procedure. If you opt out, neither you nor LG can require the other to participate in an arbitration proceeding. To opt out, you must send notice to LG no later than 30 calendar days from the date of the first consumer purchaser’s purchase of the product by either: (i) sending an e-mail to...
  • Page 65 LG Customer Information Center 1-800-243-0000 1-888-542-2623 CANADA Register your product Online! www.lg.com Printed in Korea...
