Summary of Contents for AGV INSYDE

  • Page 1 INSYDE User manual...
  • Page 2 AGV is a brand owned by Dainese S.p.A., company with QMS certified in accordance to ISO 9001 standard. The Bluetooth ® logo and wordmark are owned by Bluetooth SIG, Inc. and any use of such marks by Cardo Systems Ltd, is under license.

  • Page 3: Table Of Contents

    CONTENTS 1 SAFETY INFORMATION ............04 2 GETTING STARTED ..............06 2.1 Getting to know your INSYDE ........... 06 2.2 Charging INSYDE ............. 06 2.3 Switching on/off ............... 07 2.4 Using your INSYDE ............07 2.5 Pairing your unit to Bluetooth ®...

  • Page 4: Safety Information

    1 SAFETY INFORMATION Please ensure that the product is properly used by observing the warnings and cautions below to prevent any risk and/or damage to property. 1.1 PRODUCT STORAGE AND MANAGEMENT • Keep the product free of dust. It may damage mechanical and electronic parts of the product. •...
  • Page 5 • In any place where wireless communication is prohibited, such as hospitals or airplanes, turn off the power and refrain from using the product. In a place where wireless communication is prohibited, electromagnetic waves may cause hazards or accidents. • Do not use the product near hazardous explosives. When it is near any explosion hazards, turn off the power and heed any regulations, instructions, and signs in the area.

  • Page 6: Getting Started

    2.2 CHARGING INSYDE Make sure that your INSYDE battery is charged for at least 4 hours before initial use. To charge the unit: Using the supplied USB cable, connect your computer or wall charger to the USB port on your INSYDE.

  • Page 7: Switching On/Off

    To switch your INSYDE off: • Press both 1” → The LED flashes red three times, confirming that you INSYDE is switching off. The speak- ers plays a descending tone and a voice message, “Goodbye”. 2.4 USING YOUR INSYDE You can operate the various features of you INSYDE in the following ways: •...
  • Page 8 ® devices. 6. When your INSYDE appears in the list of available devices, select it. If prompted for a PIN or Passkey, enter 0000 (four zeros). → The device confirms that pairing has succeeded and the LED flashes purple for 2 sec-...
  • Page 9 If pairing is not completed within 2', the unit automatically returns to Standby. If you have paired two different mobile phones directly to your INSYDE, set one as default for making calls (see Setting the Default Mobile Phone). Not all Bluetooth ®...

  • Page 10: On The Road

    3 ON THE ROAD INSYDE makes it easy for you to receive phone calls and listen to music in a convenient and safe manner. 3.1 BASIC AUDIO FUNCTIONS The basic audio functions are the same whether you are listening to music, speaking on the inter- com, or having a phone conversation.

  • Page 11: Making And Receiving Phone Calls

    3.2 MAKING AND RECEIVING PHONE CALLS You can use your mobile phone to make and receive phone calls while paired to your INSYDE. You can make a hands-free call using your mobile phone's voice dial option or using the Cardo speed dial or redial last call options.

  • Page 12: Listening To Music

    3.2.1 SWITCHING BETWEEN TWO CALLS ON TWO MOBILE PHONES Your INSYDE can toggle between two calls on two mobile phones when both mobile phones are paired to your unit. To toggle between two calls on two mobile phones (without disconnecting either call): •...

  • Page 13: Listening To Fm Radio

    To skip to the previous track (while streaming): • Tap or say "Hey Cardo, previous track." 3.4 LISTENING TO FM RADIO The INSYDE is equipped with a built-in FM radio. To turn on the FM radio: • Tap twice or say "Hey Cardo, radio on."...

  • Page 14: Switching Music Sources

    • Tap within 20" of stopping the scan. 3.5 SWITCHING MUSIC RESOURCES If two music (A2DP) audio sources are paired, INSYDE uses the audio source from which you last played music. To switch to the other audio source: 1. Stop music (A2DP) playback from the current device (see Listening to Music).

  • Page 15: Riding With Others

    "Hey Cardo, call intercom" 4 RIDING WITH OTHERS Your INSYDE features two distinct intercom communication modes: the traditional Bluetooth ® protocol and the Cardo's Dynamic Mesh Communications (DMC) technology. DMC is the best way to communicate in a group. In DMC mode, you can instantly create or join a dynamically fluid network of up to 15 riders to communicate in full conference mode.
  • Page 16 To create a DMC group: 1. Confirm all group units are in DMC intercom mode (LED flashes green slowly). If your INSYDE is not in DMC intercom mode, tap 2. The group creator and all group members: press for 5" .
  • Page 17 If you join a new DMC group, you automatically leave your existing DMC group. To join an existing DMC group: 1. Confirm both your INSYDE and the creator's unit are in DMC intercom mode (LED flashes green slowly): if your INSYDE is not in DMC intercom mode, tap 2.
  • Page 18 If you delete a DMC intercom group, you must rejoin it if you want to connect to it again in the future. To delete a DMC group: 1. Confirm your INSYDE is in DMC intercom mode (LED flashes green slowly): if your INSYDE is not in DMC intercom mode, tap 2. Press for 5".
  • Page 19 4.1.2.4 Background audio level and audio source priorities The INSYDE can use parallel audio streaming to stream audio from two connected sources si- multaneously, so that you can listen to your music or the FM radio while holding a DMC intercom conversation.

  • Page 20: Bluetooth Intercom

    Pairing a channel replaces any existing paired unit on that channel with the new unit. The Intercom range with other models is limited to the distance of the unit with the shorter range. For details on how to pair and use your INSYDE with other Cardo units, go to Setting Up Non-DMC Intercom Groups.
  • Page 21 3. To add a 3 rider: • Press for 5". 5” → The LED flashes red. • Tap twice. Rider 1 Rider 2 → The following announcement is heard: Rider B pairing. Bluetooth intercom pairing needs to be initiated on the other device. ®...
  • Page 22 To pair a non-Cardo Bluetooth intercom group unit: ® 1. Confirm your unit is in Standby Bluetooth ® intercom mode (LED flashes blue slowly). If your unit is not in Bluetooth ® intercom mode, tap For more information, see Switching between Intercom modes. 2.
  • Page 23 3. To add a 3 rider: • Press for 5". 5” → The LED flashes red. • Tap 2 times. → The LED flashes blue. • Tap → The LED flashes red and blue. Rider 1 Rider 2 Bluetooth ® intercom pairing needs to be initiated on the other device.
  • Page 24 4.2.2 USING THE BLUETOOTH ® INTERCOM 4.2.2.1 Starting / Ending Bluetooth ® intercom calls To start or end communication with Rider 1: • Rider 1: tap To start or end communication with Rider 2: • Rider 2: tap twice. To initiate a 4-way Bluetooth ®...

  • Page 25: Sharing Music And Radio

    When stop music sharing, music continues on your unit only. To start or end communication with Rider 2: 1. Confirm your INSYDE is in Bluetooth ® intercom mode (LED flashes blue slowly).

  • Page 26: Switching Between Intercom Modes

    4.4 SWITCHING BETWEEN INTERCOM MODES Your INSYDE unit can work in only one intercom mode at a time. The current intercom mode is indicated by the color of the LED: • When in DMC intercom mode, the LED flashes green at approximately 4-second intervals.

  • Page 27: Reset To Factory Settings

    → The LED flashes purple 5 times slowly, confirming that pairing has been reset. 5.3 RESET TO FACTORY SETTINGS This option deletes all paired units and devices. To reset the factory settings: 1. Check that your INSYDE is in Standby (see INSYDE LED Indications). 2. Simultaneously press for 5". 5”...

  • Page 28: Personalizing Your Device

    6 PERSONALIZING YOUR DEVICE Get the most out of your INSYDE by changing the settings and customizing your unit according to your own personal preferences, using either of the following methods: • Cardo Connect App on iOS or Android devices.
  • Page 29 Object Default value Description Cardo Connect (iOS / Android) Mobile priority Mobile 1 If you paired your unit to two mobile phones, you must set one of them as the default phone for outgoing calls. Parallel audio Disable You can hear two audio sources simultaneously. For streaming in example, hear GPS while listening to music.

  • Page 30: Setting The Default Mobile Phone

    Parallel audio streaming may not work properly with some iOS devices (i.e., music player or GPS navigator) due to connected device limitations. Your INSYDE sets the various audio sources to either foreground (volume remains the same) or background (volume reduced) as described in the following table:...

  • Page 31: Audio Source Priorities

    Music can be streamed in the background during an active DMC intercom call. You can configure parallel audio streaming via the Cardo Connect app. 6.3 AUDIO SOURCES PRIORITIES If Parallel Audio Streaming is disabled, INSYDE manages the audio sources you hear through the speakers according to the following audio source priorities. Priority...

  • Page 32: Led Indications

    Your INSYDE operates in various modes. Each mode consists of a group of features currently availa- ble for your use. For example, when INSYDE plays music, it will be in music playing mode, enabling features related to playing music such as skipping to the next and previous tracks.

  • Page 33: Glossary

    8 GLOSSARY Term / Abbreviation Description A2DP Advanced Audio Distribution Profile (for music). A protocol for playing music over Bluetooth ® AGC sensitivity AGC (Automatic Gain Control) automatically adjusts speaker volume according to ambient noise and riding speed. Device Mobile phone, GPS or music player. Dynamic Mesh Communications.
