Summary of Contents for ADVANCE Easy Moving NOVA 1 PLUS
- Page 1 ASSEMBLY, USE AND MAINTENANCE MANUAL CENTRAL VACUUM UNIT NOVA 1 PLUS...
- Page 3 INSTRUCTION MANUAL • Type: feeding system for solid fuel boilers • Model: Nova 1 Plus • Revision 1.0.1 VACUUM UNIT NOVA 1 Plus INDEX INTRODUCTION 1.1 Use of this manual WARNINGS 2.1 Installer’s responsibilities TECHNICAL DATA, EXPLODED VIEW DRAWINGS AND DIMENSIONS 3.1 Identifi...
- Page 4 Instruction manual for vacuum unit 1 INTRODUCTION Dear customer, the manufacturer would fi rstly like to thank you for the choice you made in buying an our product, whose technical features will certainly meet Your needs. Our products have been designed and manufactured in total compliance with the current regulations, by choosing the best materials to obtain durability and ease of use of the product.
- Page 5 3 TECHNICAL DATA, EXPLODED VIEW DRAWINGS AND DIMENSIONS Model Nova 1 Plus Article AP1000.50.07 English Dust inlet pipe Ø mm Discharge pipe Ø mm IP protection degree Operating temperature min/max °C 0 ÷ 40 Degree of humidity min/max 30 ÷ 95...
- Page 6 Instruction manual for vacuum unit Thermal switch Activation signal cable (micro lines) Soundproof dome Printed Circuit Board Electric power cable Main switch Motor Air exhaust (blowing outlet) Dust inlet with (suction inlet) Filter cartridge Machine body Bucket seal holder Handle and closure hook Dust container 08/07/22 Rev:1.0.1...
- Page 7 Thermal switch Cover English Main switch Dome Printed Circuit Board Upper motor seal Motor Soundproofi ng sponge Fixing Lower motor seal plate air venting Front Dust inlet with Machine body Dust entry seal Handle and closure hook Filter cartridge Filter tightening knob Conveyor cone with gasket...
- Page 8 Instruction manual for vacuum unit 3.1 Identifi cation plate The CE identifi cation plate is located to the piping network attachment side. Do not remove or damage the plate. Vacuum unit type Manufacturer identifi cation ......................CE Mark of Model: conformity P/N:...
- Page 9 4 KIT AND ACCESSORIES Check that the product corresponds to what was ordered and that there is no obvious damage caused by transport, otherwise notify the retailer immediately. English After opening the packaging, check that the material contained in the package is conforms to the list below: N°1 vacuum unit N°1 fi...
-
Page 10: Proper Use Of The Product
Instruction manual for vacuum unit 5 PROPER USE OF THE PRODUCT The vacuum unit has been designed to be installed for the pneumatic transport of pellets or other biomass fuels with a medium-fi ne size: it can move a large amount of air into the pipes connected, allowing the solid fuel to be conveyed and transported together with the air. - Page 11 3- in single-pipe systems, the maximum length allowed for the various sections of pipe, despite being limited by the components chosen for your system, is more generous, but even in these ca- ses it is necessary to evaluate in advance the characteristics and technical data provided for each component installed.
- Page 12 Instruction manual for vacuum unit 6.3 Connection to the piping network Using the sleeves or a fl exible hose section, connect the suction and discharge pipes from the system to the vacuum unit. Do not glue the hoses extremities to the vacuum unit’s joints. The maximum gross length admitted between the point of fuel sampling and system is 30 m.
-
Page 13: Electrical Connection
6.4 Electrical Connection Before making the electrical connection, check that the supply voltage corresponds to the one required and that the electrical system to which the product is connected English is done in compliance with current regulations. Connect the two MICRO line wires to the MICRO OUT terminal on the control panel. Connect the power cable to a 230 V ac power outlet. -
Page 14: Thermal Switch
Instruction manual for vacuum unit If the vacuum unit is used only for pneumatic fuel transport, its operation is managed automatically by the control panel, and it only works when it is required to transport the fuel. If the plant is also used for dust aspiration and so if one or more aspiration sockets have been provided in the system, its operation is twofold and it is always managed by the control panel. -
Page 15: Spare Parts
8 MAINTENANCE AND END-OF-LIFE Before carrying out any maintenance operation, it is obligatory to disconnect the power supply cable from the main socket and to aerate the premises in which it is installed for at least 15 minutes. English Complex or long maintenance operations must be done out of fuel storage and heating unit premises. -
Page 16: Safety Requirements
Instruction manual for vacuum unit 9 SAFETY REQUIREMENTS FOR FUEL STORAGE TANKS SAFETY REQUIREMENTS for pellet storage tanks with capacity up to 10 t Keep the doors closed. Access is permitted only to authorized personnel under the supervision of a person outside Do not smoke and approach fl... -
Page 17: Warranty
10 WARRANTY PRODUCT LIMITED WARRANTY CONDITIONS English The Manufacturer guarantees to the original purchaser the absence of defects in material and workmanship of the product for the period stated, from the date of purchase. Except as prohibited by applicable law, this warranty is non transferable and it is limited to the original purchaser. - Page 18 Instruction manual for vacuum unit 11 CERTIFICATION Declaration of absence of harmful substances The manufacturer declares that their products and equipment are made with materials compliant with the current regulations regarding protection of health and the environment and does not contain substances classifi...
- Page 20 F0920247.1 info@advanceeasymoving.com - www.advanceeasymoving.com...
