- Page 1 ASSEMBLY, USE AND MAINTENANCE MANUAL Motorized Tank M-TANK...
- Page 3 INSTRUCTION MANUAL • Type: Motorized Tank • Revision 1.0.1 MAGAZZINO MOTORIZZATO INDEX INTRODUCTION 1.1 Use of this manual WARNINGS TECHNICAL DATA AND DIMENSIONS 3.1 Identifi cation plate 3.2 Safety symbols PACKAGING CONTENT INSTALLER’S RESPONSIBILITIES PROPER USE OF THE PRODUCT INSTALLATION PIPES CONNECTION ELECTRICAL CONNECTION 10 START UP AND USE...
- Page 4 Motorized Tank 1 INTRODUCTION Dear customer, the manufacturer would fi rstly like to thank you for the choice you made in buying an our product, whose technical features will certainly meet Your needs. Our products have been designed and manufactured in total compliance with the current regulations, by choosing the best materials to obtain durability and ease of use of the product.
-
Page 5: Technical Data And Dimensions
3 TECHNICAL DATA AND DIMENSIONS Rear view English Article AP3460.00.01 AP3460.00.02 Protec on degree IP20 Opera ng temperature °C 0 ÷ 40 min/max Degree of humidity min/max 40 ÷ 80 Power supply V ac Frequency Motor power 1350 Max absorp onx Thermal switch Fuse T16A5x20... - Page 6 Motorized Tank 3.1 Identifi cation plate Do not remove or damage the identifi cation plate. Type of equipment Manufacturer identifi cation ......................CE Mark of Model: conformity P/N: S/N: Serial number Item number Technical data of the equipment 3.2 Safety symbols DANGER OF VOLTAGE OR ELECTRICAL CURRENT Danger of serious personal injuries.
-
Page 7: Packaging Content
4 PACKAGING CONTENT After opening the packaging, verify that the material contained in it conforms to the following list: 1) motorized Tank 5) minimum level sensor with fl ange English 2) bag support grid 6) rubber gasket 3) cover 7) Warranty form 4) n°... -
Page 8: Installation
Motorized Tank 7 INSTALLATION It is the installer’s responsibility to verify the presence of any risk of danger in the installation area and to determine the suitability in accordance with both the applicable laws and the product characteristics described in this manual. Only specialized technical personnel are authorized to do the installation and maintenance of the product. -
Page 9: Electrical Connection
9 ELECTRICAL CONNECTION fi gure 3 Before making the electrical connection to the mains, check that the voltage corresponds to that required and that the electrical system to which the English product is connected is built in compliance with current regulations. Connect the two wires called REED with the corresponding ones coming from the sensor of the dispenser installed on the boiler (see fi... - Page 10 Motorized Tank The operating time may also need to be changed at any time in the future to accommodate a different type or specifi c weight of the fuel used. When the fuel level inside the motorized warehouse decreases, the sensor located inside it (see Figure 2) will stop the engine operation, leaving the transport system in standby mode, as soon as the correct fuel level is restored, the system will restart automatically.
- Page 11 11 MAINTENANCE AND END-OF-LIF The normal maintenance of the motorized tank includes: - periodic cleaning of the bottom to prevent excessive dust deposits English - cleaning the motor ventilation grides with compressed air Using fuels with a low presence of dust guarantees a better functioning of the motorized tank 11.1 End-of-life The disposal of packaging, accessories and machine must be executed in accordance with applicable laws, ensuring the recycling of any of the core components.
-
Page 12: Safety Requirements
Motorized Tank 12 SAFETY REQUIREMENTS FOR FUEL STORAGE TANKS SAFETY REQUIREMENTS for pellet storage tanks with capacity up to 10 t Keep the doors closed. Access is permitted only to authorized personnel under the supervision of a person outside Do not smoke and approach fl ames or other sources of ignition. -
Page 13: Warranty
13 WARRANTY PRODUCT LIMITED WARRANTY CONDITIONS English The Manufacturer guarantees to the original purchaser the absence of defects in material and workmanship of the product for the period stated, from the date of purchase. Except as prohibited by applicable law, this warranty is non transferable and it is limited to the original purchaser. - Page 14 Motorized Tank 14 CERTIFICATION Declaration of absence of harmful substances The manufacturer declares that their products and equipment are made with materials com- pliant with the current regulations regarding protection of health and the environment and does not contain substances classifi ed as SVHC (Substance of Very High Concern) in accordance with Regulation EC 1907/2006 (REACH, or registration, evaluation, authorization and restric- tion of chemical substances).
- Page 15 English 15/12/21 Rev:1.0.1...
- Page 16 F0920593.03 info@advanceeasymoving.com - www.advanceeasymoving.com...
