- Page 1 ENIGMA SPIRIT WHEELCHAIR Enigma Spirit Wheelchair Owners Handbook Page 1 of 16 Part Code: Z15996 (Rev A)
-
Page 2: Table Of Contents
8. Using the Stepper Tube 2 . I N T R O D U C T I O N The Enigma Spirit wheelchair been designed with elegance and quality in mind. It is suitable for occasional or frequent use, and can be used outdoors and indoors. -
Page 3: Parts Description
3 . P A R T S D E S C R I P T I O N PUSH HANDLE BACK CANVAS HALF-FOLD MECHANISM ARMREST REAR WHEEL QUICK RELEASE PIN PARKING BRAKE CASTOR WHEEL LEG REST Enigma Spirit Wheelchair Owners Handbook Page 3 of 16 Part Code: Z15996 (Rev A) - Page 4 When the desired angle is reached, release the button to lock. Enigma Spirit Wheelchair Owners Handbook Page 4 of 16 Part Code: Z15996 (Rev A)
- Page 5 Then repeat for the other side. Warning: Do not pull on the black lever as this could result in damage and/or injury. Enigma Spirit Wheelchair Owners Handbook Page 5 of 16 Part Code: Z15996 (Rev A)
- Page 6 45º then swing the legrest inwards until it locks in position. Warning: Always ensure the legrest is properly reinstalled and locked in position before use. Enigma Spirit Wheelchair Owners Handbook Page 6 of 16 Part Code: Z15996 (Rev A)
- Page 7 Pull up in the centre of the front and rear of the seat canvas and the wheelchair will naturally fold up. Enigma Spirit Wheelchair Owners Handbook Page 7 of 16 Part Code: Z15996 (Rev A)
- Page 8 The parking brakes should always be applied when transferring. The wheelchair brakes and parking brakes and are not suitable for slowing the wheelchair down. Enigma Spirit Wheelchair Owners Handbook Page 8 of 16 Part Code: Z15996 (Rev A)
- Page 9 To apply the brakes, push down on the brake handle (shown by white arrow). To unlock the brakes, pull up on the brake handle (shown by black arrow). Enigma Spirit Wheelchair Owners Handbook Page 9 of 16 Part Code: Z15996 (Rev A)
- Page 10 The attendant uses the stepper tube to raise the front castors and tip the user slightly back. Keeping the castors raised, slowly lower the wheelchair down the kerb. Enigma Spirit Wheelchair Owners Handbook Page 10 of 16 Part Code: Z15996 (Rev A)
-
Page 11: Using The Wheelchair In A Vehicle
10. TYRE PRESSURE AND INFLATIO N The Enigma wheelchair comes with solid tyres on both front and rear wheels, and hence there is no need to monitor tyre pressure. -
Page 12: Care And Maintenance
Castors Rear wheel quick release pin Brakes Anti-tip bar adjustment Legrest locking mechanism Half folding back mechanism Seat upholstery Back posts Back upholstery Wheelchair (folds up) Enigma Spirit Wheelchair Owners Handbook Page 12 of 16 Part Code: Z15996 (Rev A) -
Page 13: Specification
12. SPECIFICATIO N Model XSES18 (Spirit wheelchair) Overall D* 97 x 71 x 91cm / 38¼” x 28¼” x 36” Folded Width 32cm / 12½” Seat D* 40 x 45 x 48cm / 16” x 18” x 18¾” Carry Weight 5.8kg / 13lb... - Page 14 The frames on Enigma aluminium wheelchairs have a five-year warranty. In the event of your wheelchair requiring attention, please contact your service agent / dealer and give all relevant details so they can act quickly.
- Page 15 Please contact your local Drive Medical Dealer for a catalogue. Drive Medical Ltd, Dealer Stamp Ainley’s Industrial Estate, Elland, West Yorkshire HX5 9JP. Tel: +44 (0) 1422 314488 Email: enquiries@drivemedical.co.uk Web: www.drivemedical.co.uk Enigma Spirit Wheelchair Owners Handbook Page 15 of 16 Part Code: Z15996 (Rev A)
- Page 16 Enigma Spirit Wheelchair Owners Handbook Page 16 of 16 Part Code: Z15996 (Rev A)
